Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 92000-06035 | BOLT, HEX. (6X35) | 1 |
| 40531-950-000 | COVER A, BRAKE DRUM | ||
| 40532-918-000B | COVER B, BRAKE DRUM *NH1* (BLACK) Use up to Frame SN 2000069 | ||
| 40532-943-000 | COVER B, BRAKE DRUM Use from Frame SN 2000070 | ||
| 40533-918-000 | GASKET, BRAKE DRUM COVER Use up to Frame SN 2000069 | ||
| 41710-950-010 | HOLDER, BEARING | ||
| 42622-950-000 | DRUM, RR. BRAKE | ||
| 2 | 43120-942-000 | SHOE, BRAKE | 2 |
| 2 | 43120-968-681 | SHOE, RR. BRAKE (ASK) (NA USE ALT:06430-HF1-911) | 2 |
| 2 | 43120-968-682 | SHOE, RR. BRAKE (JB) | 2 |
| 2 | 45120-303-690 | SHOE, FR. BRAKE | 2 |
| 43141-950-000 | CAM, RR. BRAKE | ||
| 2 | 43151-329-000 | SPRING, RR. BRAKE SHOE | 2 |
| 43410-950-000 | ARM, RR. BRAKE | ||
| 1 | 45134-250-000 | DUST SEAL, BRAKE CAM | 1 |
| 90526-216-000 | WASHER (14X26) Use up to Frame SN 2000250 | ||
| 90527-634-670 | WASHER (14X26) Use up to Frame SN 2000250 | ||
| 90527-634-670 | WASHER (14X26) | ||
| 91201-950-003 | OIL SEAL (35X55X8) (ARAI) | ||
| 91203-918-015 | DUST SEAL (40X62X7) | ||
| 6 | 92000-06008-0A | BOLT, HEX. (6X8) Use from Frame SN 2000070 | 6 |
| 6 | 92000-06010 | BOLT, HEX. (6X10) Use up to Frame SN 2000069 | 6 |
| 6 | 92101-06008-0A | BOLT, HEX. (6X8) Use from Frame SN 2000070 | 6 |
| 6 | 92101-06010-0A | BOLT, HEX. (6X10) Use up to Frame SN 2000069 | 6 |
| 4 | 92000-06012 | BOLT, HEX. (6X12) | 4 |
| 4 | 92101-06012 | BOLT, HEX. (6X12) | 4 |
| 4 | 92101-06012-0A | BOLT, HEX. (6X12) | 4 |
| 1 | 92000-06035-0A | BOLT, HEX. (6X35) | 1 |
| 1 | 92101-06035-0A | BOLT, HEX. (6X35) | 1 |
| 2 | 92000-08032-0A | BOLT, HEX. (8X32) | 2 |
| 2 | 92000-08032-0B | BOLT, HEX. (8X32) | 2 |
| 2 | 92101-08032-0B | BOLT, HEX. (8X32) | 2 |
| 1 | 90310-KA3-711 | NUT, HEX. (6MM) Use up to Frame SN 2000069 | 1 |
| 1 | 94000-06000-0S | NUT, HEX. (6MM) Use up to Frame SN 2000069 | 1 |
| 1 | 94001-06000 | NUT, HEX. (6MM) Use up to Frame SN 2000069 | 1 |
| 1 | 94001-06000-0S | NUT, HEX. (6MM) Use up to Frame SN 2000069 | 1 |
| 1 | 94001-06000-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06008-0S | NUT, HEX. (6MM) Use up to Frame SN 2000069 | 1 |
| 1 | 94001-06200-0S | NUT, HEX. (6MM) Use up to Frame SN 2000069 | 1 |
| 1 | 94001-06200-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94030-06000 | NUT, HEX. (6MM) Use up to Frame SN 2000069 | 1 |
| 12 | 94101-06000 | WASHER, PLAIN (6MM) Use up to Frame SN 2000069 | 12 |
| 6 | 94101-06000 | WASHER, PLAIN (6MM) Use from Frame SN 2000070 | 6 |
| 12 | 94101-06080 | WASHER, PLAIN (6MM) Use up to Frame SN 2000069 | 12 |
| 6 | 94101-06080 | WASHER, PLAIN (6MM) Use from Frame SN 2000070 | 6 |
| 12 | 94101-06800 | WASHER, PLAIN (6MM) Use up to Frame SN 2000069 | 12 |
| 6 | 94101-06800 | WASHER, PLAIN (6MM) Use from Frame SN 2000070 | 6 |
| 2 | 94101-08000 | WASHER, PLAIN (8MM) | 2 |
| 4 | 94111-06000 | WASHER, SPRING (6MM) Use up to Frame SN 2000069 | 4 |
| 10 | 94111-06000 | WASHER, SPRING (6MM) Use from Frame SN 2000070 | 10 |
| 2 | 94111-08000 | WASHER, SPRING (8MM) | 2 |
| 96100-60070-10 | BEARING, RADIAL BALL (6007) |
