Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11335-HA0-000 | PIPE, OIL PASSAGE | ||
| 11335-HA0-003 | PIPE, OIL PASSAGE | ||
| 12000-HA0-000 | CYLINDER HEAD ASSY. | ||
| 12000-HA0-770 | CYLINDER HEAD ASSY. | ||
| 12232-HA0-305 | GUIDE, VALVE (OS) | ||
| 1 | 12251-HA0-003 | GASKET, CYLINDER HEAD | 1 |
| 1 | 12251-HA0-004 | GASKET, CYLINDER HEAD | 1 |
| 12252-HA0-305 | GASKET, CYLINDER HEAD (OS 0.50-1.00) (Optional). | ||
| 2 | 12351-428-000 | COVER, TAPPET ADJ. HOLE | 2 |
| 2 | 12392-HC4-005 | GASKET, TAPPET COVER (KOYO) | 2 |
| 2 | 12392-428-000 | GASKET, TAPPET COVER | 2 |
| 15533-HA0-000 | BOLT, FLANGE (7X23) | ||
| 16211-HA0-681 | INSULATOR, CARBURETOR | ||
| 1 | 16219-422-000 | BAND, INSULATOR | 1 |
| 90004-HA0-000 | BOLT, FLANGE (6X22) | ||
| 2 | 90005-HA0-003 | BOLT, STUD (8X40) Use up to Engine SN 5161730 | 2 |
| 2 | 92900-08022-0B | BOLT, STUD (8X22) Use from Engine SN 5161731 | 2 |
| 1 | 90009-HA0-000 | BOLT, FLANGE (6X52) | 1 |
| 2 | 90048-MC8-000 | BOLT, FLANGE (6X140) Use up to Engine SN 5151530 | 2 |
| 2 | 95701-06140-00 | BOLT, FLANGE (6X140) | 2 |
| 90064-HA0-000 | BOLT, SOCKET (8X88) | ||
| 4 | 90201-HA0-000 | NUT, FLANGE CAP (10MM) | 4 |
| 90410-HA0-000 | WASHER (10MM) | ||
| 3 | 90441-MC0-000 | WASHER, SEALING (7MM) | 3 |
| 3 | 90441-469-000 | WASHER, SEALING (8MM) | 3 |
| 1 | 90441-706-000 | WASHER, SEALING (6MM) | 1 |
| 90443-HA0-000 | WASHER, LOCK (7MM) | ||
| 90443-HA0-771 | WASHER, LOCK (7MM) | ||
| 2 | 94301-08120 | PIN A, DOWEL (8X12) | 2 |
| 2 | 91301-200-000 | O-RING (10X1.6) | 2 |
| 1 | 91305-HA0-680 | O-RING (33.7X2.4) | 1 |
| 1 | 93500-05020-0G | SCREW, PAN (5X20) | 1 |
| 2 | 94301-12200 | PIN A, DOWEL (12X20) | 2 |
| 4 | 95700-06020-00 | BOLT, FLANGE (6X20) Use up to Engine SN 5131745 | 4 |
| 4 | 95701-06020-00 | BOLT, FLANGE (6X20) Use up to Engine SN 5131745 | 4 |
| 4 | 96000-06022-00 | BOLT, FLANGE (6X22) Use from Engine SN 5131746 to 5161730 | 4 |
| 4 | 96001-06022-00 | BOLT, FLANGE (6X22) Use from Engine SN 5131746 | 4 |
| 1 | 93493-06012-07 | BOLT-WASHER (6X12) | 1 |
| 1 | 95700-06012 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95700-06012-00 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95700-06012-10 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95800-06012 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95800-06012-00 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95900-06012-00 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95900-06012-02 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95701-06012-00 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95900-06028-00 | BOLT, FLANGE (6X28) | 1 |
| 1 | 95701-06028-00 | BOLT, FLANGE (6X28) | 1 |
| 2 | 95900-06070-00 | BOLT, FLANGE (6X70) Use up to Engine SN 5151530 | 2 |
| 2 | 95701-06070-00 | BOLT, FLANGE (6X70) | 2 |
| 3 | 96000-06025-00 | BOLT, FLANGE (6X25) Use up to Engine SN 5131745 | 3 |
| 3 | 96001-06025-00 | BOLT, FLANGE (6X25) Use up to Engine SN 5131745 | 3 |
| 3 | 96000-06028-00 | BOLT, FLANGE (6X28) Use from Engine SN 5131746 to 5161730 | 3 |
| 3 | 96001-06028-00 | BOLT, FLANGE (6X28) Use from Engine SN 5131746 | 3 |
| 1 | 96000-06035-00 | BOLT, FLANGE (6X35) Use up to Engine SN 5151530 | 1 |
| 1 | 96001-06035-00 | BOLT, FLANGE (6X35) | 1 |
| 1 | 96000-06040-00 | BOLT, FLANGE (6X40) Use up to Engine SN 5131745 | 1 |
| 1 | 96001-06040-00 | BOLT, FLANGE (6X40) Use up to Engine SN 5131745 | 1 |
| 1 | 96000-06045-00 | BOLT, FLANGE (6X45) Use from Engine SN 5131746 | 1 |
| 1 | 96001-06045-00 | BOLT, FLANGE (6X45) Use from Engine SN 5131746 | 1 |
| 2 | 96000-06045-00 | BOLT, FLANGE (6X45) Use up to Engine SN 5112009 | 2 |
| 2 | 96001-06045-00 | BOLT, FLANGE (6X45) | 2 |
| 1 | 98069-38716 | SPARK PLUG (DR8ES-L) (NGK) | 1 |
| 1 | 98069-38719 | SPARK PLUG (DR8ES-L) (NGK) | 1 |
| 1 | 98069-57716 | SPARK PLUG (DR7ES) (NGK) (Optional). | 1 |
| 1 | 98069-57719 | SPARK PLUG (DR7ES) (NGK) (Optional). | 1 |
| 1 | 98069-57726 | SPARK PLUG (X22ESR-U) (DENSO) (Optional). | 1 |
| 1 | 98069-58716 | SPARK PLUG (DR8ES) (NGK) (Optional). | 1 |
| 1 | 98069-58719 | SPARK PLUG (DR8ES) (NGK) (Optional). | 1 |
| 1 | 98069-58726 | SPARK PLUG (X24ESR-U) (DENSO) | 1 |
| 1 | 98069-59726 | SPARK PLUG (X27ESR-U) (DENSO) (Optional). | 1 |
