Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5718-538 | Panel, Side w/Decals - Right - Gray (See Decals Page For Decals) | ||
| 1 | 5718-612 | Panel, Side w/o Decals - Right - Gray (inc. 2-11 and 17-18) | 1 |
| 1 | 4621-813 | Decal, Warning - French | 1 |
| 8 | 1623-939 | Nut, U | 8 |
| 4 | 2623-166 | Screw, Self-Tapping | 4 |
| 1 | 7606-292 | Hook, Mounting - Right | 1 |
| 1 | 7606-293 | Hook, Mounting - Left | 1 |
| 1 | 0617-790 | Foam, Side Panel - Lower Rear - Right | 1 |
| 1 | 7606-644 | Foil, Protective - Lower - Right | 1 |
| 1 | 7606-646 | Foil, Protective - Upper - Right | 1 |
| 1 | 7606-650 | Foil, Protective - Mid - Right | 1 |
| 1 | 0617-792 | Foam, Side Panel - Mid - Right | 1 |
| 1 | 0617-788 | Foam, Side Panel - Lower Front - Right | 1 |
| 5718-539 | Panel, Side w/Decals - Left - Gray (See Decals Page For Decals) | ||
| 1 | 5718-779 | Panel, Side w/o Decals - Left - Gray (inc. 3-5 and 13-20) | 1 |
| 1 | 4621-812 | Decal, Warning - English | 1 |
| 1 | 0617-791 | Foam, Side Panel - Lower Rear - Left | 1 |
| 1 | 0617-789 | Foam, Side Panel - Lower Front - Left | 1 |
| 1 | 0617-793 | Foam, Side Panel - Middle - Left | 1 |
| 1 | 7606-640 | Vent, Upper Side Panel - Right | 1 |
| 1 | 7606-641 | Vent, Upper Side Panel - Left | 1 |
| 11 | 0123-987 | Clip, U | 11 |
| 1 | 7606-682 | Brace | 1 |
| 2 | 0617-797 | Tape | 2 |
| 1 | 5718-790 | Plate, Skid - Right - Black (inc. two No. 3, 22-25, 28, and 35-41) | 1 |
| 1 | 0617-776 | Foam, Skid Plate - Front - Right | 1 |
| 1 | 0617-794 | Foam, Skid Plate - Middle - Right | 1 |
| 1 | 3612-328 | Foil, Skid Plate - Right | 1 |
| 18 | 0123-802 | Washer | 18 |
| 1 | 3612-232 | Plate, Exhaust Outlet | 1 |
| 1 | 3612-231 | Seal, Exhaust Outlet | 1 |
| 1 | 3612-196 | Shield, Resonator | 1 |
| 1 | 2712-041 | Deflector, Exhaust Outlet | 1 |
| 4 | 8061-712 | Rivet | 4 |
| 1 | 5718-791 | Plate, Skid - Left - Black (inc. two No. 3 and 32-40) | 1 |
| 1 | 0617-765 | Foam, Skid Plate - Lower - Left | 1 |
| 1 | 0617-795 | Foam, Skid Plate - Middle - Left | 1 |
| 1 | 0617-761 | Foam, Skid Plate - Front - Left | 1 |
| 2 | 7606-265 | Knob, Hold-Down | 2 |
| 2 | 2623-005 | Clip, Retaining | 2 |
| 2 | 7606-296 | Plate, Backing | 2 |
| 2 | 2623-155 | Clip, Retaining | 2 |
| 2 | 2623-171 | Washer | 2 |
| 2 | 2623-211 | Screw, Self-Tapping | 2 |
| 28 | 8061-708 | Rivet | 28 |
| 1 | 2712-099 | Shield, Heat Barrier w/Grommets | 1 |
| 1 | 6606-940 | Shield, Heat - ECM | 1 |
| 2 | 8408-620 | Screw, Cap | 2 |
| 1 | 0730-249 | ECM (PLEASE INCLUDE VIN WHEN ORDERING) | 1 |
| 2 | 0423-031 | Clip, U-Nut | 2 |
| 1 | 7606-654 | Bumper, Protector | 1 |
| 1 | 7606-621 | Brace | 1 |
| 2 | 2623-164 | Screw, Self-Tapping | 2 |
| 1 | 2712-103 | Deflector, Exhaust | 1 |
| 6 | 8061-710 | Rivet | 6 |
