Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 15772-292-010 | CLIP, BREATHER TUBE | 2 |
| 17211-405-000 | ELEMENT, AIR CLEANER | ||
| 17215-392-000 | STAY, R. AIR CLEANER HOUSING | ||
| 17215-393-000 | GROMMET, SOLENOID PIPE | ||
| 17215-393-780 | CLIP, AIR VENT TUBE | ||
| 17216-392-000 | STAY, L. AIR CLEANER HOUSING | ||
| 17217-392-000 | PLATE, R. AIR CLEANER HOUSING | ||
| 17218-392-000 | PLATE, L. AIR CLEANER HOUSING | ||
| 17219-392-000 | RUBBER, AIR CLEANER HOUSING MOUNT | ||
| 17220-300-010 | COLLAR, AIR CLEANER HOUSING MOUNT | ||
| 17230-405-305 | SEPARATOR, AIR CLEANER HOUSING | ||
| 17231-392-000 | COVER, AIR CLEANER | ||
| 17237-392-000 | COLLAR, AIR CLEANER HOUSING | ||
| 17238-392-000 | NUT A, AIR CLEANER COVER | ||
| 17239-392-000 | NUT B, AIR CLEANER COVER | ||
| 17240-393-771 | HOUSING, AIR CLEANER | ||
| 17253-393-770 | TUBE, AIR CLEANER CONNECTING | ||
| 4 | 17255-230-000 | BAND, AIR CLEANER CONNECTING TUBE | 4 |
| 17266-393-780 | STAY, BREATHER SEPARATOR | ||
| 17361-405-770 | BODY, CONDENSATION CHAMBER | ||
| 17363-405-770 | HOLDER, ELEMENT | ||
| 17364-405-000 | ELEMENT A, CONDENSATION | ||
| 17366-393-780 | CAP, BREATHER SEPARATOR | ||
| 90143-392-000 | BOLT, AIR CLEANER COVER | ||
| 90182-393-780 | TUBE A, BREATHER | ||
| 1 | 91305-405-770 | O-RING (62X2.5) | 1 |
| 1 | 91311-881-003 | O-RING (62X2.5) | 1 |
| 91462-393-780 | CLIP, TUBE | ||
| 1 | 91463-393-780 | JOINT, TUBE | 1 |
| 91464-393-780 | TUBE (11X70) | ||
| 91467-393-780 | TUBE (11X400) | ||
| 1 | 92000-06012 | BOLT, HEX. (6X12) | 1 |
| 1 | 92101-06012 | BOLT, HEX. (6X12) | 1 |
| 1 | 92101-06012-0A | BOLT, HEX. (6X12) | 1 |
| 2 | 92000-06016 | BOLT, HEX. (6X16) | 2 |
| 2 | 92000-06016-0A | BOLT, HEX. (6X16) | 2 |
| 2 | 92000-06016-1A | BOLT, HEX. (6X16) | 2 |
| 2 | 92100-06016-0A | BOLT, HEX. (6X16) | 2 |
| 2 | 92101-06016-0A | BOLT, HEX. (6X16) | 2 |
| 2 | 92200-06016-0A | BOLT, HEX. (6X16) | 2 |
| 4 | 93500-04020-0A | SCREW, PAN (4X20) | 4 |
| 2 | 93500-06020 | SCREW, PAN (6X20) | 2 |
| 2 | 93500-06020-0A | SCREW, PAN (6X20) | 2 |
| 2 | 93500-06080 | SCREW, PAN (6X80) | 2 |
| 2 | 93500-06080-0A | SCREW, PAN (6X80) | 2 |
| 93891-04020-00 | SCREW-WASHER (4X20) | ||
| 4 | 94001-04000 | NUT, HEX. (4MM) | 4 |
| 4 | 94001-04000-0S | NUT, HEX. (4MM) | 4 |
| 2 | 90310-KA3-711 | NUT, HEX. (6MM) | 2 |
| 2 | 94000-06000-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06000 | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06000-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06008-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06200-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94030-06000 | NUT, HEX. (6MM) | 2 |
| 4 | 94101-04000 | WASHER, PLAIN (4MM) | 4 |
| 5 | 94101-06000 | WASHER, PLAIN (6MM) | 5 |
| 5 | 94101-06080 | WASHER, PLAIN (6MM) | 5 |
| 5 | 94101-06800 | WASHER, PLAIN (6MM) | 5 |
| 2 | 94111-06000 | WASHER, SPRING (6MM) | 2 |
| 2 | 95001-35003-60M | BULK HOSE, FUEL (3.5X3000) (3.5X170) | 2 |
| 1 | 95002-01160 | CLIP, TUBE (A16) | 1 |
| 2 | 95002-02070 | CLIP, TUBE (B7) | 2 |
| 1 | 95700-06012-00 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95701-06012-00 | BOLT, FLANGE (6X12) | 1 |
