Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13201-43C10 | CARBURETOR ASSY, LH | ||
| 13201-43C20 | CARBURETOR ASSY, LH CALIFORNIA ONLY | ||
| 13202-43C10 | CARBURETOR ASSY, ML | ||
| 13202-43C20 | CARBURETOR ASSY, ML CALIFORNIA ONLY | ||
| 13203-43C10 | CARBURETOR ASSY, MR | ||
| 13203-43C20 | CARBURETOR ASSY, MR CALIFORNIA ONLY | ||
| 13204-43C10 | CARBURETOR ASSY, RH | ||
| 13204-43C20 | CARBURETOR ASSY, RH CALIFORNIA ONLY | ||
| 13500-19C00 | DIAPHRAGM ASSY | ||
| 4 | 13394-10010 | E RING | 4 |
| 4 | 13382-42A00 | RING | 4 |
| 4 | 13387-47010 | RING | 4 |
| 13417-26B00 | SPRING | ||
| 13383-19C20 | NEEDLE, JET (4CZ4-1) | ||
| 13383-19C30 | NEEDLE, JET (4CZ5-1) CALIFORNIA ONLY | ||
| 08310-21086 | NUT ML, MR | ||
| 13606-47070 | WASHER ML, MR | ||
| 13573-28A10 | SPRING LH, ML | ||
| 13550-28A30 | SHAFT ASSY LH | ||
| 13550-28A00 | SHAFT ASSY ML | ||
| 13553-28A00 | LEVER ML | ||
| 13555-28A00 | LEVER MR | ||
| 13573-28A00 | SPRING MR | ||
| 13573-28A20 | SPRING RH | ||
| 13550-28A20 | SHAFT ASSY RH | ||
| 8 | 13651-51010 | SEAL | 8 |
| 2 | 13617-44080 | E RING LH, RH | 2 |
| 4 | 13557-47070 | WASHER | 4 |
| 13582-95216 | NUT ML | ||
| 13267-52012 | SCREW LH, ML, RH | ||
| 4 | 13605-73000 | SCREW | 4 |
| 8 | 13604-42A00 | SCREW | 8 |
| 13551-42A30 | VALVE, THROTTLE (130) | ||
| 4 | 13251-42A00 | .O RING,FLOAT CHAMBER | 4 |
| 4 | 13249-78100 | WASHER | 4 |
| 4 | 09492-32006 | JET, PILOT (32.5) | 4 |
| 4 | 09492-35010 | JET, PILOT (37.5) CALIFORNIA ONLY | 4 |
| 09494-00624 | JET, NEEDLE (P-8) | ||
| 4 | 13332-44080 | WASHER | 4 |
| 2 | 09491-27010 | JET, MAIN (137.5) LH, RH | 2 |
| 2 | 09491-27009 | JET, MAIN (135) ML, MR | 2 |
| 13247-24500 | SCREW, DRAIN LH | ||
| 2 | 13247-38B00 | SCREW, DRAIN ML, MR | 2 |
| 1 | 13247-19C00 | SCREW, DRAIN RH | 1 |
| 4 | 13250-28A00 | FLOAT | 4 |
| 4 | 13602-43410 | SCREW | 4 |
| 4 | 13254-92311 | PIN | 4 |
| 4 | 13370-44500 | .NEEDLE VALVE | 4 |
| 4 | 13374-44080 | O-RING | 4 |
| 4 | 13376-84110 | FILTER | 4 |
| 15 | 02112-04085 | SCREW LH, ML, MR:4, RH:3 | 15 |
| 1 | 13602-38A20 | SCREW RH | 1 |
| 13271-28A00 | SPRING LH, RH | ||
| 3 | 13268-96110 | SPRING LH, ML, RH | 3 |
| 4 | 09493-30005 | JET, PILOT AIR (155) | 4 |
| 09493-30003 | JET, PILOT AIR (150) CALIFORNIA ONLY | ||
| 14 | 13602-27A10 | SCREW LH, ML:3, MR, RH:4 | 14 |
| 13550-28A10 | SHAFT ASSY MR | ||
| 13574-28A00 | RING MR | ||
| 13502-28A00 | COVER, DIAPHRAGM | ||
| 4 | 13682-31210 | .CAP,STARTER VALVE | 4 |
| 2 | 13602-19C00 | SCREW LH, ML | 2 |
| 1 | 13692-02500 | CLIP ML | 1 |
| 4 | 13418-44080 | .HOLDER,GUIDE | 4 |
| 4 | 13417-43010 | .SPRING,STARTER VALVE | 4 |
| 4 | 13411-05320 | PLUNGER ASSY | 4 |
| 13692-19C00 | CLIP LH | ||
| 13692-43C00 | CLIP ML | ||
| 1 | 13671-05A20 | CLAMP RH | 1 |
| 13671-48B00 | CLIP MR | ||
| 13586-48B00 | SHAFT, STARTER | ||
| 13605-49330 | SCREW | ||
| 13422-28A00 | LEVER | ||
| 13628-19C00 | PLATE | ||
| 14 | 02112-05128 | SCREW | 14 |
| 13628-19C10 | PLATE | ||
| 09126-05005 | SCREW (5X14) | ||
| 2 | 13683-49160 | HOSE (6.5X10.5X400) L:400->18 | 2 |
| 2 | 13684-22A00 | HOSE (5X8X550) L:550->400 | 2 |
| 13680-27A00 | HOSE ASSY (3X5X18) | ||
| 13680-28A00 | HOSE ASSY | ||
| 13605-34390 | SCREW | ||
| 13684-43440 | HOSE (16X19X100) L:100->30 | ||
| 1 | 13683-05A30 | HOSE (5X9X325) | 1 |
| 1 | 13687-17C00 | HOSE (5X9X175) CALIFORNIA ONLY | 1 |
| 13271-28A10 | SPRING | ||
| 1 | 13432-47090 | WASHER | 1 |
| 13267-43C00 | ADJUSTER | ||
| 1 | 13671-05A30 | CLIP OTHER THAN CALIFORNIA | 1 |
| 13422-48B00 | LEVER | ||
| 13684-19C00 | HOSE (10X14X225) | ||
| 13684-19C20 | HOSE (10X14X90) CALIFORNIA ONLY | ||
| 1 | 13671-33600 | CLIP CALIFORNIA ONLY | 1 |
| 1 | 13685-48B00 | NIPPLE CALIFORNIA ONLY | 1 |
| 13684-19C10 | HOSE (10X14X175) CALIFORNIA ONLY | ||
| 13683-19C20 | HOSE (5X8X200) CALIFORNIA ONLY |
