Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 23211-425-000 | MAINSHAFT, TRANSMISSION (15T) | ||
| 23220-425-000 | COUNTERSHAFT, TRANSMISSION (34T) Use up to Engine SN 3001070 | ||
| 23220-425-010 | COUNTERSHAFT, TRANSMISSION (34T) | ||
| 23220-425-010 | COUNTERSHAFT, TRANSMISSION (34T) Use up to Engine SN 3001070 | ||
| 23220-425-020 | COUNTERSHAFT, TRANSMISSION (34T) Use up to Engine SN 3001070 | ||
| 23411-425-000 | GEAR, COUNTERSHAFT LOW (38T) | ||
| 23422-425-000 | BUSH, COUNTERSHAFT LOW GEAR | ||
| 23431-425-000 | GEAR, MAINSHAFT SECOND (19T) | ||
| 23451-425-000 | GEAR, MAINSHAFT THIRD (23T) | ||
| 23451-425-010 | GEAR, MAINSHAFT THIRD (23T) | ||
| 23451-MC3-630 | GEAR, MAINSHAFT THIRD (23T) | ||
| 23451-438-010 | GEAR, MAINSHAFT THIRD (23T) | ||
| 23461-425-000 | GEAR, COUNTERSHAFT THIRD (32T) | ||
| 23461-425-010 | GEAR, COUNTERSHAFT THIRD (32T) | ||
| 23471-425-000 | GEAR, MAINSHAFT FOURTH (25T) | ||
| 23471-425-010 | GEAR, MAINSHAFT FOURTH (25T) | ||
| 23471-425-020 | GEAR, MAINSHAFT FOURTH (25T) | ||
| 23471-425-030 | GEAR, MAINSHAFT FOURTH (25T) | ||
| 23481-425-000 | GEAR, COUNTERSHAFT FOURTH (29T) | ||
| 23481-438-000 | GEAR, COUNTERSHAFT FOURTH (29T) | ||
| 23491-425-000 | GEAR, MAINSHAFT FIFTH (28T) | ||
| 23491-461-000 | GEAR, MAINSHAFT FIFTH (28T) | ||
| 23491-MC3-630 | GEAR, MAINSHAFT FIFTH (28T) | ||
| 23491-425-010 | GEAR, MAINSHAFT FIFTH (28T) | ||
| 23495-422-000 | COLLAR, SPLINE (28X17) | ||
| 23501-MC3-630 | GEAR, COUNTERSHAFT FIFTH (27T) | ||
| 23501-425-000 | GEAR, COUNTERSHAFT FIFTH (27T) | ||
| 23801-425-670 | SPROCKET, DRIVE (15T) | ||
| 1 | 24261-283-000 | PIN, GEARSHIFT FORK GUIDE | 1 |
| 1 | 90037-422-000 | BOLT, SPECIAL (10MM) | 1 |
| 1 | 90037-422-003 | BOLT, SPECIAL (10MM) | 1 |
| 3 | 90451-422-000 | WASHER, THRUST (28MM) | 3 |
| 90453-704-000 | WASHER (22MM) Use up to Engine SN 3005825 | ||
| 90453-426-000 | WASHER, THRUST (22.5MM) Use from Engine SN 3005826 | ||
| 90457-425-000 | WASHER, THRUST | ||
| 90457-703-000 | WASHER (27MM) | ||
| 90459-422-000 | WASHER (10.2MM) Use up to Engine SN 3007624 | ||
| 1 | 90459-438-000 | WASHER (10.2MM) Use from Engine SN 3007625 | 1 |
| 3 | 90601-422-000 | CIRCLIP (OUTER) (28MM) | 3 |
| 91004-MG5-671 | BEARING, RADIAL BALL (6305) | ||
| 1 | 91004-657-003 | BEARING, BALL (6305) (NACHI) | 1 |
| 1 | 91004-657-008 | BEARING, BALL (6305) (NACHI) | 1 |
| 91004-689-000 | BEARING, BALL (6305) | ||
| 91005-425-003 | BEARING, RADIAL BALL (63/22U) | ||
| 91022-425-008 | BEARING, NEEDLE (22MM) Use up to Engine SN 3006370 | ||
| 91022-438-008 | BEARING, NEEDLE (22MM) Use from Engine SN 3006371 | ||
| 1 | 91205-425-003 | OIL SEAL (40X62X13) | 1 |
| 1 | 91305-422-000 | O-RING (9.8X2.4) | 1 |
| 1 | 91352-425-003 | O-RING (9.8X7.4) | 1 |
| 1 | 91352-526-000 | O-RING (9.8X2.4) | 1 |
| 95015-26200 | SET-RING (62MM) | ||
| 90602-428-000 | SET-RING (62MM) |
