Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 06910-MBL-610 | BEARING SET, NEEDLE | 1 |
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 12361-300-000 | CAP, VALVE ADJ. | ||
| 12361-371-980 | CAP, VALVE ADJ. | ||
| 41300-MEH-000 | GEAR ASSY., FINAL | ||
| 1 | 41305-MB4-770 | RING, STOPPER | 1 |
| 1 | 41310-MEH-000 | GEAR SET, FINAL | 1 |
| 1 | 41311-MEH-000 | CASE SUB-ASSY., FINAL GEAR | 1 |
| 1 | 41320-MEH-000 | COVER SUB-ASSY., FINAL GEAR | 1 |
| 1 | 41331-MN5-000 | RETAINER, BEARING | 1 |
| 1 | 41332-415-000 | LOCK A, BEARING ADJUSTING (SINGLE TAB) | 1 |
| 1 | 41333-415-000 | LOCK B, BEARING ADJUSTING (DOUBLE TABS) | 1 |
| 1 | 41352-MEH-010 | STAY A, FINAL GEAR COVER | 1 |
| 1 | 41353-MEH-000 | STAY B, FINAL GEAR COVER | 1 |
| 1 | 41410-ME9-770 | JOINT, PINION | 1 |
| 1 | 41450-MG9-000 | SHIM A, PINION GEAR (1.32) | 1 |
| 1 | 41451-MG9-000 | SHIM B, PINION GEAR (1.38) | 1 |
| 1 | 41452-MG9-000 | SHIM C, PINION GEAR (1.44) | 1 |
| 1 | 41453-MG9-000 | SHIM D, PINION GEAR (1.50) | 1 |
| 1 | 41454-MG9-000 | SHIM E, PINION GEAR (1.56) | 1 |
| 1 | 41455-MG9-000 | SHIM F, PINION GEAR (1.62) | 1 |
| 1 | 41456-MG9-000 | SHIM G, PINION GEAR (1.68) | 1 |
| 1 | 41510-MS9-750 | SHIM A, SHAFT (1.73) | 1 |
| 1 | 41511-MS9-750 | SHIM B, SHAFT (1.76) | 1 |
| 1 | 41512-MS9-750 | SHIM C, SHAFT (1.79) | 1 |
| 1 | 41513-MS9-750 | SHIM D, SHAFT (1.82) | 1 |
| 1 | 41514-MS9-750 | SHIM E, SHAFT (1.85) | 1 |
| 1 | 41515-MS9-750 | SHIM F, SHAFT (1.88) | 1 |
| 1 | 41516-MS9-750 | SHIM G, SHAFT (1.91) | 1 |
| 1 | 41517-MS9-750 | SHIM H, SHAFT (1.94) | 1 |
| 1 | 41518-MS9-750 | SHIM I, SHAFT (1.97) | 1 |
| 1 | 41519-MS9-750 | SHIM J, SHAFT (2.00) | 1 |
| 1 | 41520-MS9-750 | SHIM K, SHAFT (2.03) | 1 |
| 1 | 41521-MS9-750 | SHIM L, SHAFT (2.06) | 1 |
| 1 | 41522-MS9-750 | SHIM M, SHAFT (2.09) | 1 |
| 1 | 41523-MS9-750 | SHIM N, SHAFT (2.12) | 1 |
| 1 | 41524-MS9-750 | SHIM O, SHAFT (2.15) | 1 |
| 1 | 41525-MS9-750 | SHIM P, SHAFT (0.45) | 1 |
| 1 | 41530-MCA-000 | SHIM A, RING GEAR (1.82) | 1 |
| 1 | 41531-MCA-000 | SHIM B, RING GEAR (1.88) | 1 |
| 1 | 41532-MCA-000 | SHIM C, RING GEAR (1.94) | 1 |
| 1 | 41533-MCA-000 | SHIM D, RING GEAR (2.00) | 1 |
| 1 | 41534-MCA-000 | SHIM E, RING GEAR (2.06) | 1 |
| 1 | 41535-MCA-000 | SHIM F, RING GEAR (2.12) | 1 |
| 1 | 41536-MCA-000 | SHIM G, RING GEAR (2.18) | 1 |
| 1 | 41537-MCA-000 | SHIM H, RING GEAR (2.24) | 1 |
| 1 | 41538-MCA-000 | SHIM I, RING GEAR (2.30) | 1 |
| 1 | 41539-MCA-000 | SHIM J, RING GEAR (2.36) | 1 |
| 1 | 41540-MCA-000 | SHIM K, RING GEAR (2.42) | 1 |
| 1 | 41541-MCA-000 | SHIM L, RING GEAR (2.48) | 1 |
| 1 | 41542-MCA-000 | SHIM M, RING GEAR (2.54) | 1 |
| 1 | 41543-MCA-000 | SHIM N, RING GEAR (2.60) | 1 |
| 1 | 41544-MCA-000 | SHIM P, RING GEAR (2.66) | 1 |
| 1 | 83551-GE2-000 | GROMMET, AIR CLEANER HOUSING | 1 |
| 1 | 90109-ME5-770 | BOLT, SOCKET (8X11) | 1 |
| 5 | 90125-MCA-300 | BOLT, STUD (12X46) | 5 |
| 6 | 90133-MCA-000 | BOLT, FLANGE (8X30) | 6 |
| 2 | 90134-MCA-000 | BOLT, FLANGE (10X38) | 2 |
| 1 | 90381-MB0-010 | NUT, HEX. (16MM) | 1 |
| 1 | 90471-580-000 | GASKET (8MM) | 1 |
| 1 | 91051-MEH-003 | BEARING, RADIAL BALL (100X125X13) | 1 |
| 1 | 91052-MS9-003 | BEARING, RADIAL BALL (30X55X18) | 1 |
| 1 | 91061-MT3-003 | BEARING, RADIAL BALL (QJ3/28V1) | 1 |
| 1 | 91262-MCH-003 | OIL SEAL (39X56X7) | 1 |
| 1 | 91265-MEH-003 | OIL SEAL (99.7X117X7) | 1 |
| 1 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 1 | 91359-MG9-003 | O-RING (64.5X3.5) (ARAI) | 1 |
| 91451-MEC-A01 | TUBE, FINAL GEAR BREATHER | ||
| 1 | 92101-06012-0A | BOLT, HEX. (6X12) | 1 |
| 4 | 92900-10040-0E | BOLT, STUD (10X40) | 4 |
| 2 | 94301-12160 | PIN A, DOWEL (12X16) | 2 |
| 1 | 95002-02079 | CLIP, TUBE (B7) | 1 |
| 4 | 95701-06012-00 | BOLT, FLANGE (6X12) | 4 |
