Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 16111-MC7-000 | O-RING, INJECTOR | ||
| 16111-MC7-004 | O-RING, INJECTOR (7.8X1.7) | ||
| 16112-MG9-950 | RING, CUSHION | ||
| 16115-MG9-950 | SHIM A, INJECTOR | ||
| 16116-MG9-950 | SHIM B, INJECTOR | ||
| 16117-MG9-950 | SHIM C, INJECTOR | ||
| 16118-MG9-950 | SHIM D, INJECTOR | ||
| 16120-MG9-951 | INJECTOR ASSY., FUEL (A. NON PAINT) | ||
| 16130-MG9-951 | INJECTOR ASSY., FUEL (B. BLUE PAINT) | ||
| 16161-MG9-950 | EMBLEM, THROTTLE LINK COVER | ||
| 4 | 16219-MB0-770 | BAND, INSULATOR | 4 |
| 4 | 16223-KS5-000 | BAND, INSULATOR | 4 |
| 16221-MG9-950 | COVER, INJECTOR | ||
| 16222-MG9-950 | RING, INJECTOR SEAL | ||
| 16223-MG9-950 | COVER, R. INJECTOR CAP | ||
| 16224-MG9-950 | COVER, L. INJECTOR CAP | ||
| 16310-MG9-950 | PIPE ASSY., FUEL | ||
| 16314-MG9-950 | PIPE, FUEL | ||
| 16315-MG9-950 | CAP A, INJECTOR | ||
| 16316-MG9-950 | CAP A/B, INJECTOR | ||
| 16320-MG9-950 | PIPE ASSY., L. FUEL DELIVERY | ||
| 16340-MG9-950 | COVER, R. THROTTLE LINK | ||
| 16345-MG9-950 | BRACKET, R. THROTTLE LINK | ||
| 16350-MG9-950 | COVER, L. THROTTLE LINK | ||
| 16355-MG9-950 | BRACKET, L. THROTTLE LINK | ||
| 16850-MG9-951 | REGULATOR ASSY., PRESSURE | ||
| 16852-MG9-951 | CAP, PRESSURE REGULATOR | ||
| 17130-MG9-000 | PIPE, AIR FEED (A) | ||
| 17140-MG9-000 | PIPE, AIR FEED (B) | ||
| 17150-MG9-000 | HOSE, AIR FEED | ||
| 17151-MG9-000 | RUBBER, AIR PIPE SETTING | ||
| 17180-MG9-950 | HOLDER A, INJECTOR | ||
| 17180-MG9-951 | HOLDER A, INJECTOR | ||
| 17190-MG9-950 | HOLDER B, INJECTOR | ||
| 17190-MG9-951 | HOLDER B, INJECTOR | ||
| 17810-MG9-951 | VALVE, AIR (TWO-WAY) | ||
| 17811-MG9-950 | COVER, AIR VALVE | ||
| 17815-MG9-950 | STAY, AIR VALVE | ||
| 1 | 19509-GE2-003 | CLAMP, TUBE (D19) | 1 |
| 19521-MG9-950 | HOSE, WATER (A) | ||
| 19522-MG9-950 | HOSE, WATER (B) | ||
| 19523-MG9-950 | HOSE, WATER (C) | ||
| 19525-MG9-950 | JOINT, WATER HOSE | ||
| 8 | 53729-671-003 | CLAMP D (15.5MM) | 8 |
| 90004-MG9-950 | BOLT, FLANGE (6X25) | ||
| 90031-MG9-950 | BOLT, STUD (12X34) | ||
| 2 | 90201-PD1-000 | NUT A, SEALING (12MM) | 2 |
| 4 | 90428-PD1-003 | WASHER, SEALING (12MM) | 4 |
| 4 | 90428-PD6-003 | WASHER, SEALING (12MM) | 4 |
| 1 | 90461-357-000 | WASHER, SEALING (12MM) | 1 |
| 12 | 91103-429-000 | PIN, DOWEL (8X10) | 12 |
| 91301-MG9-951 | O-RING | ||
| 4 | 91304-MG9-951 | O-RING (13.8X2.9) (ARAI) | 4 |
| 4 | 91304-MG9-952 | O-RING (13.8X2.9) | 4 |
| 4 | 91305-422-000 | O-RING (9.8X2.4) | 4 |
| 4 | 91352-425-003 | O-RING (9.8X7.4) | 4 |
| 91401-MG9-000 | HOSE, FUEL (5.3X110) | ||
| 4 | 93500-05020-0G | SCREW, PAN (5X20) | 4 |
| 2 | 94050-06000 | NUT, FLANGE (6MM) | 2 |
| 4 | 95001-35003-60M | BULK HOSE, FUEL (3.5X3000) (3.5X25) | 4 |
| 8 | 95002-41250-08 | CLAMP, TUBE (D12.5) | 8 |
| 1 | 95700-06010-00 | BOLT, FLANGE (6X10) | 1 |
| 1 | 95701-06010-00 | BOLT, FLANGE (6X10) | 1 |
| 2 | 95700-06014 | BOLT, FLANGE (6X14) | 2 |
| 2 | 95700-06014-00 | BOLT, FLANGE (6X14) | 2 |
| 2 | 95701-06014-00 | BOLT, FLANGE (6X14) | 2 |
| 2 | 95700-06016 | BOLT, FLANGE (6X16) | 2 |
| 2 | 95700-06016-00 | BOLT, FLANGE (6X16) | 2 |
| 2 | 95701-06016-00 | BOLT, FLANGE (6X16) | 2 |
| 4 | 96000-06010-02 | BOLT, FLANGE (6X10) | 4 |
| 4 | 96001-06010-02 | BOLT, FLANGE (6X10) | 4 |
| 2 | 96000-06016-02 | BOLT, FLANGE (6X16) | 2 |
| 2 | 96001-06016-02 | BOLT, FLANGE (6X16) | 2 |
| 8 | 96000-06025-02 | BOLT, FLANGE (6X25) | 8 |
| 8 | 96001-06025-02 | BOLT, FLANGE (6X25) | 8 |
| 6 | 96000-06035-02 | BOLT, FLANGE (6X35) | 6 |
| 6 | 96001-06035-02 | BOLT, FLANGE (6X35) | 6 |
