Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 17710-29F11 | RADIATOR, RH MODEL K5/K6/K7 | 1 |
| 1 | 17710-29F40 | RADIATOR,WATER RH MODEL K8; Includes Item(s) 2 | 1 |
| 1 | 09148-06015 | .NUT | 1 |
| 1 | 17730-19D11 | CAP,RADIATOR (1.1) | 1 |
| 1 | 17720-29F12 | RADIATOR, LH MODEL K5/K6/K7 | 1 |
| 1 | 17720-29F40 | RADIATOR,WATER LH MODEL K8; Includes Item(s) 5 | 1 |
| 1 | 17568-50F00 | UNION,AIR VENT | 1 |
| 1 | 09168-06026 | GASKET (6.4X11.5X0.8) | 1 |
| 4 | 17787-19A00 | CUSHION,RADIATOR,LOWER | 4 |
| 4 | 09116-06147 | BOLT (6X25) | 4 |
| 4 | 09180-06243 | SPACER | 4 |
| 1 | 17851-29F10 | HOSE,RDTR INLET | 1 |
| 1 | 17852-29F30 | HOSE,RADIATOR OUTLET | 1 |
| 1 | 17853-29F10 | HOSE,RDTR JOINT | 1 |
| 3 | 09402-28513 | CLAMP | 3 |
| 3 | 09402-32512 | CLAMP | 3 |
| 1 | 17733-03D10 | SCREW,RADIATOR CAP | 1 |
| 1 | 34850-03D00 | SWITCH ASSY, WATER TEMP MODEL K5/K6/K7 | 1 |
| 1 | 34850-29F00 | SWITCH ASSY, WATER TEMP MODEL K8 | 1 |
| 1 | 17680-24A30 | SWITCH,FAN | 1 |
| 1 | 17911-29F11 | TANK,RESERVOIR | 1 |
| 1 | 17913-29F00 | CUSHION,RESERVOIR TANK | 1 |
| 1 | 17981-29F01 | HOSE,RESERVOIR TANK,INLET | 1 |
| 1 | 09352-50901-00B | HOSE, OVERFLOW L:2000!650 | 1 |
| 2 | 09401-08411 | CLIP | 2 |
| 1 | 09404-08205 | CLAMP, RESERVOIR HOSE | 1 |
| 1 | 09404-06429 | CLAMP, RESERVOIR INLET HOSE | 1 |
| 1 | 01550-0612B | BOLT | 1 |
| 2 | 09103-06274 | SCREW, RADIATOR SIDE | 2 |
| 2 | 09169-06053 | WASHER | 2 |
| 4 | 09103-06275 | SCREW, TANK SIDE | 4 |
| 4 | 09160-06125 | WASHER (6.5X14X1.6) | 4 |
| 1 | 47451-38A01 | CUSHION,TOOL HOLDER | 1 |
| 2 | 17831-37E11 | LOUVER,RADIATOR | 2 |
| 17760-29F80-019 | COVER, RADIATOR RH (BLACK) MODEL K5 | ||
| 17760-29F70-YU1 | COVER, RADIATOR RH (YELLOW) MODEL K5; Includes Item(s) 34 - 34 | ||
| 68665-29F80-BYL | TAPE, RADIATOR COVER RH MODEL K5 FOR 019 | ||
| 68665-29F70-YHB | TAPE, RADIATOR COVER RH MODEL K5 FOR YU1 | ||
| 17770-29F80-019 | COVER, RADIATOR LH (BLACK) MODEL K5 | ||
| 17770-29F70-YU1 | COVER, RADIATOR LH (YELLOW) MODEL K5; Includes Item(s) 36 - 36 | ||
| 68675-29F80-BYL | TAPE, RADIATOR COVER LH MODEL K5 FOR 019 | ||
| 68675-29F70-YHB | TAPE, RADIATOR COVER LH MODEL K5 FOR YU1 | ||
| 17760-29F90-019 | COVER, RADIATOR RH (BLACK) MODEL K6 | ||
| 17760-29F90-YU1 | COVER, RADIATOR RH (YELLOW) MODEL K6; Includes Item(s) 38 - 38 | ||
| 68665-29F90-CNN | TAPE, RADIATOR COVER RH MODEL K6 FOR 019 | ||
| 68665-29F90-CET | TAPE, RADIATOR COVER RH MODEL K6 FOR YU1 | ||
| 17770-29F90-019 | COVER, RADIATOR LH (BLACK) MODEL K6 | ||
| 17770-29F90-YU1 | COVER, RADIATOR LH (YELLOW) MODEL K6; Includes Item(s) 40 - 40 | ||
| 68675-29F90-CNN | TAPE, RADIATOR COVER LH MODEL K6 FOR 019 | ||
| 68675-29F90-CET | TAPE, RADIATOR COVER LH MODEL K6 FOR YU1 | ||
| 17760-29FB0-019 | COVER, RADIATOR RH (BLACK) MODEL K7 FOR 019 | ||
| 17760-29FB0-YLW | COVER, RADIATOR RH (BLUE) MODEL K7 FOR N9J; Includes Item(s) 42 - 42 | ||
| 68665-29FB0-DVU | TAPE, RADIATOR COVER RH MODEL K7 FOR 019 | ||
| 68665-29FB0-DVV | TAPE, RADIATOR COVER RH MODEL K7 FOR N9J | ||
| 1 | 17760-29FA0-YU1 | COVER, RADIATOR RH (YELLOW) MODEL K7 FOR YU1; Includes Item(s) 44 | 1 |
| 68665-29FA0-DRA | TAPE, RADIATOR COVER RH MODEL K7 FOR YU1 | ||
| 17770-29FB0-019 | COVER, RADIATOR LH (BLACK) MODEL K7 FOR 019 | ||
| 17770-29FB0-YLW | COVER, RADIATOR LH (BLUE) MODEL K7 FOR N9J; Includes Item(s) 46 - 46 | ||
| 68675-29FB0-DVU | TAPE, RADIATOR COVER LH MODEL K7 FOR 019 | ||
| 68675-29FB0-DVV | TAPE, RADIATOR COVER LH MODEL K7 FOR N9J | ||
| 17770-29FA0-YU1 | COVER, RADIATOR LH (YELLOW) MODEL K7 FOR YU1; Includes Item(s) 48 | ||
| 68675-29FA0-DRA | TAPE, RADIATOR COVER LH MODEL K7 FOR YU1 | ||
| 1 | 17760-29FE0-30H | COVER, RADIATOR RH (WHITE) MODEL K8 | 1 |
| 17760-29FF0-019 | COVER, RADIATOR RH (BLACK) MODEL K8; Includes Item(s) 50 - 50 | ||
| 68665-29FE0-FCS | TAPE, RADIATOR COVER RH MODEL K8 FOR 30H | ||
| 68665-29FF0-FCN | TAPE, RADIATOR COVER RH MODEL K8 FOR 019 | ||
| 17770-29FE0-30H | COVER, RADIATOR LH (WHITE) MODEL K8 | ||
| 17770-29FF0-019 | COVER, RADIATOR LH (BLACK) MODEL K8; Includes Item(s) 52 - 52 | ||
| 68675-29FE0-FCS | TAPE, RADIATOR COVER LH MODEL K8 FOR 30H | ||
| 68675-29FF0-FCN | TAPE, RADIATOR COVER LH MODEL K8 FOR 019 |
