Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 58031701244 | CARBURETTOR 45 / 45 / 165 / DR266 / KS1 IV | ||
| 58031601644 | CARBURETOR PHM 38 SD (140295) | ||
| 58031601844 | CARBURETTOR 45 / 45 / 190 / DR270 / K51 II | ||
| 58031601944 | CARBURETTOR 45 / 38 / 135 / DR266 / K51 II | ||
| 58031701044 | CARBURETTOR 45 / 45 / 170 / DR268/K51 III | ||
| 58031701144 | CARBURETTOR 45 / 45 / 140 / DR268/K51 III | ||
| 58031901644 | CARBURETTOR 45 / 45 / 155 / DR266 / K51 IV | ||
| 58031901544 | CARBURETTOR 45 / 45 / 195 / DR272 / K51 II | ||
| 58031901244 | CARBURETTOR 45 / 45 / 135 / DR268/K51 III | ||
| 58031901444 | CARBURETTOR 45 / 45 / 135 / DR268/K51 III | ||
| 58031901144 | CARBURETTOR 45 / 45 / 170 / DR268/K51 III | ||
| 58031135040 | THROTTLE VALVE N0.40 | ||
| 1 | 49031134051 | JET NEEDLE K51 | 1 |
| 58031121272 | NEEDLE JET DR 272 | ||
| 58031121270 | NEEDLE JET DR 270 (As Required) | ||
| 58031121268 | NEEDLE JET DR 268 | ||
| 58031121266 | NEEDLE JET DR 266 | ||
| 1 | 57031523200 | MAIN JET 200 | 1 |
| 57031523195 | MAIN JET 195 | ||
| 57031523190 | MAIN JET 190 (As Required) | ||
| 57031523170 | MAIN JET 170 | ||
| 57031523165 | MAIN JET 165 | ||
| 57031523160 | MAIN JET (As Required) | ||
| 57031523155 | MAIN JET 155 | ||
| 57031523140 | MAIN JET 140 | ||
| 57031523135 | MAIN JET | ||
| 15131123045 | JET 45 | ||
| 15131123038 | JET 38 | ||
| 49031122000 | IDLE MIXING TUBE NR.1 CD | ||
| 1 | 58031151045 | STARTING JET 45 400LC4/DUKE | 1 |
| 1 | 57231120300 | NEEDLE VALVE 300 | 1 |
| 57031509000 | GRAMM FLOAT (As Required) | ||
| 1 | 58331509000 | FLOAT | 1 |
| 58031140038 | CONNECT.AIR INTAKE 400 LC4 | ||
| 58031140040 | CONNECT.AIR INTAKE 620 LC4 | ||
| 52031138000 | RUBBER SLEEVE | ||
| 57031525100 | ADJUSTMENT SCREW M6X0,75 | ||
| 58031528000 | SUPPORT BUSHING SW=10 | ||
| 49031131000 | NIPPEL NIPPLE | ||
| 1 | 0799025055 | TAB WASHER DIN6799-RS 2,5 | 1 |
| 54431530000 | SLIDING SPRING 1,25X190 | ||
| 3 | 52031126000 | HEXAGON NUT M 6X0,75 DIN0439 | 3 |
| 57031524000 | HEXAGON NUT M 5X16 | ||
| 58031127000 | CARBURETOR COVER PLATE | ||
| 1 | 57031525000 | ADJUSTMENT SCREW M6X0,75 | 1 |
| 57231155000 | PLUG | ||
| 58031153000 | SPRING | ||
| 57031549000 | STARTING DEVICE | ||
| 57231150100 | START.DEVICE BODY 4-T | ||
| 58031180000 | PUSHBUTTON | ||
| 58031181000 | HEXAGON NUT M 9X0,75 | ||
| 0964040143 | OVAL HEAD SCREW DIN0964-M 4x14 | ||
| 0912040123 | AH SCREW DIN0912-M 4X12 | ||
| 57031522000 | MAIN JET HOLDER | ||
| 1 | 57031572000 | WASHER 3,3 X 5,8 X 0,5 | 1 |
| 57031515000 | SPRING AIR ADJUST.SCREW | ||
| 57031517000 | MIXTURE REGULAT.SCREW M7X0,75 | ||
| 54631517000 | MIXTURE REG.SCREW 400/620 RXC | ||
| 1 | 57031519000 | ADJUSTMENT SCREW M5 | 1 |
| 1 | 52031116000 | SPRING | 1 |
| 1 | 57031573000 | WASHER 5,1 X 8 X 0,8 | 1 |
| 0933060163 | HH SCREW DIN0933-M 6X16 | ||
| 57031513000 | HOSE CONNECTOR | ||
| 1 | 15131112000 | FUEL FILTER | 1 |
| 50131174000 | COVER | ||
| 57031508000 | STUD 2 X 47 | ||
| 57031511100 | FLOAT CHAMBER | ||
| 57031514000 | PLUG M12X1 | ||
| 1 | 58031199000 | GASKET SET PHM38SD/PHM40SD | 1 |
| 58031160000 | TUBE WITH THREAD 4T 92 | ||
| 1 | 31007007001 | PVC-HOSE 5 X 8 MM | 1 |
| 1 | 52031137001 | PVC-HOSE 3X5MM | 1 |
