Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 27311-19B10 | GEAR, FRONT DRIVE BEVEL NT:11 | ||
| 27321-19B11 | GEAR, FRONT DRIVEN BEVEL NT:34 | ||
| 1 | 09180-25085 | SPACER | 1 |
| 1 | 09265-25013 | BEARING, FRONT | 1 |
| 1 | 09265-25011 | BEARING, REAR MODEL M | 1 |
| 1 | 09265-25024 | BEARING, REAR MODEL N/P/R/S | 1 |
| 1 | 09262-70001 | BEARING (70X110X13) | 1 |
| 1 | 27411-19B00 | CASE, DIFFERENTIAL | 1 |
| 27331-65000 | PINION, DIFFERENTIAL SIDE NT:10 | ||
| 27341-19B10 | GEAR, RH (NT:13) | ||
| 27341-84211 | GEAR, LH (NT:13) MODEL M/N | ||
| 27341-84212 | GEAR, LH (NT:13) MODEL P/R/S | ||
| 27351-51005 | SHAFT, PINION | ||
| 27322-19B10 | HUB MODEL M/N | ||
| 27322-19B11 | HUB MODEL P/R/S | ||
| 27361-19B10 | SHAFT, DRIVEN OUTPUT | ||
| 09160-29011 | WASHER (T:0.8) | ||
| 09160-29012 | WASHER (T:1.0) | ||
| 09160-29013 | WASHER (T:1.2) | ||
| 09164-29003 | WASHER | ||
| 2 | 09160-13003 | WASHER (13.3X25X0.85) | 2 |
| 09202-06022 | PIN, PINION SHAFT | ||
| 6 | 07110-08165 | BOLT MODEL M/N/P | 6 |
| 6 | 07130-08163 | BOLT MODEL R/S | 6 |
| 27450-19B00 | HOUSING, DIFFERENTIAL GEAR MODEL M/N | ||
| 27450-19B10 | HOUSING, DIFFERENTIAL GEAR MODEL P | ||
| 27450-19B11 | HOUSING, DIFFERENTIAL GEAR MODEL R | ||
| 27450-19B12 | HOUSING, DIFFERENTIAL GEAR MODEL S; Includes Item(s) 19 | ||
| 1 | 09364-08003 | UNION, BREATHER | 1 |
| 1 | 27441-19B00 | HOUSING, DRIVE BEVEL GEAR | 1 |
| 1 | 08211-25351 | WASHER | 1 |
| 27326-19B00-035 | SHIM (T:0.35) | ||
| 27326-19B00-040 | SHIM (T:0.40) | ||
| 27326-19B00-050 | SHIM (T:0.50) | ||
| 27326-19B00-060 | SHIM (T:0.60) | ||
| 27327-34200 | SHIM (T:0.35) | ||
| 27327-34210 | SHIM (T:0.40) | ||
| 27327-34220 | SHIM (T:0.50) | ||
| 27327-34230 | SHIM (T:0.60) | ||
| 27445-19B00-015 | SHIM (T:0.15) | ||
| 27445-19B00-030 | SHIM (T:0.30) | ||
| 27445-19B00-035 | SHIM (T:0.35) | ||
| 27445-19B00-040 | SHIM (T:0.40) | ||
| 1 | 09280-63004 | O RING (D:2.4,ID:62.6) | 1 |
| 1 | 09280-00022 | O RING (D:2.4,ID;131.4) | 1 |
| 27461-19B00 | CASE, DRIVEN GEAR BEARING MODEL M/N | ||
| 27461-19B10 | CASE, DRIVEN GEAR BEARING MODEL P/R/S | ||
| 1 | 27471-19B00 | COVER MODEL M/N | 1 |
| 1 | 27471-19B01 | COVER MODEL P/R/S | 1 |
| 1 | 08113-60050 | BEARING, LH | 1 |
| 1 | 09262-40006 | BEARING, RH | 1 |
| 3 | 09283-34008 | OIL SEAL | 3 |
| 1 | 27473-19B00 | GASKET, CASE COVER MODEL M | 1 |
| 1 | 27473-19B10 | GASKET, CASE COVER MODEL N/P/R | 1 |
| 1 | 27473-19B11 | GASKET, CASE COVER MODEL S | 1 |
| 2 | 09103-10148 | BOLT (L:110) | 2 |
| 11 | 01550-08257 | BOLT | 11 |
| 2 | 01547-06357 | BOLT | 2 |
| 2 | 01547-06257 | BOLT | 2 |
| 2 | 04211-09109 | PIN | 2 |
| 1 | 27180-19B00 | FLANGE, DRIVE BEVEL GEAR Includes Item(s) 39 - 42 | 1 |
| 1 | 09165-30002 | PLATE | 1 |
| 1 | 27591-19B01 | COLLAR | 1 |
| 1 | 27592-19B00 | PLATE, OIL SEAL | 1 |
| 1 | 09280-28007 | O RING | 1 |
| 1 | 09159-16004 | NUT | 1 |
| 1 | 09160-16026 | WASHER (16X30X3) | 1 |
| 1 | 09247-14019 | PLUG, DRAIN | 1 |
| 1 | 09168-14002 | .GASKET (13.8X18.8X4.8) | 1 |
| 09247-16004 | PLUG, FILLER | ||
| 1 | 09280-17002 | O RING (D:2.4,ID:16.8) | 1 |
| 1 | 09352-70103-00B | HOSE, BREATHER (L:1280->1140) L:2000->1140 | 1 |
| 1 | 09401-10402 | CLIP MODEL M/N | 1 |
| 1 | 09401-10403 | CLIP MODEL P/R/S | 1 |
| 1 | 27371-19B00 | DOG MODEL M/N | 1 |
| 1 | 27371-19B01 | DOG MODEL P/R/S | 1 |
| 2 | 08319-31107 | NUT | 2 |
| 2 | 09381-22007 | CIRCLIP | 2 |
