Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13200-19A00 | CARBURETOR ASSY MODEL F | ||
| 13200-19A10 | CARBURETOR ASSY MODEL G | ||
| 13200-01C01 | CARBURETOR ASSY MODEL H | ||
| 13200-01C11 | CARBURETOR ASSY MODEL J | ||
| 13200-01C20 | CARBURETOR ASSY MODEL K/L | ||
| 13200-01C30 | CARBURETOR ASSY MODEL M | ||
| 13200-01C31 | CARBURETOR ASSY MODEL N; Includes Item(s) 1 - 54 | ||
| 13261-14500 | CAP, TOP | ||
| 13266-14500 | GASKET | ||
| 2 | 02112-04126 | SCREW | 2 |
| 2 | 08321-21046 | LOCK WASHER | 2 |
| 1 | 13681-41510 | CAP, RUBBER | 1 |
| 1 | 13577-41612 | ADJUSTER | 1 |
| 1 | 13661-16600 | NUT | 1 |
| 13573-14500 | SPRING MODEL F/G | ||
| 13573-01C00 | SPRING MODEL H/J/K/L/M/N | ||
| 13629-16700 | RING | ||
| 13398-16700 | JOINT | ||
| 2 | 02112-03106 | SCREW | 2 |
| 2 | 08321-21036 | LOCK WASHER | 2 |
| 13383-14510 | NEEDLE, JET (6FP55-3) MODEL F/G | ||
| 13383-01C00 | NEEDLE, JET (6FP60-3) MODEL H | ||
| 13383-01C10 | NEEDLE, JET (6FP63-3) MODEL J/K/L/M/N | ||
| 1 | 13394-10010 | E RING MODEL F/G/H | 1 |
| 1 | 13394-31210 | E RING MODEL J/K/L/M/N | 1 |
| 13551-19A00 | VALVE, PISTON (CA:3.0) MODEL F | ||
| 13551-19A10 | VALVE, PISTON (CA:4.0) MODEL G | ||
| 13551-01C00 | VALVE, PISTON (CA:4.0) MODEL H/J/K/L/M/N | ||
| 09494-00491 | JET, NEEDLE (Q-1) MODEL F | ||
| 09494-00526 | JET, NEEDLE (Q-3) MODEL G | ||
| 09494-00393 | JET, NEEDLE (Q-8) MODEL H/M | ||
| 09494-00357 | JET, NEEDLE (R-0) MODEL J/K/L | ||
| 09494-00729 | JET, NEEDLE (Q-7) MODEL N | ||
| 2 | 13252-18620 | FLOAT | 2 |
| 1 | 13254-92311 | PIN, FLOAT | 1 |
| 09492-45009 | JET, PILOT (45) MODEL F/G | ||
| 09492-35006 | JET, PILOT (37.5) MODEL H | ||
| 1 | 09492-30006 | JET, PILOT (30) MODEL J/K/L/M/N | 1 |
| 09491-40006 | JET, MAIN (200) MODEL F | ||
| 09491-42001 | JET, MAIN (210) MODEL G | ||
| 09491-48001 | JET, MAIN (240) MODEL H/J/K/L | ||
| 09491-54002 | JET, MAIN (270) MODEL M | ||
| 1 | 09491-52001 | JET, MAIN (260) MODEL N | 1 |
| 13331-19A00 | RING MODEL F | ||
| 13331-19A10 | RING MODEL G | ||
| 13331-01B21 | RING MODEL H/J/K/L/M/N | ||
| 13370-14300 | VALVE ASSY, NEEDLE | ||
| 1 | 13373-39110 | PLATE | 1 |
| 1 | 02112-04066 | SCREW | 1 |
| 4 | 02112-05166 | SCREW | 4 |
| 4 | 08321-21056 | LOCK WASHER | 4 |
| 13693-13A00 | PLATE MODEL G/H/J | ||
| 1 | 13267-48700 | ADJUSTER, THROTTLE STOP | 1 |
| 1 | 13268-48110 | SPRING | 1 |
| 1 | 13278-02340 | .O RING | 1 |
| 13253-40010 | ARM, FLOAT | ||
| 1 | 13249-41310 | O RING | 1 |
| 1 | 13247-32210 | BOLT, DRAIN | 1 |
| 13269-48030 | SCREW, AIR (3/4) MODEL F | ||
| 13269-48030 | SCREW, AIR (1 1/4) MODEL G | ||
| 13269-48030 | SCREW, AIR (1 1/2) MODEL H | ||
| 13269-48030 | SCREW, AIR (2.0) MODEL J/K/L/M | ||
| 13269-48030 | SCREW, AIR (1 3/4) MODEL N | ||
| 1 | 13268-48700 | .SPRING,THROTTLE SCREW | 1 |
| 1 | 13291-29900 | .WASHER (14X17) | 1 |
| 1 | 13295-29900 | O RING | 1 |
| 13251-14300 | GASKET, FLOAT CHAMBER | ||
| 13692-14500 | CLIP | ||
| 1 | 13601-04148 | SCREW | 1 |
| 13414-13A00 | LEVER, CHOKE | ||
| 1 | 13602-05A30 | SCREW | 1 |
| 13571-19A00 | WASHER | ||
| 1 | 13682-09210 | CAP | 1 |
| 1 | 13418-09110 | HOLDER, PLUNGER | 1 |
| 13426-13A00 | SPRING | ||
| 13411-18010 | PLUNGER ASSY | ||
| 1 | 13417-18630 | SPRING | 1 |
| 2 | 13693-36500 | PLATE MODEL K/L/M/N | 2 |
| 1 | 13684-19A01 | HOSE (3.5X6.5X300) MODEL F/G | 1 |
| 2 | 13684-19A01 | HOSE (3.5X6.5X300!225) MODEL F/G | 2 |
| 1 | 13683-37420 | HOSE (3.5X6.5X500!350) MODEL H/J | 1 |
| 2 | 13683-37420 | HOSE (3.5X6.5X500!350) MODEL K/L/M/N | 2 |
| 1 | 13683-37420 | HOSE (3.5X6.5X500!280) MODEL H/J | 1 |
| 1 | 13683-37420 | HOSE (3.5X6.5X500!225) MODEL H/J/K/L/M/N | 1 |
| 09491-38009 | JET, MAIN (190) OPT | ||
| 09491-38006 | JET, MAIN (195) OPT | ||
| 09491-40006 | JET, MAIN (200) OPT | ||
| 09491-42001 | JET, MAIN (210) OPT | ||
| 09491-44001 | JET, MAIN (220) OPT | ||
| 1 | 09491-46001 | JET, MAIN (230) OPT | 1 |
| 09491-48001 | JET, MAIN (240) OPT | ||
| 09491-50008 | JET, MAIN (250) OPT | ||
| 1 | 09491-52001 | JET, MAIN (260) OPT | 1 |
| 09491-54002 | JET, MAIN (270) OPT | ||
| 1 | 09404-06402 | CLAMP (L:60) MODEL F/G | 1 |
| 1 | 09407-25401 | CLAMP, AIR VENT HOSE MODEL L/M/N | 1 |
