Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 45501-16G30-YAY | COVER, SEAT TAIL, R (BLACK) | ||
| 45501-16G30-YD8 | COVER, SEAT TAIL, R (SILVER) | ||
| 45501-16G30-YU7 | COVER, SEAT TAIL, R (RED) Includes Item(s) 2 - 5 | ||
| 68161-16G20-BRS | EMBLEM, SEAT TAIL COVER FOR YAY | ||
| 68161-16G20-BRW | EMBLEM, SEAT TAIL COVER FOR YD8 | ||
| 68161-16G20-BRU | EMBLEM, SEAT TAIL COVER FOR YU7 | ||
| 1 | 45516-42F00 | TAPE, SEAT TAIL COVER FR | 1 |
| 45517-16G10 | TAPE, SEAT TAIL COVER FR NO.2 | ||
| 1 | 47161-10D00 | TAPE, SEAT TAIL COVER FR NO.3 | 1 |
| 45502-16G30-YAY | COVER, SEAT TAIL, L (BLACK) | ||
| 45502-16G30-YD8 | COVER, SEAT TAIL, L (SILVER) | ||
| 45502-16G30-YU7 | COVER, SEAT TAIL, L (RED) Includes Item(s) 7 - 10 | ||
| 4 | 09136-06082 | SCREW | 4 |
| 2 | 09180-06286 | SPACER FR | 2 |
| 2 | 09180-06286 | SPACER CTR | 2 |
| 2 | 09320-10052 | CUSHION FR | 2 |
| 2 | 47115-16G00 | CUSHION,SEAT TAIL COVER CTR CTR | 2 |
| 2 | 09320-20010 | CUSHION (20X32X9) RR | 2 |
| 1 | 03241-15123 | SCREW | 1 |
| 1 | 09148-05038 | NUT | 1 |
| 1 | 45503-16G00-YAY | COVER, SEAT TAIL CENTER (BLACK FOR YAY | 1 |
| 45503-16G00-YMX | COVER, SEAT TAIL CENTER (SILVER) FOR YD8 | ||
| 45503-16G00-YU7 | COVER, SEAT TAIL CENTER (RED) FOR YU7; Includes Item(s) 20 - 23 | ||
| 1 | 68161-16G00-YD8 | .EMBLEM,"SUZUKI" (SILVER) FOR Y7H,YU7 | 1 |
| 68161-16G00-17U | EMBLEM, "SUZUKI" FOR YD8 | ||
| 1 | 45518-16G00 | CUSHION,SEAT TAIL COVER CTR | 1 |
| 2 | 45517-16G00 | TAPE, SEAT TAIL COVER | 2 |
| 2 | 45516-42F00 | TAPE | 2 |
| 1 | 45514-16G00-YAY | COVER, SEAT TAIL, REAR (BLACK) | 1 |
| 45514-16G00-YD8 | COVER, SEAT TAIL, REAR (SILVER) | ||
| 45514-16G00-YU7 | COVER, SEAT TAIL, REAR (RED) | ||
| 3 | 45519-16G00 | CUSHION, SEAT TAIL COVER RR | 3 |
| 4 | 09148-06018 | NUT | 4 |
| 9 | 09409-06314-5PK | CLIP | 9 |
| 46211-16G00-YAY | HANDLE, PILLION RIDER (BLACK) | ||
| 46211-16G00-YD8 | HANDLE, PILLION RIDER (SILVER) | ||
| 1 | 46211-16G00-YU7 | HANDLE, PILLION RIDER (RED) | 1 |
| 2 | 01551-08403 | BOLT | 2 |
| 2 | 09160-08501 | WASHER | 2 |
| 2 | 09180-06271 | SPACER | 2 |
| 2 | 09139-06112 | SCREW | 2 |
