Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 17211-383-670 | TRAP, FLAME | ||
| 17212-385-000 | CAP, ELEMENT HOLDER | ||
| 1 | 17213-383-670 | ELEMENT, AIR CLEANER | 1 |
| 17217-383-670 | PLATE B, AIR DUCT | ||
| 17217-385-000 | SPRING, ELEMENT | ||
| 17218-383-670 | PLATE A, AIR DUCT | ||
| 17219-383-670 | DUCT, AIR | ||
| 17220-383-670 | COVER, AIR CLEANER | ||
| 17221-383-670 | HOUSING, AIR CLEANER | ||
| 17226-383-670 | GASKET, AIR CLEANER HOUSING | ||
| 3 | 17245-107-010 | RUBBER, AIR CLEANER HOUSING SETTING | 3 |
| 17253-383-671 | TUBE, CONNECTING | ||
| 17253-383-672 | TUBE, CONNECTING | ||
| 1 | 17231-051-000 | BAND A, AIR CLEANER IN. PIPE | 1 |
| 1 | 17255-028-000 | BAND A, AIR CLEANER CONNECTING TUBE | 1 |
| 1 | 18362-720-000 | NUT, FLANGE (6MM) | 1 |
| 1 | 94050-06000 | NUT, FLANGE (6MM) | 1 |
| 1 | 31511-107-300 | RUBBER, BATTERY CUSHION | 1 |
| 31700-102-731 | RECTIFIER ASSY. | ||
| 1 | 38300-GF0-405 | RELAY ASSY., TURN SIGNAL | 1 |
| 1 | 38300-089-671 | RELAY, TURN SIGNAL | 1 |
| 1 | 38300-243-670 | RELAY, TURN SIGNAL | 1 |
| 1 | 38300-428-004 | RELAY, TURN SIGNAL | 1 |
| 1 | 38301-428-671 | RELAY, TURN SIGNAL (DENSO) | 1 |
| 1 | 38310-428-671 | RELAY, TURN SIGNAL | 1 |
| 38303-107-670 | SUB-WIRE, TURN SIGNAL RELAY | ||
| 38306-092-670 | SUSPENSION, TURN SIGNAL RELAY | ||
| 3 | 61104-357-000 | COLLAR, FR. FENDER | 3 |
| 3 | 61104-428-000 | COLLAR, FR. FENDER | 3 |
| 61105-428-000 | COLLAR, RR. FENDER | ||
| 1 | 83618-323-000 | RUBBER, BATTERY BOX | 1 |
| 87506-340-670 | LABEL, AIR CLEANER CAUTION | ||
| 2 | 92000-06025 | BOLT, HEX. (6X25) | 2 |
| 2 | 92101-06025-0A | BOLT, HEX. (6X25) | 2 |
| 1 | 92300-06025 | BOLT, RECESSED (6X25) | 1 |
| 1 | 92300-06025-0A | BOLT, RECESSED (6X25) | 1 |
| 1 | 92301-06025-0A | BOLT, RECESSED (6X25) | 1 |
| 2 | 90310-KA3-711 | NUT, HEX. (6MM) | 2 |
| 2 | 94000-06000-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06000 | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06000-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06008-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06200-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94030-06000 | NUT, HEX. (6MM) | 2 |
| 2 | 94101-06000 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94101-06080 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94101-06800 | WASHER, PLAIN (6MM) | 2 |
| 95002-30000 | CLIP, TUBE (C6) | ||
| 95003-08015-10 | TUBE, VINYL (4.5X6.5X150) | ||
| 1 | 95012-15000 | BAND D, BATTERY | 1 |
| 1 | 95012-15001 | BAND, BATTERY | 1 |
| 31500-329-677 | BATTERY ASSY. (6N6-3B) | ||
| 98203-63260 | BATTERY (6N6-3B) |
