Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1050 | 503195313 | Stopper Strap | 1 |
| 1060 | 503193995 | Washer | 2 |
| 1070 | 207663056 | Hex. Flange Screw M6 X 1.0 X 30 | 1 |
| 1080 | 233261466 | Hex. Flange Elastic Nut M6 | 1 |
| 2000 | 503196038 | Front Suspension Arm Ass'y Included 2000 to 2000h | 1 |
| 2000b | 503191556 | Extended Bushing | 4 |
| 2000c | 503192531 | Rocker | 1 |
| 2000d | 503191555 | Swivel Bushing | 2 |
| 2000e | 503193037 | Bushing | 1 |
| 2000f | 503189282 | Bushing | 1 |
| 2000g | 207005044 | Hex. Screw M10 X 1.5 X 50 | 1 |
| 2000h | 233601416 | Elastic Locking Nut M10 X 1.5 | 1 |
| 2010 | 503193714 | Upper Axle | 2 |
| 2030 | 503192496 | Washer | 2 |
| 2040 | 503191926 | Washer | 2 |
| 2050 | 207006056 | Hex. Cap Screw M10 X 60 | 2 |
| 2060 | 233601466 | Elastic Locking Nut M10 | 2 |
| 2070 | 503193716 | Lower Axle | 2 |
| 2080 | 250200113 | Flat Washer, 12 mm | 2 |
| 2110 | 250000537 | Hex. Cap Screw M12 X 35 | 2 |
| 3000 | 503196045 | Rear Suspension Arm Ass'y Included 3000 to 3000r | 1 |
| 3000b | 503192767 | Bushing | 2 |
| 3000c | 503191555 | Swivel Bushing | 4 |
| 3000d | 503191640 | Cushion | 2 |
| 3000e | 503195743 | Lower Shaft | 1 |
| 3000f | 503195658 | Pivot Arm Ass'y Included 3000f to 3000f.p | 1 |
| 3000f.c | 390402200 | Pop Rivet 3/16" | 2 |
| 3000f.g | 517225900 | Flat Washer | 2 |
| 3000f.j | 408200700 | Grease Fitting | 1 |
| 3000f.n | 232551414 | Elastic Stop Nut M5 | 2 |
| 3000f.p | 205041060 | Socket Head Screw M4X 10 | 2 |
| 3000g | 503195700 | Guide | 2 |
| 3000h | 503195701 | LH Cam | 1 |
| 3000j | 503195702 | RH Cam | 1 |
| 3000k | 503192496 | Washer | 2 |
| 3000m | 205503554 | Socket Head Screw M10 X 35 | 2 |
| 3000n | 408200700 | Grease Fitting | 1 |
| 3000p | 503195853 | O-Ring | 2 |
| 3000q | 516004900 | LH Block Sticker Decal | 1 |
| 3000r | 516004901 | RH Block Sticker Decal | 1 |
| 3010 | 503196052 | Black, LH Square Spring | 1 |
| 3020 | 503196053 | Black, RH Square Spring | 1 |
| 3060 | 503190434 | Labyrinth Seal | 2 |
| 3070 | 503195817 | Black, Wheel Ass'y 165 Included 3070 to 3070b | 2 |
| 3070a | 503193548 | Ball Bearing | 1 |
| 3070b | 415129780 | Retaining Ring | 1 |
| 3080 | 503189146 | Axle Spring | 2 |
| 3090 | 503192592 | Labyrinth Ring | 2 |
| 3100 | 503195798 | Arm Extension Included 3100 to 3100e | 2 |
| 3100c | 503192494 | Washer | 1 |
| 3100d | 233281466 | Elastic Flange Nut M8 | 1 |
| 3100e | 503191555 | Swivel Bushing | 2 |
| 3110 | 293370080 | Retaining Ring | 2 |
| 3170 | 503192496 | Washer | 2 |
| 3180 | 207204056 | Cap Screw Hex. M10 X 40 | 2 |
| 3190 | 503189156 | Pivot Arm Axle | 1 |
| 3200 | 503192494 | Washer | 4 |
| 3210 | 503192440 | Bolt M8 X 248mm | 1 |
| 3220 | 233281466 | Elastic Flange Nut M8 | 1 |
| 4000 | 503193814 | Accélération Link Rod | 2 |
| 4030 | 503190643 | Axle Bar (Long) | 1 |
| 4060 | 503192494 | Washer | 2 |
| 4070 | 503193372 | Screw M8 X 90 | 1 |
| 4080 | 233281466 | Elastic Flange Nut M8 | 1 |
| 4090 | 503192555 | Axle Bar | 2 |
| 4100 | 503192494 | Washer | 2 |
| 4110 | 234082410 | Flat Washer 8 mm | 2 |
| 4120 | 207085556 | Hex. Screw M8 X 55 | 2 |
| 4130 | 233281466 | Elastic Flange Nut M8 | 2 |
