Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 16010-HM5-730 | GASKET SET | 1 |
| 1 | 16010-HM7-700 | GASKET SET | 1 |
| 16012-HM5-730 | NEEDLE SET, JET | ||
| 1 | 16013-KR3-980 | FLOAT SET | 1 |
| 16015-HM5-730 | CHAMBER SET, FLOAT | ||
| 16016-HM5-730 | SCREW SET | ||
| 1 | 16028-HM5-730 | SCREW SET | 1 |
| 1 | 16037-HM5-L00 | PLATE SET, VALVE | 1 |
| 1 | 16037-KM3-751 | PLATE SET, VALVE | 1 |
| 1 | 16046-HM5-730 | VALVE SET, STARTER | 1 |
| 1 | 16048-HC4-013 | PUMP SET | 1 |
| 1 | 16048-HM7-700 | PUMP SET | 1 |
| 1 | 16048-HN7-003 | PUMP SET | 1 |
| 1 | 16050-HC4-003 | SPRING, COMPRESSION COIL | 1 |
| 1 | 16050-HM5-L00 | SPRING, COMPRESSION COIL | 1 |
| 1 | 16080-HC0-003 | SCREW-WASHER | 1 |
| 1 | 16100-HM5-L01 | CARBURETOR ASSY. (VE91D A) | 1 |
| 1 | 16100-HM5-850 | CARBURETOR ASSY. (VE91C A) | 1 |
| 16107-KM3-702 | TOP | ||
| 16111-HC4-003 | PISTON, VACUUM | ||
| 1 | 16155-397-971 | VALVE, FLOAT | 1 |
| 1 | 16157-HC4-003 | COVER, BODY | 1 |
| 1 | 16157-HN8-003 | COVER, BODY | 1 |
| 1 | 16165-HC4-840 | HOLDER, NEEDLE JET | 1 |
| 1 | 16165-HN5-B01 | HOLDER, NEEDLE JET | 1 |
| 1 | 16168-HC4-003 | HOLDER, JET | 1 |
| 1 | 16180-HC4-003 | VALVE, ONE-WAY | 1 |
| 16199-HM5-850 | TUBE | ||
| 4 | 93500-04008-0H | SCREW, PAN (4X8) | 4 |
| 4 | 93500-04008-1H | SCREW, PAN (4X8) | 4 |
| 4 | 93500-04014-0H | SCREW, PAN (4X14) | 4 |
| 4 | 93500-04014-1H | SCREW, PAN (4X14) | 4 |
| 2 | 93892-04012-08 | SCREW-WASHER (4X12) | 2 |
| 2 | 93892-04012-18 | SCREW-WASHER (4X12) | 2 |
| 5 | 95002-02079 | CLIP, TUBE (B7) | 5 |
| 1 | 95002-02089 | CLIP, TUBE (B1 8) | 1 |
| 2 | 95005-35001-50M | BULK HOSE, VACUUM (3.5X1000) (3.5X140) | 2 |
| 1 | 99101-GHB-1200 | JET, MAIN (#120) (Optional). | 1 |
| 1 | 99101-GHB-1250 | JET, MAIN (#125) | 1 |
| 1 | 99101-MBZ-1200 | JET, MAIN (#120) (Optional). | 1 |
| 1 | 99101-443-1250 | JET, MAIN (#125) | 1 |
| 1 | 99103-MA1-0400 | JET, SLOW (#40) | 1 |
| 1 | 99112-HC4-0850 | JET, BY-STARTER (#85) | 1 |
| 1 | 99112-HN2-0850 | JET (#85) | 1 |
| 06161-HM5-305 | HEATER KIT, CARBURETOR (Optional). | ||
| 16070-HM5-305 | HEATER ASSY. (SOURCE: VINTAGE PARTS INC.) (Optional). | ||
| 16172-HN0-A00 | COLLAR, SETTING (Optional). | ||
| 30801-121-970 | CUSHION, CARBURETOR HEATER UNIT (Optional). | ||
| 30810-HM5-305 | HEATER UNIT, CARBURETOR (SOURCE: VINTAGE PARTS INC.) (Optional). | ||
| 30900-HM5-305 | SENSOR, THERMO (SOURCE: VINTAGE PARTS INC.) (Optional). | ||
| 32300-HM5-305 | SUB-WIRE, HEATER (Optional). |
