Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 204470913 | Buzzer Ass'y Includes 1 To 4 | 1 |
| 2 | 278000222 | Male Terminal | 2 |
| 2 | 278000218 | Wire Seal | 2 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 278000707 | Buzzer Nut | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 278001734 | Emergency Switch Includes 7 To 10 | 1 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 3 | 278000218 | Wire Seal | 3 |
| 3 | 278000223 | Female Terminal | 3 |
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 278001543 | Safety Lanyard | 1 |
| 278000621 | IGNITION SWITCH | ||
| 278000565 | IGNITION SWITCH CAP, RED | ||
| 4 | 204100027 | FLAT WASHER | 4 |
| 204470011 | VENTILATION SWITCH ASS'Y Includes 16 To 17 | ||
| 204470132 | Gasket | ||
| 204470099 | BILGE PUMP SWITCH ASS'Y Includes 18 To 19 | ||
| 1 | 204470100 | LIGHT SWITCH ASS'Y Includes 20 To 21 | 1 |
| 1 | 204470101 | HORN SWITCH ASS'Y Includes 22 To 23 | 1 |
| 204470102 | COURTESY LIGHT SWITCH ASS'Y Includes 24 To 25 | ||
| 1 | 204471048 | INLET CLEARANCE SYSTEM SWITCH, ICS Includes 26 To 27 | 1 |
| 204471055 | Fuel Gauge | ||
| 204470943 | Speedometer | ||
| 204471019 | Tachometer Gauge | ||
| 204470959 | ENGINE WARNING GAUGE | ||
| 1 | 204470894 | RADIO CD PLAYER COVER | 1 |
| 209642560 | PHILLIPS SCREW M4.2 X 25 | ||
| 204471056 | Stereo Compact Disk Player/radio Utopia 205 | ||
| 204471057 | Compact Disk Stereo Player/radio Utopia 205 SE | ||
| 204470930 | Stereo Adaptor Harness | ||
| 1 | 204470926 | 90 RADIO SUPPORT | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 204470931 | Antenna | ||
| 204471059 | Speaker, White | ||
| 2 | 204470982 | SPEAKER COVER ASS'Y | 2 |
| 204471009 | Dash Panel Ass'y Utopia 205, Includes 41 To 44 | ||
| 204471036 | Dash Panel Ass'y Utopia 205 SE, Includes 41 To 44 | ||
| 204000130 | Elevator Bolt | ||
| 1 | 204100089 | FLAT WASHER 9/32? | 1 |
| 211100026 | HEX. NUT 1/4 | ||
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 204470917 | DEPTH GAUGE Utopia 205 SE | 1 |
| 204470993 | Stereo Remote Cable Utopia 205 SE | ||
| 204471058 | Cd Player/radio Remote Control Utopia 205 SE | ||
| 204471084 | Ground Wire Utopia 205 SE | ||
| 204471085 | Back Light Wire Ass'y Utopia 205 SE | ||
| 204470995 | Power Wire Ass'y, Purple Utopia 205 SE | ||
| 1 | 204470918 | DEPTH SENSOR Utopia 205 SE | 1 |
