Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 715009073 | Deep Black, Rear Chasis Kit Includes 10 to 10a69 | 1 |
| 16 | 390402200 | Pop Rivet 3/16" | 16 |
| 1 | 715008347 | Front Cage Service Kit | 1 |
| 1 | 715009063 | Rear Cage Service Kit Includes 35 to 35a1ab | 1 |
| 2 | 390402200 | Pop Rivet 3/16" | 2 |
| 1 | 705207588 | Deep Black, Front Bumper | 1 |
| 4 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 4 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 1 | 705209388 | Module Support | 1 |
| 3 | 207682044 | Hex. Flange Screw M8 X 20 | 3 |
| 3 | 233281416 | Hex. Elastic Flange Nut M8 | 3 |
| 1 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 1 |
| 1 | 705208741 | Power Steering Support | 1 |
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 1 | 207682044 | Hex. Flange Screw M8 X 20 | 1 |
| 1 | 705209190 | Steering Column Support Includes 90 to 90d | 1 |
| 4 | 250100199 | Insert Half Hex Body M6 x 1.0 | 4 |
| 1 | 705208742 | Support | 1 |
| 1 | 250100199 | Insert Half Hex Body M6 x 1.0 | 1 |
| 2 | 250100199 | Insert Half Hex Body M6 x 1.0 | 2 |
| 6 | 250100199 | Insert Half Hex Body M6 x 1.0 | 6 |
| 1 | 705014849 | Heat Shield | 1 |
| 1 | 707002709 | Heat Shield | 1 |
| 5 | 293150103 | Pop Rivet 3/16" | 5 |
| 1 | 708200976 | Bumper Ass'y Kit Includes 390 to 390d | 1 |
| 2 | 250000886 | Torx Screw M8 X 30 | 2 |
| 2 | 250001106 | Torx Truss M/S M8 x X 100 | 2 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 2 | 705207754 | Spacer | 2 |
| 1 | 715005754 | Deep Black, Front Bumper | 1 |
| 2 | 705202455 | Cap | 2 |
| 1 | 705207753 | Rear Chassis Reinforcement | 1 |
| 6 | 293150104 | Pop Rivet 3/16" | 6 |
| 1 | 710007523 | Voltage Regulator Support | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 1 |
| 2 | 705208203 | Spacer | 2 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 1 | 705210679 | Rear Chassis Extension Includes 1000 to 1000a29 | 1 |
| 18 | 390402200 | Pop Rivet 3/16" | 18 |
| 3 | 705207755 | Spacer | 3 |
| 3 | 250000892 | Screw Flange M12 X 135 | 3 |
| 5 | 250001195 | Elastic Flange Nut M12 | 5 |
| 2 | 250000876 | Hex. Flange Screw M12 X 95 | 2 |
| 4 | 293150174 | Hemlock Rivet, 6.4 mm | 4 |
| 1 | 705210673 | Upper Rear Differential Support | 1 |
| 4 | 233281416 | Hex. Elastic Flange Nut M8 | 4 |
| 4 | 207682544 | Hex. Flange Screw M8 X 25 | 4 |
| 1 | 705208867 | Rear Skid Plate | 1 |
| 2 | 708303134 | Rubber Stopper Includes 1250 to 1250a | 2 |
| 1 | 224060251 | Washer | 1 |
| 1 | 705015933 | Rear Solenoid Support | 1 |
| 2 | 293150103 | Pop Rivet 3/16" | 2 |
| 8 | 250000855 | Hex. Flange Screw M10 X 35 | 8 |
| 8 | 233201436 | Hex. Flange Elastic Nut M10 | 8 |
| 4 | 233201466 | Flange Elastic Nut M10 | 4 |
| 4 | 207606046 | Hex. Flange Screw M10 X 6 | 4 |
