Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 204471071 | BRACKET | 2 |
| 6 | 293150037 | Avdel Rivet 3/16" | 6 |
| 204470906 | TWIN ENGINE INTERFACE Includes 3 To 8 | ||
| 278001618 | FUSE HOLDER COVER | ||
| 278001719 | COVER BUSHING | ||
| 278001196 | FUSE, 3 AMPERES | ||
| 2 | 278000344 | Fuse, 5 Amperes | 2 |
| 4 | 278001197 | Fuse, 10 Amperes | 4 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 2 | 232561600 | Hex. Elastic Stop Nut M6 | 2 |
| 204470770 | FUSE BLOCK Includes 11 To 17 | ||
| 2 | 278001442 | FUSE, 2 AMPERES | 2 |
| 10 | 278001197 | Fuse, 10 Amperes | 10 |
| 2 | 409003900 | Fuse, 20 Amperes | 2 |
| 2 | 410917200 | Fuse, 30 Amperes | 2 |
| 2 | 209641960 | PHILLIPS TAPPING SCREW M4.2 X 19 | 2 |
| 2 | 234041600 | Flat Washer 4 mm, Stainless | 2 |
| 278001969 | REGULATOR Includes 20 To 24 | ||
| 2 | 409207400 | Female Housing, 3 Circuits | 2 |
| 1 | 278000632 | Female Terminal | 1 |
| 2 | 278001674 | Mâle Terminal Housing, 2 Circuits | 2 |
| 1 | 515175568 | Male Terminal | 1 |
| 2 | 293250123 | SEAL | 2 |
| 208663060 | PHILLIPS SCREW M6 X 30 | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 6 | 207162060 | Hex. Forming Screw M6 X 20 | 6 |
| 6 | 234062600 | Flat Washer M6, Stainless | 6 |
| 6 | 232561600 | Hex. Elastic Stop Nut M6 | 6 |
| 204471027 | Accessory Harness | ||
| 204470811 | Engine Harness Starboard | ||
| 204470973 | Engine Harness Port Side | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 204471077 | SLIT CONDUIT | 1 |
| 4 | 293750002 | Tie Wrap 142 mm | 4 |
| 2 | 278001725 | Diagnostic Connect Cap | 2 |
| 2 | 278001802 | Relay Starter | 2 |
| 4 | 232561600 | Hex. Elastic Stop Nut M6 | 4 |
| 204470852 | Red Cable Port Side | ||
| 204470798 | RED CABLE Starboard | ||
| 1 | 204470853 | RED CABLE Port Side | 1 |
| 204470838 | RED CABLE Starboard | ||
| 2 | 204470108 | Fan Ass'y Includes 41 To 44 | 2 |
| 2 | 278000220 | Male Connector, 2 Circuits | 2 |
| 4 | 278000223 | Female Terminal | 4 |
| 4 | 278000218 | Wire Seal | 4 |
| 4 | 293150011 | Pop Rivet 3/16" | 4 |
| 4 | 234052600 | Flat Washer 5 mm, Stainless | 4 |
| 1 | 278001993 | Speed Sensor | 1 |
| 3 | 211000021 | PHILLIPS SCREW #10 X 7/8 | 3 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 1 | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| 204471072 | Bilge Pump | ||
| 293150029 | RIVET_POP 5/32 | ||
| 250000090 | TAPPING SCREW M4.2 X 19 | ||
| 2 | 278001016 | Temperature Sensor | 2 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
