Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 278000849 | Speed Sensor Includes 3 - 7. | ||
| 3 | 278000222 | Male Terminal | 3 |
| 3 | 278000218 | Wire Seal | 3 |
| 1 | 293710031 | ELECTRIC CONNECTION | 1 |
| 295500108 | Paddle Wheel Kit | ||
| 208551060 | PHILLIPS SCREW M5 X 10 | ||
| 1 | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 204470220 | Bilge Pump | 1 |
| 2 | 293150029 | RIVET_POP 5/32 | 2 |
| 204050304 | Bilge Pump Support | ||
| 2 | 293150011 | Pop Rivet 3/16" | 2 |
| 278001398 | ELECTRONIC MODULE ASS'Y Includes 16 - 19. | ||
| 1 | 278001069 | Fuse Holder Cover | 1 |
| 278001070 | Cover Seal | ||
| 1 | 278000343 | Fuse, 15 Amperes | 1 |
| 2 | 278000704 | FUSE, 7.5 AMPERES | 2 |
| 2 | 278000344 | Fuse, 5 Amperes | 2 |
| 278001196 | FUSE, 3 AMPERES | ||
| 1 | 219704365 | Was 293200017 Neoprene Seal | 1 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 2 | 232561600 | Hex. Elastic Stop Nut M6 | 2 |
| 1 | 293550015 | Deoxit Lubricant, Spray | 1 |
| 278000978 | Buzzer Ass'y Includes 24 - 27. | ||
| 2 | 278000223 | Female Terminal | 2 |
| 2 | 278000218 | Wire Seal | 2 |
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 278000977 | Safety Switch Includes 28 - 32. | ||
| 1 | 278000216 | Wire Seal | 1 |
| 278000890 | FEMALE CONNECTOR, 4 CIRCUITS | ||
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 278001277 | Safety Landyard Ass'y | 1 |
| 204620176 | LCD Info Gauge Includes 35 - 50. | ||
| 278000219 | MALE HOUSING, 1 CIRCUIT | ||
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 1 | 278000891 | MALE CONNECTOR, 4 CIRCUITS | 1 |
| 7 | 278000223 | Female Terminal | 7 |
| 2 | 278000217 | Female Housing, 2 Circuits | 2 |
| 7 | 278000222 | Male Terminal | 7 |
| 14 | 278001065 | Wire Seal | 14 |
| 278000993 | Male Connector, 26 Circuits Includes 45 - 46. | ||
| 1 | 278001307 | WIRE SEAL | 1 |
| 3 | 278000994 | FEMALE TERMINAL | 3 |
| 278000995 | FEMALE TERMINAL | ||
| 278000996 | WIRE SEAL | ||
| 10 | 293000070 | SEALING CAP | 10 |
| 293720047 | Gauge Support | ||
| 278001359 | Speedometer Includes 52 - 57. | ||
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 5 | 278000222 | Male Terminal | 5 |
| 5 | 278001065 | Wire Seal | 5 |
| 278001243 | Compass Includes 58 - 63. | ||
| 6 | 278000223 | Female Terminal | 6 |
| 6 | 278000218 | Wire Seal | 6 |
| 2 | 293730016 | Dart, Black | 2 |
| 278000851 | Temperature Sensor Includes 64 - 67. | ||
| 1 | 234000600 | Flat Washer 10 mm, Stainless | 1 |
| 1 | 250100004 | NUT-HEX.PLASTIC M10 X 1.5 | 1 |
| 1 | 278001016 | Temperature Sensor | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 1 | 270600005 | Solenoid Valve | 1 |
| 2 | 234051600 | Flat Washer M5, Stainless | 2 |
| 2 | 232551600 | Hex. Elastic Nut M5 | 2 |
| 278001402 | Oil Sensor Includes 75 - 79. | ||
| 2 | 278000222 | Male Terminal | 2 |
| 1 | 293720008 | Grommet | 1 |
