Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 415130433 | MODULE_CHASSIS TUNNEL 137 B-160 Includes 10 to 10au | ||
| 1 | 518330738 | Deep Black, RH Footrest Reinforcement | 1 |
| 1 | 518331523 | Deep Black, LH Footrest Reinforcement | 1 |
| 1 | 518329010 | RH Footrest | 1 |
| 1 | 518329011 | LH Footrest | 1 |
| 1 | 518331253 | Stirrup Reinforcement | 1 |
| 1 | 518331560 | Deep Black, LH Chasssis Reinforcement | 1 |
| 1 | 518329023 | RH Roller | 1 |
| 1 | 518329024 | LH Roller | 1 |
| 1 | 518331939 | Radiator Ass'y | 1 |
| 2 | 250100199 | Insert Half Hex Body M6 x 1.0 | 2 |
| 518332733 | Rear Tunnel 137 | ||
| 1 | 518328460 | RH Footrest | 1 |
| 3 | 293730047 | Black, Dart 8 mm | 3 |
| 2 | 293730060 | Black, Dart 10 mm | 2 |
| 1 | 293730052 | Black, Plug | 1 |
| 1 | 293150203 | Rivet Avibulb 3/16 | 1 |
| 6 | 293150096 | Hemlock Rivet, 6.5 mm | 6 |
| 1 | 293150119 | Hemlock Rivet, 6.5 mm | 1 |
| 4 | 293150174 | Hemlock Rivet, 6.4 mm | 4 |
| 8 | 293150147 | Hemlock Rivet | 8 |
| 4 | 293450275 | Insert | 4 |
| 2 | 234081410 | Flat Washer 8 mm | 2 |
| 8 | 250000779 | Torx Screw M6 X 1.0 X 18, Scotch Grip | 8 |
| 8 | 224061201 | Flat Washer | 8 |
| 2 | 250000942 | Hex Screw M8 X 30 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 1 | 518331753 | Engine Chassis Module Includes 100 to 100r | 1 |
| 1 | 518331257 | RH Member Ass'y | 1 |
| 1 | 505072690 | Leg Bushing | 1 |
| 1 | 518331254 | LH Member Ass'y | 1 |
| 3 | 293150148 | Rivet Magna-Grip 6,4 X 50,8 | 3 |
| 3 | 293150149 | Collar Huck Magna-Grip 6.4 | 3 |
| 1 | 518332716 | Bottom Plate | 1 |
| 6 | 293150203 | Rivet Avibulb 3/16 | 6 |
| 1 | 293450268 | Insert M5 X 0.8 | 1 |
| 8 | 293150203 | Rivet Avibulb 3/16 | 8 |
| 518329814 | RH Cross Link | ||
| 518330641 | LH Cross Link | ||
| 1 | 518330100 | Front Member | 1 |
| 4 | 250000945 | Hex. Flange Screw M6 X 25 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 2 | 293150203 | Rivet Avibulb 3/16 | 2 |
| 3 | 293150147 | Hemlock Rivet | 3 |
| 2 | 250000536 | Tork Screw M6 X 18 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 2 | 207662046 | Hex. Flange Screw M6 X 20 | 2 |
| 2 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 1 | 293450267 | Insert M5 - 0.8 | 1 |
| 4 | 207661646 | Hex. Flange Screw M6 X 16 | 4 |
| 1 | 518329493 | LH Junction Reinforcement | 1 |
| 1 | 518329494 | RH Junction Reinforcement | 1 |
| 1 | 207562056 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 518330166 | Brace Ass'y Includes 300 to 300a | 1 |
| 512061284 | Rubber Mount | ||
| 4 | 250001060 | Screw-Pan HD.Torx M8X30 | 4 |
| 1 | 518330637 | Chassis Suspension Module Includes 400 to 400a | 1 |
| XXXX | Not Available As Spare Part - S Module | ||
| 2 | 250001051 | Screw-Forming Hex.HD.FL. M6 X 16 | 2 |
| 1 | 233261416 | Elastic Flange Nut M6 X 1.0 | 1 |
| 6 | 207661636 | Hex. Flange Screw M6 X 16 | 6 |
| 2 | 293450278 | Insert | 2 |
| 2 | 518329480 | Member Fixation Plate | 2 |
| 4 | 293150203 | Rivet Avibulb 3/16 | 4 |
| 1 | 518330140 | Black, LH Member Includes 900 to 900a | 1 |
| 518330885 | RH Rear Diagonal Cross Member | ||
| 1 | 518331058 | RH Rear Diagonal Cross Member | 1 |
| 4 | 250000887 | Pan Head Torx Screw M8 X 12 | 4 |
| 1 | 518329499 | Brace Rear Member | 1 |
| 4 | 207661644 | Hex. Flange Screw M6 X 16 | 4 |
| 2 | 250300629 | Stud M5 X 20 | 2 |
| 2 | 518329974 | Upper Colomn Support | 2 |
| 1 | 207562034 | Hex. Flange Screw M6 X 20, Scotch Grip | 1 |
| 1 | 207662544 | Hex. Flange Screw M6 X 25 | 1 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 1 | 518331570 | Rear Bumper Includes 1300 to 1300a | 1 |
| 2 | 520001612 | Cap | 2 |
| 1 | 518329982 | Front Protector | 1 |
| 3 | 293150108 | Pop Rivet 3/16” | 3 |
| 1 | 518331019 | LH Footrest Ass'y Includes 3000 to 3000a1 | 1 |
| 2 | 390909100 | Avex Rivet | 2 |
| 1 | 518331020 | RH Footrest Ass'y Includes 3010 to 3010a1 | 1 |
| 2 | 518329838 | Support | 2 |
| 12 | 250000767 | Torx Truss Screw M6 X 12 | 12 |
