Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 27410-03G20 | CASE ASSY, REAR Includes Item(s) 2 - 65 | ||
| 1 | 27155-38FP0 | SHAFT, REAR FINAL DRIVE | 1 |
| 1 | 27156-38FM0 | SEAL, FINAL DRIVE BEARING | 1 |
| 1 | 27157-38F00 | JOINT, REAR FINAL DRIVE | 1 |
| 27311-38FM0 | GEAR, FINAL DRIVE BEVEL | ||
| 1 | 27312-38F00 | .STOPPER,FINAL DRIVE BEARING | 1 |
| 1 | 27316-38FM0 | SPACER, REAR FINAL DRIVE | 1 |
| 1 | 27321-38FM0 | GEAR, FINAL DRIVEN BEVEL | 1 |
| 1 | 27326-09810 | SHIM SET, FINAL DRIVEN LH T:0.30/0.35/0.40/0.50/0.60 | 1 |
| 1 | 27326-18810 | SHIM SET, FINAL DRIVEN RH T:0.30/0.35/0.40/0.50/0.60 | 1 |
| 1 | 27445-24810 | .SHIM SET,FINAL DRIVE GEAR (T T:0.30/0.35/0.40/0.50/0.60 | 1 |
| 27450-38FM0 | CASE, REAR FINAL GEAR | ||
| 1 | 09364-08009 | UNION, BREATHER | 1 |
| 27461-38FM0 | CASE, REAR FINAL DRIVEN RH | ||
| 27471-38FP0 | HOUSING, REAR FINAL DRIVE | ||
| 1 | 27590-38F00 | COLLAR, OUTPUT OIL SEAL | 1 |
| 1 | 09168-06018 | .GASKET (6.2X13X1.2) 6.2X13X1.2 | 1 |
| 1 | 09168-16002 | GASKET, OIL DRAIN 16X22X2.0 | 1 |
| 1 | 09168-16002 | GASKET, OIL FILLER 16X22X2.0 | 1 |
| 1 | 27407-38FM0 | WASHER, REAR FINAL DRIVE | 1 |
| 1 | 09248-16012 | PLUG, OIL DRAIN | 1 |
| 1 | 09248-16012 | PLUG, OIL FILLER | 1 |
| 1 | 27405-38FM0 | BEARING, REAR FINAL | 1 |
| 1 | 27405-38FN0 | BEARING, FINAL DRIVE GEAR | 1 |
| 1 | 27405-38FP0 | BEARING, FINAL DRIVEN RH | 1 |
| 1 | 27405-38FR0 | BEARING, FINAL DRIVE PILOT | 1 |
| 1 | 27405-38FS0 | BEARING, FINAL DRIVEN LH | 1 |
| 1 | 27405-38FT0 | O RING, BEARING CASE RH | 1 |
| 1 | 09280-24010 | O RING (D:2.4,ID:23.7) D:2.4,ID:23.7 | 1 |
| 1 | 09280-76008 | O RING, REAR FINAL HOUSING D:3.1,ID:74.0 | 1 |
| 1 | 09283-38009 | OIL SEAL, FINAL DRIVEN LH 38X54X6.0 | 1 |
| 1 | 09283-42011 | OIL SEAL, FINAL DRIVEN RH 42X62X7.0 | 1 |
| 4 | 01421-10303 | BOLT, REAR FINAL GEAR | 4 |
| 1 | 27401-38FM0 | BOLT, OIL CHECK | 1 |
| 8 | 27401-38FM0 | BOLT, REAR FINAL GEAR | 8 |
| 1 | 27407-38FN0 | WASHER, FINAL DRIVEN LH | 1 |
| 27408-38FM0 | NUT, REAR FINAL DRIVE | ||
| 3 | 08331-31256 | CIRCLIP | 3 |
| 1 | 27403-38FM0 | CIRCLIP, REAR FINAL BEARING | 1 |
| 1 | 25350-09F50 | STOPPER, PARKING CAM | 1 |
| 1 | 29613-44D00 | SPRING | 1 |
| 1 | 25351-44D50 | STOPPER | 1 |
| 1 | 25360-38F00 | ARM SELECT | 1 |
| 1 | 25932-38F10 | PAWL, PARKING LOCK | 1 |
| 1 | 25933-38FM0 | SPRING, PARKING | 1 |
| 1 | 25934-38F10 | SHAFT, PARKING PAWL | 1 |
| 1 | 25935-38FM0 | GEAR, PARKING LOCK (NT:24) | 1 |
| 2 | 09181-25139 | WASHER (25X32X1.0) | 2 |
| 1 | 25936-38FM0 | SPACER, PARKING PAWL | 1 |
| 25940-38F00 | SHAFT, PARKING LOCK CAM | ||
| 1 | 25942-38F00 | CAM, PARKING LOCK SHAFT | 1 |
| 25944-38F00 | GUIDE, PARKING PAWL | ||
| 1 | 25984-38FM0 | SPRING, PARKING CAM | 1 |
| 1 | 27475-38FM0 | COVER, REAR FINAL DOOR | 1 |
| 1 | 09168-06024 | GASKET, REAR FINAL COVER | 1 |
| 1 | 09168-10007 | GASKET, PARKING PAWL | 1 |
| 1 | 09168-14002 | .GASKET (13.8X18.8X4.8) | 1 |
| 27407-38FP0 | WASHER, PARKING RH | ||
| 27407-38FR0 | WASHER, PARKING LH | ||
| 1 | 09248-10007 | PLUG, PARKING PAWL | 1 |
| 27405-38FU0 | BEARING, PARKING CAM | ||
| 1 | 09283-14006 | SEAL, PARKING 14X22X6 | 1 |
| 27401-38FP0 | BOLT, REAR FINAL HOUSING | ||
| 27401-38FR0 | BOLT, REAR FINAL HOUSING | ||
| 27401-38FS0 | BOLT, SELECT ARM | ||
| 27404-38FM0 | PIN, REAR FINAL COVER | ||
| 1 | 27153-03G10 | BOOT, RR FINAL DRIVE | 1 |
| 1 | 27491-38F00 | CASE, BREATHER | 1 |
| 1 | 09401-08411 | CLAMP | 1 |
