Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 204470913 | Buzzer Ass'y Includes 1 to 4 | 1 |
| 2 | 278000222 | Male Terminal | 2 |
| 2 | 278000218 | Wire Seal | 2 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 278000707 | Buzzer Nut | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 278001734 | Emergency Switch | 1 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 3 | 278000218 | Wire Seal | 3 |
| 3 | 278000223 | Female Terminal | 3 |
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 278001543 | Safety Lanyard | 1 |
| 278000621 | IGNITION SWITCH | ||
| 278000565 | IGNITION SWITCH CAP, RED | ||
| 1 | 204100027 | FLAT WASHER | 1 |
| 204470011 | VENTILATION SWITCH ASS'Y Includes 16 to 17 | ||
| 204470132 | Gasket | ||
| 204470974 | Bilge Pump Switch Ass'y Includes 18 to 19 | ||
| 204470975 | Navigation Light Switch Ass'y Includes 20 to 21 | ||
| 204470976 | HORN SWITCH ASS'Y Includes 22 to 23 | ||
| 1 | 204470977 | COURTESY LIGHT SWITCH ASS'Y Includes 24 to 25 | 1 |
| 204471047 | Inlet Clearance System Switch Ass'y Includes 26 to 27 | ||
| 1 | 204470907 | Receptacle, 12 Volt | 1 |
| 204470985 | Fuel Gauge | ||
| 204470986 | Speedometer Gauge | ||
| 204470988 | Tachometer Gauge | ||
| 204470989 | Engine Warning Gauge | ||
| 1 | 204470072 | FRONT LAMP SUPPORT | 1 |
| 209642560 | PHILLIPS SCREW M4.2 X 25 | ||
| 204470372 | Front Lamp | ||
| 3 | 204470026 | Courtesy Light Ass'y Includes 36 to 37 | 3 |
| 1 | 204470081 | BULB | 1 |
| 12 | 293150032 | RIVET_POP 1/8 X ,487 | 12 |
| 204470990 | REAR LIGHT BASE | ||
| 1 | 204470980 | REAR LIGHT HARNESS Includes 40 to 43 | 1 |
| 202000435 | Connector With Heat Shrink | ||
| 3 | 209943260 | Phillips Tapping Screw M4.2 X 32 | 3 |
| 2 | 293750002 | Tie Wrap 142 mm | 2 |
| 1 | 204470979 | REAR LIGHT POLE | 1 |
| 204470801 | HORN | ||
| 2 | 209943260 | Phillips Tapping Screw M4.2 X 32 | 2 |
| 204471056 | Stereo Compact Disk Player/radio | ||
| 204470930 | Stereo Adaptor Harness | ||
| 1 | 204471010 | STEREO TRIM RING | 1 |
| 1 | 204470981 | RADIO SUPPORT | 1 |
| 1 | 208462060 | PHILLIPS SCREW M6 X 20 | 1 |
| 1 | 234062600 | Flat Washer M6, Stainless | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 2 | 204130098 | TIE RAP WITH DART | 2 |
| 204470931 | Antenna | ||
| 1 | 204470987 | GAUGE CAP | 1 |
| 204471059 | Speaker, White | ||
| 2 | 204470982 | SPEAKER COVER ASS'Y | 2 |
| 204470949 | Fascia Ass'y | ||
| 209941960 | PHILLIPS SCREW M4.2 X 19 |
