Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 11065-0062 | CAP,GEAR CASE,RH | 1 |
| 1 | 13107-0043 | SHAFT,OUTPUT,BEVEL GEAR | 1 |
| 1 | 13107-2235 | SHAFT | 1 |
| 1 | 13139-0005 | SHIFTER,2WD/4WD | 1 |
| 1 | 13236-0039 | LEVER-COMP | 1 |
| 1 | 14044-0005 | HOLDER-CABLE,SHIFT CONTROL | 1 |
| 1 | 14044-0006 | HOLDER-CABLE,DIFF-LOCK | 1 |
| 1 | 14044-0007 | HOLDER-CABLE,2WD/4WD | 1 |
| 1 | 14055-0008 | CASE-GEAR,RH | 1 |
| 1 | 14055-5001 | CASE-GEAR,SET | 1 |
| 1 | 14069-1051 | BREATHER | 1 |
| 1 | 14091-0394 | COVER | 1 |
| 1 | 14092-0052 | COVER | 1 |
| 1 | 14092-0053 | COVER | 1 |
| 1 | 16115-0015 | CAP-OIL FILLER | 1 |
| 1 | 16115-1053 | CAP-OIL FILLER | 1 |
| 1 | 39111-0016 | ROD-TIE | 1 |
| 1 | 42036-2060 | SLEEVE | 1 |
| 1 | 49022-0021 | GEAR-BEVEL,18T | 1 |
| 1 | 49022-0022 | GEAR-BEVEL,PINION,16T | 1 |
| 1 | 49110-0004 | GOVERNOR-ASSY | 1 |
| 2 | 92002-1656 | BOLT,6X14 | 2 |
| 1 | 92005-1127 | FITTING,BREATHER | 1 |
| 1 | 92009-1914 | SCREW,64MM | 1 |
| 6 | 92009-2308 | SCREW | 6 |
| 1 | 92015-1768 | NUT,25MM | 1 |
| 1 | 92022-1990 | WASHER,TOOTHED | 1 |
| 1 | 92022-225 | WASHER,25.3X32X0.5 | 1 |
| 1 | 92025-1688 | SHIM,25.3X36X0.15 | 1 |
| 1 | 92025-1689 | SHIM,25.3X36X0.50 | 1 |
| 1 | 92025-1690 | SHIM,25.3X36X0.60 | 1 |
| 1 | 92025-1691 | SHIM,25.3X36X0.70 | 1 |
| 1 | 92025-1692 | SHIM,25.3X36X0.80 | 1 |
| 1 | 92025-1693 | SHIM,25.3X36X0.90 | 1 |
| 1 | 92025-1694 | SHIM,25.3X36X1.00 | 1 |
| 1 | 92025-1695 | SHIM,25.3X36X1.10 | 1 |
| 1 | 92025-1696 | SHIM,25.3X36X1.20 | 1 |
| 1 | 92028-1347 | BUSHING | 1 |
| 1 | 92033-0035 | RING-SNAP | 1 |
| 1 | 92033-0036 | RING-SNAP | 1 |
| 2 | 130BA0614 | BOLT-FLANGED,6X14 | 2 |
| 1 | 130BA0616 | BOLT-FLANGED,6X16 | 1 |
| 16 | 130BA0635 | BOLT-FLANGED,6X35 | 16 |
| 8 | 130BA0845 | BOLT-FLANGED,8X45 | 8 |
| 2 | 130BA1025 | BOLT-FLANGED,10X25 | 2 |
| 1 | 130CA0620 | BOLT-FLANGED,6X20 | 1 |
| 1 | 601B6008 | BEARING-BALL | 1 |
| 1 | 601B6202 | BEARING-BALL,#6202C3 | 1 |
| 1 | 601B6206 | BEARING-BALL,#6206C3 | 1 |
| 1 | 601B6303 | BEARING-BALL,#6303C3 | 1 |
| 1 | 601B6303U | BEARING-BALL | 1 |
| 3 | 601B6305 | BEARING-BALL,#6305C3 | 3 |
| 1 | 601B6305U | BEARING-BALL,#6305U | 1 |
| 2 | 92037-1505 | CLAMP,TUBE | 2 |
| 2 | 92043-1037 | PIN,DOWEL,10X14 | 2 |
| 2 | 92043-1263 | PIN,6.2X8X14 | 2 |
| 1 | 92045-1213 | BEARING-BALL,6210CM | 1 |
| 2 | 92049-0049 | SEAL-OIL,HTC 30 60 8 | 2 |
| 1 | 92049-0053 | SEAL-OIL,YC9Y 22X50X9X13.4 | 1 |
| 2 | 92049-1520 | SEAL-OIL,TC14245 | 2 |
| 1 | 92049-1576 | SEAL-OIL,HTC 28X45X7 | 1 |
| 1 | 92049-2097 | SEAL-OIL,VC-6X10X2.5 | 1 |
| 1 | 92051-005 | SEAL-OIL,TB13225.5 | 1 |
| 1 | 92055-012 | RING-O | 1 |
| 1 | 92055-1141 | RING-O,ID=13.8 | 1 |
| 1 | 92055-2185 | RING-O,20X3 | 1 |
| 1 | 92065-058 | GASKET,10.5X16X1 | 1 |
| 1 | 92066-1227 | PLUG,PT1/8X7 | 1 |
| 1 | 92067-001 | PLUG,DRAIN,10X12 | 1 |
| 1 | 92152-0132 | COLLAR,20.2X28.0 | 1 |
| 4 | 92153-0898 | BOLT,FLANGED,8X21 | 4 |
| 3 | 92153-0908 | BOLT,10X30 | 3 |
| 1 | 92171-0476 | CLAMP | 1 |
| 1 | 92192-0216 | TUBE | 1 |
| 4 | 92200-0205 | WASHER,8.2X20.0X2.5 | 4 |
| 1 | 92200-0210 | WASHER,17X30X3.5 | 1 |
| 3 | 92200-0211 | WASHER,10.2X23X2.5 | 3 |
| 1 | 92200-2036 | WASHER,6.2X20X0.5 | 1 |
| 1 | 92210-0211 | NUT,16MM | 1 |
