Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11364-425-000 | RUBBER, L. SIDE COVER MOUNTING | ||
| 11375-461-010 | COVER, FINAL GEAR CASE | ||
| 11376-461-000 | O-RING, FINAL GEAR CASE COVER | ||
| 11377-461-000 | PROTECTOR, FINAL GEAR CASE COVER | ||
| 11378-461-000 | PLATE, PROTECTOR SETTING | ||
| 11379-461-000 | PLATE A, OIL PASSAGE | ||
| 23510-461-305 | GEAR SET, REDUCTION Use up to Engine SN 2112944 | ||
| 23510-461-305 | GEAR SET, REDUCTION GEAR, REDUCTION DRIVE (47T) Use up to Engine SN 2112944 | ||
| 23511-461-000 | GEAR, REDUCTION DRIVE (47T) Use up to Engine SN 2112944 | ||
| 23511-461-010 | GEAR, REDUCTION DRIVE (47T) Use from Engine SN 2112945 | ||
| 23511-461-000 | GEAR, REDUCTION DRIVE (47T) GEAR, REDUCTION SUB-DRIVE Use up to Engine SN 2112944 | ||
| 23512-461-000 | GEAR, REDUCTION SUB-DRIVE (43T) Use up to Engine SN 2112944 | ||
| 23512-461-010 | GEAR, REDUCTION SUB-DRIVE (43T) Use from Engine SN 2112945 | ||
| 23514-461-000 | COLLAR, SPLINE (48MM) | ||
| 23515-461-000 | COLLAR, SPLINE (28X14.1) | ||
| 23516-461-000 | SHAFT, SHIFT FORK | ||
| 23512-461-000 | GEAR, REDUCTION SUB-DRIVE (43T) SHIFTER, REDUCTION GEAR Use up to Engine SN 2112944 | ||
| 24271-461-000 | SHIFTER, REDUCTION GEAR Use up to Engine SN 2112944 | ||
| 24271-461-010 | SHIFTER, REDUCTION GEAR Use from Engine SN 2112945 | ||
| 24435-461-000 | SPRING, SHIFT DRUM STOPPER | ||
| 24438-461-000 | STOPPER, GEARSHIFT DRUM | ||
| 24615-461-000 | SPINDLE, GEARSHIFT | ||
| 25100-461-003 | PUMP ASSY., OIL | ||
| 31105-003-000 | WASHER, ROTOR SETTING | ||
| 1 | 90023-041-000 | BOLT, GEARSHIFT DRUM STOPPER ARM PIVOT | 1 |
| 1 | 90023-041-010 | BOLT, GEARSHIFT DRUM STOPPER ARM PIVOT | 1 |
| 90063-461-000 | BOLT, FLANGE (8X52) | ||
| 90064-461-000 | BOLT, FLANGE (8X82) | ||
| 90065-461-000 | BOLT, FLANGE (8X90) | ||
| 90067-461-000 | BOLT, SPECIAL (8MM) | ||
| 1 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 90451-461-000 | WASHER, THRUST (28MM) | ||
| 90468-461-000 | WASHER, STOPPER (28MM) | ||
| 90469-461-000 | WASHER (36MM) | ||
| 1 | 90471-580-000 | WASHER (8MM) | 1 |
| 90472-461-000 | CAP, OIL | ||
| 90473-461-000 | BOLT, FLANGE (12X15) | ||
| 90706-461-000 | PIN, DOWEL (10X46) | ||
| 91013-461-000 | BEARING, RADIAL BALL (6205) | ||
| 1 | 91203-436-003 | OIL SEAL (12X24X5) (ARAI) | 1 |
| 1 | 91203-436-004 | OIL SEAL (12X24X5) (NOK) | 1 |
| 1 | 91370-461-000 | O-RING (11.9X2.2) | 1 |
| 1 | 93500-06006 | SCREW, PAN (6X6) | 1 |
| 1 | 93500-06006-0A | SCREW, PAN (6X6) | 1 |
| 3 | 93500-06010 | SCREW, PAN (6X10) | 3 |
| 1 | 94109-12000 | WASHER, DRAIN PLUG (12MM) | 1 |
| 1 | 94510-36000 | CIRCLIP (OUTER) (36MM) | 1 |
| 1 | 94520-38000 | CIRCLIP (INNER) (38MM) | 1 |
| 1 | 95700-06050-00 | BOLT, FLANGE (6X50) | 1 |
| 1 | 95701-06050-00 | BOLT, FLANGE (6X50) | 1 |
| 1 | 96100-62040-00 | BEARING, RADIAL BALL (6204) | 1 |
