Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 94510-19C00 | BRACE, COWLING | ||
| 94510-19C10 | BRACE, COWLING CALIFORNIA ONLY | ||
| 1 | 01517-08205 | BOLT | 1 |
| 2 | 01517-06125 | BOLT | 2 |
| 2 | 02142-06127 | SCREW | 2 |
| 94520-19C00 | PLATE, METER | ||
| 4 | 02142-06125 | SCREW | 4 |
| 94420-19C00 | COVER, METER (BLACK) | ||
| 2 | 94635-19C10 | MOLDING | 2 |
| 4 | 03541-05085 | SCREW | 4 |
| 1 | 94527-19C00 | MOLDING, METER | 1 |
| 94426-19C00 | CUSHION, COVER | ||
| 94610-19C10 | WINDOW | ||
| 1 | 94631-19C00 | MOLDING (L:525) | 1 |
| 94637-19C00 | CAP | ||
| 4 | 09139-05022 | SCREW | 4 |
| 4 | 09161-05010 | WASHER (5.2X11.0X1.0) | 4 |
| 94460-19C00 | PLATE, CENTER | ||
| 2 | 09136-06081 | SCREW | 2 |
| 2 | 09180-06167 | SPACER | 2 |
| 2 | 09320-10015 | CUSHION (10X20X10) | 2 |
| 1 | 94638-19C00 | CUSHION, SCREEN | 1 |
| 94421-19C01-28V | PANEL, CENTER (RED) | ||
| 94421-19C01-33J | PANEL, CENTER (BLACK) | ||
| 2 | 02142-05128 | SCREW | 2 |
| 94401-43C10-28V | COVER ASSY, COWLING, RH (RED) | ||
| 94401-43C10-33J | COVER ASSY, COWLING, RH (BLACK) | ||
| 68681-19C20-0WR | EMBLEM, KATANA FOR 28V | ||
| 68681-19C20-0WS | EMBLEM, KATANA FOR 33J | ||
| 94631-19C10 | MOLDING | ||
| 1 | 94635-19C00 | MOLDING | 1 |
| 94438-19C00 | JOINT | ||
| 94435-19C01-28V | LID, OIL (RED) | ||
| 94435-19C01-33J | LID, OIL (BLACK) | ||
| 1 | 09139-06030 | SCREW | 1 |
| 94433-19C01-28V | COVER, METER RH (RED) WITH OUT DRAWING | ||
| 94433-19C01-33J | COVER, METER RH (BLACK) WITH OUT DRAWING | ||
| 2 | 03541-04105 | SCREW WITH OUT DRAWING | 2 |
| 94402-43C10-28V | COVER ASSY, COWLING, LH (RED) | ||
| 94402-43C10-33J | COVER ASSY, COWLING, LH (BLACK) | ||
| 94402-43C20-28V | COVER ASSY, COWLING, LH (RED) CALIFORNIA ONLY | ||
| 94402-43C20-33J | COVER ASSY, COWLING, LH (BLACK) CALIFORNIA ONLY | ||
| 68691-19C00-0WR | EMBLEM, KATANA CALIFORNIA ONLY FOR 28V | ||
| 68691-19C00-0WS | EMBLEM, KATANA CALIFORNIA ONLY FOR 33J | ||
| 94443-19C01-28V | COVER, METER LH (RED) WITH OUT DRAWING | ||
| 94443-19C01-33J | COVER, METER LH (BLACK) WITH OUT DRAWING | ||
| 2 | 09139-06029 | SCREW, FRONT | 2 |
| 2 | 09160-06036 | WASHER | 2 |
| 2 | 09139-06030 | SCREW, UPPER | 2 |
| 2 | 09161-06021 | WASHER | 2 |
| 94560-19C00 | BRACKET, UPPER, RH | ||
| 94570-19C00 | BRACKET, UPPER, LH | ||
| 4 | 09125-06055 | SCREW | 4 |
| 94573-19C00 | NUT | ||
| 4 | 09139-06029 | SCREW | 4 |
| 4 | 09160-06036 | WASHER | 4 |
| 4 | 09180-06011 | SPACER | 4 |
| 4 | 09320-09016 | CUSHION | 4 |
| 94471-19C00-20G | COVER, UNDER, RH (GRAY) FOR 28V | ||
| 94471-19C00-24K | COVER, UNDER, RH (CHARCOAL) FOR 33J | ||
| 94481-19C00-20G | COVER, UNDER, LH (GRAY) FOR 28V | ||
| 94481-19C00-24K | COVER, UNDER, LH (CHARCOAL) FOR 33J | ||
| 2 | 09139-06042 | SCREW, FRONT | 2 |
| 94531-19C00 | BRACKET, UNDER, RH | ||
| 94532-19C00 | BRACKET, UNDER, LH | ||
| 94590-19C00 | NUT | ||
| 2 | 01137-06165 | BOLT | 2 |
| 2 | 09139-05025 | SCREW (5X14) | 2 |
| 2 | 09161-05017 | WASHER | 2 |
| 2 | 94484-32B00 | NUT | 2 |
| 2 | 09139-06029 | SCREW, REAR | 2 |
| 2 | 09180-06097 | SPACER | 2 |
| 2 | 09320-09016 | CUSHION | 2 |
| 2 | 09136-06081 | SCREW, LOWER | 2 |
| 2 | 09180-06011 | SPACER | 2 |
| 2 | 02142-15165 | SCREW, LOWER | 2 |
| 94580-19C00 | BRACKET, LOWER | ||
| 3 | 02142-05164 | SCREW | 3 |
| 3 | 09161-05017 | WASHER | 3 |
| 94475-19C01 | COVER, UNDER, FRONT (BLACK) | ||
| 1 | 68612-48B00 | LABEL, SCREEN | 1 |
| 1 | 68319-40C00 | LABEL, WARNING | 1 |
