Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 93003001100EB | Frame Duke 18 orange | 1 |
| 1 | 93003038000 | Footrest bracket front left | 1 |
| 2 | 93003048050 | Heel protector left | 2 |
| 1 | 93008020060 | Screw M6X1X9 | 1 |
| 1 | 93003140033 | Front footpeg cmpl. left | 1 |
| 2 | 90103040001 | PLAIN WASHER 6,4X12X1 | 2 |
| 2 | J029060103S | CAP SCREW M6X10 SS | 2 |
| 4 | 93003054000 | Pin footrest pivot black | 4 |
| 2 | 90103042000 | footrest return spring | 2 |
| 4 | J125080004 | WASHER M8 | 4 |
| 4 | J094018250 | PIN 25X1,8MM | 4 |
| 2 | 90103038001 | footrest support holder, front | 2 |
| 1 | 90104070000 | chainguide | 1 |
| 2 | 90104066010 | spacer chainguide | 2 |
| 1 | 93003048000 | Footrest bracket rear left | 1 |
| 4 | J770009015 | O-RING 9X1,5 | 4 |
| 1 | 93003150033 | Rear footpeg cmpl. left | 1 |
| 2 | 93003053000 | Plate lock pillion step bottom | 2 |
| 2 | 93003052000 | Plate lock pillion step top | 2 |
| 1 | 93003049000 | Footrest bracket rear right | 1 |
| 2 | J025060101 | Hexagon screw M6X10 | 2 |
| 1 | 93003151033 | Rear footpeg cmpl. right | 1 |
| 1 | 93005084000 | Retaining bracket | 1 |
| 1 | J025102656 | HH COLLAR SCREW M10X1,25X265 | 1 |
| 2 | J025100926 | HH COLLAR SCREW M10X1,25X92 | 2 |
| 1 | J025101103 | HH COLLAR SCREW M10X110 WS14 | 1 |
| 3 | 90103038002 | FLANGED NUT M10X1,25 WS14 | 3 |
| 1 | J027081053 | HH COLLAR SCREW M8X105 SW12 | 1 |
| 1 | 93303006000 | Engine brace right | 1 |
| 1 | 93303005000 | Engine brace left250/390 | 1 |
| 1 | 93003005100 | Nut socket-M10x1.25 | 1 |
| 2 | 93003049050 | Heel protector right | 2 |
| 4 | J125080006 | Washer M8 | 4 |
| 1 | 9300300200028 | Rear frame white | 1 |
| 1 | 93003141033 | Front footpeg cmpl. right | 1 |
| 1 | 93003039000 | Footrest bracket front right | 1 |
| 1 | 93003002050 | Bracket spider lh | 1 |
| 1 | 93003002151 | Bracket spider rh | 1 |
| 1 | 93003002030 | Bracket seat mount loose | 1 |
| 2 | 93007044000 | Retaining pin | 2 |
| 1 | 93003001070 | Seat cowl front complete | 1 |
| 2 | 93008023000 | Rubber buffer | 2 |
| 2 | 93007047033 | Seat support complete | 2 |
| 2 | J912080303 | hexagon socket screw M8X30 | 2 |
| 2 | 93007046050 | Screw | 2 |
| 4 | 93003002070 | hexagon socket screwM8X1.25X25 | 4 |
| 4 | 93003002080 | Washer Plain-ID8.2XOD 14XT 2 BLK | 4 |
| 4 | 90103098000 | BOLT | 4 |
| 1 | 93003056000 | Passenger footrest bracket | 1 |
| 2 | J912060143 | Hex socket screw M6X14 | 2 |
| 2 | 93008019070 | hexagon socket screw M8X31 | 2 |
| 2 | J125080002 | Washer plain | 2 |
| 1 | 93006040060 | Retaining bracket | 1 |
| 1 | J005050123 | FLAT HEAD SCREW M5X12 PH | 1 |
| 1 | 90111045050 | CABLE BRACKET | 1 |
| 2 | 90103032000 | FLANGED BOLT M6X14 | 2 |
| 1 | 93013041000 | Retaining bracket | 1 |
| 1 | J025060109 | HH-COLLAR SCREW M6X10 SW8 | 1 |
| 1 | 93013026000 | Support | 1 |
| 1 | J031050121 | Roundhead screw M4X12 | 1 |
| 1 | 93032059010 | Guide clutch cable | 1 |
| 1 | 90108050001 | CLIP NUT M5 | 1 |
| 1 | 93008043000 | Screw M6X1X25 | 1 |
| 1 | 90203008000 | BOLT M10X135 | 1 |
| 1 | J125100009 | Washer M10 | 1 |
| 2 | 90508026100 | Clip | 2 |
| 1 | J125140003 | Washer - plain | 1 |
| 4 | J912080251 | Hexagon screw M8X25 | 4 |
| 1 | 93008041060 | guard ih | 1 |
| 2 | J031060106 | SCREW BUTTON HEAD-M5X0.8XL 8XB | 2 |
