Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 17925-MG9-950 | GUIDE, THROTTLE CABLE | ||
| 30400-MG9-950 | UNIT ASSY., R. SPARK | ||
| 30401-MG9-950 | UNIT ASSY., L. SPARK | ||
| 30501-MG9-950 | STAY A, IGNITION COIL | ||
| 30502-MG9-950 | STAY B, IGNITION COIL | ||
| 2 | 30510-MA6-013 | COIL, IGNITION | 2 |
| 4 | 30700-KR3-670 | CAP ASSY., NOISE SUPPRESSOR | 4 |
| 4 | 30700-MB9-153 | CAP ASSY., NOISE SUPPRESSOR | 4 |
| 30705-MG9-770 | SEAL, R. SUPPRESSOR | ||
| 30706-MG9-770 | SEAL, L. SUPPRESSOR | ||
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (1-1) | 1 |
| 1 | 30750-MG9-405 | WIRE, IGNITION | 1 |
| 1 | 30751-MG9-000 | WIRE SET, IGNITION (1-1) | 1 |
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (2-2) | 1 |
| 1 | 30752-MG9-000 | WIRE SET, IGNITION (2-2) | 1 |
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (3-3) | 1 |
| 1 | 30753-MG9-000 | WIRE SET, IGNITION (3-3) | 1 |
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (4-4) | 1 |
| 1 | 30754-MG9-000 | WIRE SET, IGNITION (4-4) | 1 |
| 31610-MG9-950 | FILTER KIT, RADIO NOISE (Optional). | ||
| 31612-ML8-750 | HOLDER, CONNECTOR (8P) (Optional). | ||
| 31620-ML8-750 | FILTER, REGULATE RECTIFIER (Optional). | ||
| 31630-ML8-770 | FILTER, LINE (Optional). | ||
| 35160-MG9-950 | SENSOR ASSY., STOP | ||
| 35165-MG9-950 | STAY, SENSOR | ||
| 35228-MG9-680 | STAY, CANCEL UNIT | ||
| 36010-PA6-004 | JOINT, THREE WAY | ||
| 36034-PD1-000 | PLUG, SEALING | ||
| 1 | 36101-MB1-000 | SUSPENSION, FUEL CUT RELAY | 1 |
| 1 | 36171-MG9-951 | SENSOR, R. PRESSURE BOOST | 1 |
| 1 | 36172-MG9-951 | SENSOR, L. PRESSURE BOOST | 1 |
| 37640-MB1-701 | CHECK UNIT, PILOT LAMP | ||
| 2 | 38301-MG9-672 | FLASHER, COMBINATION (DENSO) | 2 |
| 38305-MG9-950 | STAY, TURN SIGNAL RELAY | ||
| 38306-GE8-008 | SUSPENSION, TURN SIGNAL RELAY (DENSO) | ||
| 38306-ME9-771 | SUSPENSION, TURN SIGNAL RELAY | ||
| 38506-MG9-951 | SUSPENSION, MAIN RELAY | ||
| 38506-MG9-952 | SUSPENSION, MAIN RELAY | ||
| 1 | 38501-GAM-007 | RELAY, STARTER (MATSUSHITA) | 1 |
| 1 | 38501-GN2-003 | RELAY, STARTER | 1 |
| 1 | 38520-MG9-951 | RELAY, MAIN | 1 |
| 38601-MB3-671 | RELAY, POSITION | ||
| 50210-MG9-950 | HOLDER A, CONNECTOR | ||
| 50212-MG9-950 | HOLDER, CONNECTOR (C) | ||
| 50230-MG9-950 | HOLDER, RELAY | ||
| 90105-MG9-871 | NUT, FLANGE CAP (5MM) (Optional). | ||
| 90105-460-000 | BOLT, SOCKET (6X12) | ||
| 2 | 92300-04020-0A | BOLT, RECESSED (4X20) | 2 |
| 2 | 92301-04018-0A | BOLT, RECESSED (4X18) | 2 |
| 4 | 93500-05012-0G | SCREW, PAN (5X12) | 4 |
| 2 | 93892-06012-08 | SCREW-WASHER (6X12) | 2 |
| 93892-06028-08 | SCREW-WASHER (6X28) | ||
| 4 | 93901-22320 | SCREW, TAPPING (3X12) (Optional). | 4 |
| 2 | 94101-04000 | WASHER, PLAIN (4MM) | 2 |
| 1 | 94101-05700 | WASHER, PLAIN (5MM) (Optional). | 1 |
| 2 | 94101-06800 | WASHER, PLAIN (6MM) | 2 |
| 2 | 95005-35001-20M | BULK HOSE, VACUUM (3.5X1000) (3.5X50) | 2 |
| 2 | 95005-35001-20M | BULK HOSE, VACUUM (3.5X1000) (3.5X75) | 2 |
| 2 | 95005-35001-20M | BULK HOSE, VACUUM (3.5X1000) (3.5X100) | 2 |
| 1 | 95005-35001-20M | BULK HOSE, VACUUM (3.5X1000) (3.5X360) | 1 |
| 1 | 95700-06010-07 | BOLT, FLANGE (6X10) | 1 |
| 1 | 95701-06010-07 | BOLT, FLANGE (6X10) | 1 |
| 2 | 95700-06012-08 | BOLT, FLANGE (6X12) | 2 |
| 2 | 95701-06012-08 | BOLT, FLANGE (6X12) | 2 |
| 2 | 95700-06016-00 | BOLT, FLANGE (6X16) | 2 |
| 2 | 95701-06016-00 | BOLT, FLANGE (6X16) | 2 |
| 1 | 95700-08028-08 | BOLT, FLANGE (8X28) | 1 |
| 1 | 95701-08028-08 | BOLT, FLANGE (8X28) | 1 |
