Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 24741-21A00 | RETAINER, SEC DRIVE SFT BRG | 2 |
| 2 | 02112-06123 | SCREW, SEC DRIVE SFT BRG RTNR MODEL W | 2 |
| 2 | 09125-06110 | SCREW, SEC DRIVE SFT BRG RTNR MODEL X/Y | 2 |
| 2 | 02112-06123 | SCREW, CNTR SHAFT BRG RTNR MODEL W | 2 |
| 2 | 09125-06110 | SCREW, CNTR SHAFT BRG RTNR MODEL X/Y | 2 |
| 08211-06165 | RETAINER, CNTR SHAFT BRG | ||
| 1 | 24911-44D10 | GEAR, SEC DRIVE BEVEL NT:15 | 1 |
| 1 | 24935-19810 | SHIM SET, SEC DRIVE BEVEL GR T:0.25/0.30/0.35/0.90/1.00/ 1.05/1.10/1.15 | 1 |
| 1 | 09140-20012 | NUT, SEC DRIVE BEVEL GR | 1 |
| 1 | 09164-20007 | WASHER 20.1X32X2 | 1 |
| 1 | 24921-44D10 | GEAR, SEC DRIVEN BEVEL (NT:17 | 1 |
| 24960-44D50 | SHAFT, SEC DRIVEN,FR MODEL W | ||
| 24960-44D60 | SHAFT, SEC DRIVEN,FR MODEL X/Y | ||
| 24971-44D50 | SHAFT, SEC DRIVEN OUTPUT RR | ||
| 27140-44D00 | FLANGE, RR OUTPUT JOINT MODEL W | ||
| 27140-44D10 | FLANGE, RR OUTPUT JOINT MODEL X/Y | ||
| 1 | 27200-44D00 | JOINT ASSY, REAR OUTPUT Includes Item(s) 13A - 13F | 1 |
| 1 | 27201-44D00 | BOOT SET, JOINT | 1 |
| 1 | 27214-44D00 | RING, SNAP | 1 |
| 1 | 44121-60DB0 | BAND | 1 |
| 1 | 27213-44D00 | BOOT | 1 |
| 1 | 44124-60DB0 | BAND | 1 |
| 1 | 27215-44D00 | SEAL PLATE | 1 |
| 1 | 09159-16003 | NUT, REAR OUTPUT JOINT | 1 |
| 1 | 09159-22005 | NUT, SEC DRIVEN GEAR | 1 |
| 1 | 09160-16026 | WASHER, REAR OUTPUT FRANGE 16X30X3 | 1 |
| 1 | 09181-25051 | SHIM, SEC DRIVEN 25X34X0.6 | 1 |
| 1 | 09181-25052 | SHIM, SEC DRIVEN 25X34X0.65 | 1 |
| 1 | 09181-25053 | SHIM, SEC DRIVEN 25X34X0.70 | 1 |
| 1 | 09181-25054 | SHIM, SEC DRIVEN 25X34X0.75 | 1 |
| 1 | 09181-25055 | SHIM, SEC DRIVEN 25X34X0.80 | 1 |
| 1 | 09181-25056 | SHIM, SEC DRIVEN 25X34X0.85 | 1 |
| 1 | 09181-25057 | SHIM, SEC DRIVEN 25X34X0.90 | 1 |
| 1 | 09181-25058 | SHIM, SEC DRIVEN 25X34X0.95 | 1 |
| 1 | 09181-25059 | SHIM, SEC DRIVEN 25X34X1.00 | 1 |
| 1 | 09181-25060 | SHIM, SEC DRIVEN 25X34X1.05 | 1 |
| 1 | 09181-25061 | SHIM, SEC DRIVEN 25X34X1.10 | 1 |
| 1 | 09181-25062 | SHIM, SEC DRIVEN 25X34X1.15 | 1 |
| 1 | 09181-25063 | SHIM, SEC DRIVEN 25X34X1.20 | 1 |
| 1 | 09263-30010 | BRG, SEC DRIVEN GEAR,M 30X50X17 | 1 |
| 1 | 09267-25006 | BRG, SEC DRIVEN OUTPUT SFT FR 25X52X20.6 | 1 |
| 1 | 09267-25006 | BRG, SEC DRIVEN OUTPUT SFT RR 25X52X20.6 | 1 |
| 1 | 09283-34008 | OIL SEAL, DRIVEN SFT,FR 34X52X9 | 1 |
| 1 | 09283-34008 | OIL SEAL, DRIVEN SFT,RR 34X52X9 | 1 |
| 1 | 09390-50002 | RING, SEC DRIVEN BRG,M | 1 |
| 4 | 07130-08163 | BOLT, RR OUTPUT JOINT MODEL W | 4 |
| 4 | 09106-08095 | BOLT, RR OUTPUT JOINT MODEL X/Y | 4 |
| 1 | 08211-22365 | WASHER, SEC DRIVEN | 1 |
| 1 | 26441-19B01 | HOUSING, ODOMETER GEAR | 1 |
| 1 | 26442-19B00 | SLEEVE | 1 |
| 1 | 26451-19B12 | GASKET | 1 |
| 26461-44D00 | GEAR, DRIVE | ||
| 26471-44D00 | GEAR, DRIVEN | ||
| 26481-19B00 | SPACER, DRIVEN GEAR | ||
| 1 | 09135-06013 | BOLT, GEAR | 1 |
| 1 | 09168-06004 | WASHER, DRIVEN 6.2X11X1.2 | 1 |
| 1 | 09280-17004 | O RING (D:1.9,ID:16.6) ID:16.6,DD:1.9 | 1 |
| 1 | 09289-05002 | SEAL, DRIVEN GEAR | 1 |
| 2 | 09103-06201 | BOLT, GEAR SLV | 2 |
| 1 | 08211-08151 | WASHER, DRIVEN GR | 1 |
| 1 | 08211-15201 | WASHER, DRIVE GR | 1 |
| 1 | 08211-17241 | WASHER, DRIVE GR,RH | 1 |
| 1 | 27130-19B00 | YOKE, FR DRIVE OUTPUT Includes Item(s) 41 - 44 | 1 |
| 1 | 27591-19B01 | COLLAR, YOKE | 1 |
| 1 | 27592-19B00 | PLATE, YOKE COLLAR | 1 |
| 09165-30003 | PLATE, YOKE COLLAR | ||
| 1 | 09280-28007 | O RING, YOKE COLLAR ID:28,DD:1.0 | 1 |
| 27140-19B00 | YOKE, PROP SFT JOINT | ||
| 27150-44D00 | SHAFT, PROPELLER MODEL W | ||
| 27150-44D20 | SHAFT, PROPELLER MODEL X/Y | ||
| 1 | 27153-62021 | BOOT, PROP SHAFT | 1 |
| 1 | 27200-73813 | JOINT SET, UNIVERSAL Includes Item(s) 49 | 1 |
| 4 | 09380-25005 | CIRCLIP | 4 |
| 1 | 09159-16003 | NUT, FR YOKE | 1 |
| 1 | 09160-16026 | WASHER, FR DRIVE OUTPUT YOKE 16X30X3 | 1 |
