Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 11012-1985 | CAP | 2 |
| 11051-1756 | BRACKET | ||
| 11052-1258 | BRACKET | ||
| 1 | 11052-1369 | BRACKET | 1 |
| 1 | 11052-1575 | BRACKET,FRONT GEAR CA | 1 |
| 1 | 11065-1053-6Z | CAP,F.BLACK | 1 |
| 1 | 13070-1367 | GUIDE,LH | 1 |
| 1 | 13070-1368 | GUIDE,RH | 1 |
| 2 | 13271-1800 | PLATE | 2 |
| 1 | 13320-1016 | LEVER-ASSY | 1 |
| 1 | 14024-1792 | COVER,BATTERY | 1 |
| 14090-1247 | UNDER COVER,SEAT | ||
| 1 | 14091-0118 | COVER,FLOOR,CNT | 1 |
| 1 | 14091-1228-AZ | COVER,GRAY | 1 |
| 1 | 14091-1378 | COVER,FLOOR | 1 |
| 1 | 14091-1399-AZ | COVER,GRAY | 1 |
| 2 | 21083-1146 | ARM | 2 |
| 1 | 21083-1163 | ARM | 1 |
| 1 | 21083-1172 | ARM | 1 |
| 1 | 21187-1085 | ARM-ASSY | 1 |
| 1 | 23016-1188 | LAMP-ASSY,INDICATOR | 1 |
| 1 | 23016-1189 | LAMP-ASSY | 1 |
| 4 | 27012-1577 | HOOK | 4 |
| 1 | 27012-1607 | HOOK | 1 |
| 1 | 27012-1608 | HOOK | 1 |
| 1 | 27012-1612 | HOOK | 1 |
| 1 | 35004-0007-260 | FENDER-FRONT,A.RED | 1 |
| 1 | 35004-0007-6A | FENDER-FRONT,H.GREEN | 1 |
| 1 | 35063-1203 | STAY,FR FENDER | 1 |
| 39012-1061-AZ | CASE-STORAGE,RH,GRAY | ||
| 1 | 39012-1062-AZ | CASE-STORAGE,LH,GRAY | 1 |
| 1 | 39012-1066 | CASE-STORAGE,CNT | 1 |
| 1 | 39145-1130 | TRIM-SEAL,L=774 | 1 |
| 1 | 39145-1132 | TRIM-SEAL,L=2805 | 1 |
| 1 | 39156-0014 | PAD,FRONT FENDER | 1 |
| 39156-1685 | PAD | ||
| 1 | 49006-1347 | BOOT | 1 |
| 59226-1060-AZ | PANEL-CONTROL,GRAY | ||
| 2 | 92001-1600 | BOLT,FLANGED,10X70 | 2 |
| 1 | 92001-1603 | BOLT,FLANGED,10X115 | 1 |
| 21 | 92009-1166 | SCREW,TAPPING,6X16 | 21 |
| 4 | 92009-1256 | SCREW,6X22,BLACK | 4 |
| 2 | 92009-1444 | SCREW,TAPPING,4X12 | 2 |
| 25 | 92009-1621 | SCREW,6X16 | 25 |
| 2 | 92015-1386 | NUT,FLANGED,6MM | 2 |
| 2 | 92015-1406 | NUT,FLANGED,8MM | 2 |
| 3 | 92015-1597 | NUT,LOCK,10MM | 3 |
| 2 | 92015-1603 | NUT,LOCK,FLANGED,6MM | 2 |
| 8 | 92015-1678 | NUT,CLAMP,6MM | 8 |
| 1 | 92022-1317 | WASHER,8.5X20X1.6,BLACK | 1 |
| 13 | 92022-1346 | WASHER,6.5X20X1.6,BLACK | 13 |
| 1 | 92022-1649 | WASHER,10.2X20X0.5 | 1 |
| 1 | 92022-239 | WASHER,10.5X20X1 | 1 |
| 1 | 92027-1518 | COLLAR,11X20X39 | 1 |
| 2 | 92039-1041 | RIVET | 2 |
| 6 | 92039-1229 | RIVET | 6 |
| 4 | 92039-1244 | RIVET | 4 |
| 2 | 92043-1625 | PIN,6X39 | 2 |
| 2 | 92043-1626 | PIN,6X9 | 2 |
| 2 | 92043-1627 | PIN,6X13 | 2 |
| 4 | 92066-1485 | PLUG | 4 |
| 2 | 92069-1020 | BULB,12V3W T-7 | 2 |
| 2 | 92071-019 | GROMMET HARNESS 10MM | 2 |
| 2 | 92072-1197 | BAND,L=365 | 2 |
| 4 | 92072-1252 | BAND | 4 |
| 1 | 92072-1399 | BAND,L=159 | 1 |
| 1 | 92075-1076 | DAMPER | 1 |
| 1 | 92075-1214 | DAMPER | 1 |
| 1 | 92093-1293 | SEAL,FRONT FENDER,LH | 1 |
| 3 | 130G1020 | BOLT-FLANGED,10X20 | 3 |
| 4 | 130J0616 | BOLT-FLANGED,6X16,BLACK | 4 |
| 2 | 130J0816 | BOLT-FLANGED,8X16,BLA | 2 |
| 2 | 221C0616 | SCREW-CSK-CROS | 2 |
| 2 | 224C0412 | SCREW-PAN-WP-CROS,4X1 | 2 |
| 2 | 311C0400 | NUT-HEX | 2 |
| 2 | 482L5000 | CIRCLIP-TYPE-E,5MM | 2 |
| 2 | 482L7000 | CIRCLIP-TYPE-E | 2 |
| 6 | 554A0600 | PIN-SNAP | 6 |
| 2 | 554A0800 | PIN-SNAP,8MM | 2 |
| 1 | 92093-1294 | SEAL,FRONT FENDER,RH | 1 |
| 2 | 92093-1295 | SEAL,LOWER COVER | 2 |
| 24 | 92143-1087 | COLLAR | 24 |
| 2 | 92144-1174 | SPRING,SEAT HOOK | 2 |
| 2 | 92145-1335 | SPRING | 2 |
| 1 | 92145-1402 | SPRING | 1 |
| 2 | 92151-1305 | BOLT,FLANGED,5X12 | 2 |
| 2 | 92151-1897 | BOLT,BATTERY | 2 |
| 2 | 92160-1148 | DAMPER | 2 |
| 2 | 92161-1197 | DAMPER | 2 |
| 2 | 92172-0002 | SCREW,6X18 | 2 |
| 4 | 92172-0003 | SCREW,TAPPING,6X12 | 4 |
| 4 | 92200-1567 | WASHER,8.5X26X0.8 | 4 |
| 2 | 92200-1592 | WASHER | 2 |
