Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 17507-MN5-000 | RUBBER, ENGINE SIDE COVER | ||
| 1 | 30401-GB6-000 | CUSHION, IGNITION CONTROL MODULE (CDI) | 1 |
| 35160-MN5-003 | SENSOR ASSY., STOP | ||
| 2 | 35162-MN5-003 | COLLAR | 2 |
| 2 | 35163-MN5-003 | GROMMET | 2 |
| 35880-MN5-000 | REGULATOR, STARTER MAGNETIC | ||
| 36100-MN5-000 | RELAY, FUEL CUT | ||
| 2 | 38301-KK9-952 | RELAY, TURN SIGNAL (MITSUBA) | 2 |
| 2 | 38301-MBW-D21 | RELAY, TURN SIGNAL (DENSO) | 2 |
| 2 | 38301-MG9-672 | FLASHER, COMBINATION (DENSO) | 2 |
| 2 | 38301-MG9-681 | RELAY, TURN SIGNAL (MITSUBA) | 2 |
| 2 | 38306-MF5-770 | SUSPENSION, TURN SIGNAL RELAY | 2 |
| 2 | 38306-GE7-000 | SUSPENSION, TURN SIGNAL RELAY | 2 |
| 50710-MN5-000 | HOLDER ASSY., HELMET | ||
| 50712-MN5-000 | KNOB, HELMET HOLDER | ||
| 2 | 50713-MN5-000 | ROD, HELMET HOLDER | 2 |
| 62501-MN5-000 | GUARD, R. ENGINE | ||
| 62601-MN5-000 | GUARD, L. ENGINE | ||
| 4 | 83124-MN5-000 | RUBBER, ENGINE SIDE COVER | 4 |
| 83511-MN5-000ZA | COVER, R. (UPPER) (YR149M) (TYPE1) | ||
| 83511-MN5-000ZB | COVER, R. (UPPER) (MRCR2) (TYPE2) | ||
| 83511-MN5-000ZC | COVER, R. (UPPER) (B127M) (TYPE3) COVER, R. (UPPER) (NH276M) | ||
| 83512-MN5-000ZC | COVER, R. (LOWER) (YR150M) (TYPE3) | ||
| 83512-MN5-000ZD | COVER, R. (LOWER) (R163M) (TYPE4) | ||
| 83512-MN5-000ZE | COVER, R. (LOWER) (B128M) (TYPE5) COVER, R. (LOWER) (NH276M) | ||
| 83513-MAM-300 | MAT, R. ENGINE SIDE COVER (UPPER) | ||
| 83513-MN5-300 | MAT, R. ENGINE SIDE COVER (UPPER) | ||
| 83514-MAM-300 | MAT, R. ENGINE SIDE COVER (LOWER) | ||
| 83514-MN5-300 | MAT, R. ENGINE SIDE COVER (LOWER) | ||
| 2 | 83515-MN5-300 | SEAL, ENGINE SIDE COVER | 2 |
| 83520-MN5-000ZD | COVER ASSY., R. ENGINE SIDE (YR149M/YR150M) (TYPE1/3) | ||
| 83520-MN5-000ZE | COVER ASSY., R. ENGINE SIDE (MRCR2/R163M) (TYPE2/4) | ||
| 83520-MN5-000ZF | COVER ASSY., R. ENGINE SIDE (B127M/B128M) (TYPE5/3) | ||
| 4 | 83551-300-000 | GROMMET, AIR CLEANER HOUSING | 4 |
| 83561-MN5-000ZA | COVER, L. (UPPER) (YR149M) (TYPE1) | ||
| 83561-MN5-000ZB | COVER, L. (UPPER) (MRCR2) (TYPE2) | ||
| 83561-MN5-000ZC | COVER, L. (UPPER) (B127M) (TYPE3) COVER, L. (UPPER) (NH276M) | ||
| 83562-MN5-000ZC | COVER, L. (LOWER) (YR150M) (TYPE3) | ||
| 83562-MN5-000ZD | COVER, L. (LOWER) (R163M) (TYPE4) | ||
| 83562-MN5-000ZE | COVER, L. (LOWER) (B128M) (TYPE5) COVER, L. (LOWER) (NH276M) | ||
| 83563-MAM-300 | MAT, L. ENGINE SIDE COVER (UPPER) | ||
| 83563-MN5-300 | MAT, L. ENGINE SIDE COVER (UPPER) | ||
| 83564-MAM-300 | MAT, L. ENGINE SIDE COVER (LOWER) | ||
| 83564-MN5-300 | MAT, L. ENGINE SIDE COVER (LOWER) | ||
| 83570-MN5-000ZD | COVER ASSY., L. ENGINE SIDE (YR149M/YR150M) (TYPE1/3) | ||
| 83570-MN5-000ZE | COVER ASSY., L. ENGINE SIDE (MRCR2/R163M) (TYPE4/2) | ||
| 83570-MN5-000ZF | COVER ASSY., L. ENGINE SIDE (B127M/B128M) (TYPE5/3) | ||
| 3 | 83618-323-000 | RUBBER, BATTERY BOX | 3 |
| 1 | 84100-MN5-000 | STAY, SADDLEBAG | 1 |
| 1 | 84100-MN5-610 | STAY, SADDLEBAG | 1 |
| 84102-MN5-000 | JOINT, RR. FRAME END | ||
| 84103-MN5-000 | CUSHION, RR. TRUNK | ||
| 84130-MN5-000 | GUIDE, R. SADDLEBAG | ||
| 84140-MN5-000 | GUIDE, L. SADDLEBAG | ||
| 2 | 93500-04020-0H | SCREW, PAN (4X20) | 2 |
| 2 | 93893-06012-07 | SCREW-WASHER (6X12) | 2 |
| 4 | 93903-25280 | SCREW, TAPPING (5X12) | 4 |
| 2 | 95701-06010-08 | BOLT, FLANGE (6X10) | 2 |
| 1 | 95701-06012-08 | BOLT, FLANGE (6X12) | 1 |
| 2 | 95701-08016-00 | BOLT, FLANGE (8X16) Use up to Frame SN KA100662 | 2 |
| 2 | 95701-08016-08 | BOLT, FLANGE (8X16) Use from Frame SN KA100663 | 2 |
| 5 | 95701-08016-08 | BOLT, FLANGE (8X16) | 5 |
| 2 | 95701-08020-08 | BOLT, FLANGE (8X20) | 2 |
| 2 | 95701-10025-08 | BOLT, FLANGE (10X25) | 2 |
