Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 17730-20930 | CAP, RADIATOR,1.1 MODEL P | 1 |
| 1 | 17730-12C01 | CAP, RADIATOR,1.1 MODEL R/S | 1 |
| 17791-32C00 | CONDUCTION, RADIATOR | ||
| 2 | 01517-06167 | BOLT MODEL P | 2 |
| 2 | 01550-06163 | BOLT MODEL R/S | 2 |
| 17792-32C01 | BRACKET, CONDUCTION | ||
| 2 | 01517-06207 | BOLT MODEL P | 2 |
| 2 | 01550-06203 | BOLT MODEL R/S | 2 |
| 17793-17E00 | BRACKET, CONDUCTION BRACKET | ||
| 2 | 09159-06017 | NUT MODEL P | 2 |
| 2 | 08316-10063 | NUT MODEL R/S | 2 |
| 1 | 09280-44005 | O RING (D:2.4,ID:43.2) | 1 |
| 17662-17E00 | CONNECTOR, THERMOSTAT INLET | ||
| 1 | 17670-32C01 | THERMOSTAT, WATER | 1 |
| 17857-17E00 | HOSE, RADIATOR INLET MODEL P/R | ||
| 17857-17E01 | HOSE, RADIATOR INLET MODEL S | ||
| 17852-17E00 | HOSE, RADIATOR OUTLET | ||
| 17855-17E01 | HOSE, HEAD INLET JOINT MODEL P | ||
| 17855-17E02 | HOSE, HEAD INLET JOINT MODEL R | ||
| 17856-17E50 | HOSE, HEAD INLET JOINT MODEL S | ||
| 6 | 09402-30502 | CLAMP, WATER HOSE MODEL P/R | 6 |
| 6 | 09402-32511 | CLAMP, WATER HOSE MODEL S | 6 |
| 2 | 09402-33502 | CLAMP, WATER HOSE MODEL P/R | 2 |
| 2 | 09402-38511 | CLAMP, WATER HOSE MODEL S | 2 |
| 17853-17E00 | HOSE, WATER PUMP INLET | ||
| 17856-17E00 | HOSE, HEAD OUTLET | ||
| 17880-17E00 | PIPE, HEAD OUTLET | ||
| 17840-17E00 | PIPE, HEAD OUTLET NO.2 MODEL P | ||
| 17840-17E10 | PIPE, HEAD OUTLET NO.2 MODEL R/S | ||
| 2 | 17859-17E00 | HOSE, JOINT MODEL P/R | 2 |
| 2 | 17853-28C20 | HOSE, JOINT MODEL S | 2 |
| 4 | 09402-25502 | CLAMP MODEL P/R | 4 |
| 4 | 09402-28511 | CLAMP MODEL S | 4 |
| 6 | 01517-06125 | BOLT MODEL P | 6 |
| 6 | 01550-06123 | BOLT MODEL RMODEL S | 6 |
| 4 | 09103-06183 | BOLT (6X38) MODEL S | 4 |
| 17860-17E00 | PIPE, CYLINDER SIDE MODEL P | ||
| 17860-21E00 | PIPE, CYLINDER SIDE MODEL R | ||
| 17860-17E00 | PIPE, CYLINDER SIDE MODEL S | ||
| 17870-17E00 | PIPE, CYLINDER INLET MODEL P | ||
| 17870-21E01 | PIPE, CYLINDER INLET MODEL R/S | ||
| 17890-17E00 | UNION, HOSE JOINT MODEL P | ||
| 17890-21E00 | UNION, HOSE JOINT MODEL R | ||
| 17890-17E01 | UNION, HOSE JOINT MODEL S | ||
| 4 | 09280-18009 | O RING (D:3.2,ID:17.8) | 4 |
| 1 | 34850-82002 | GAUGE ASSY, WATER TEMPERATURE MODEL P | 1 |
| 1 | 34850-50A00 | GAUGE ASSY, WATER TEMPERATURE MODEL R/S | 1 |
| 1 | 17680-45D00 | SWITCH, RADIATOR FAN | 1 |
| 17910-17E10 | TANK ASSY, RESERVOIR | ||
| 17910-17E01 | TANK ASSY, RESERVOIR CALIFORNIA ONLY; Includes Item(s) 32 | ||
| 1 | 17932-12C00 | .CAP, RESERVOIR TANK | 1 |
| 2 | 09136-06022 | SCREW (6X16) | 2 |
| 1 | 17981-17E00 | HOSE, RESERVOIR TANK INLET | 1 |
| 2 | 09401-08407 | CLIP MODEL P | 2 |
| 2 | 09401-08411 | CLIP MODEL R/S | 2 |
| 1 | 17982-17E00 | HOSE, OVER FLOW | 1 |
| 09407-22404 | CLAMP | ||
| 1 | 09407-18402 | CLAMP | 1 |
