Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 58303001400 | FRAME 95 | ||
| 58303002200 | SUB FRAME CPL. 95 | ||
| 58303002090 | PLUG 12 X 17 MM | ||
| 58303003000 | FOOTREST BRACKET REAR L/S 93 | ||
| 58303103000 | FOOT PED BRACKET R 93 | ||
| 44003007000 | STEERING HEAD LOCK | ||
| 58003012000 | SPACER ROLLER 10,3X20X22 | ||
| 2 | 71001012000 | PVC CAP D=22MM | 2 |
| 58307015000 | TANK SUPPORT '93 93 | ||
| 58303055000 | ENGINE SUPPORT AGW '94 94 | ||
| 0931101103 | HH SCREW DIN0931-M10X110 | ||
| 1 | 49009082000 | flanged hex nut DIN 6927 M10 WS15 | 1 |
| 4 | 49109481052 | HH COLLAR SCREW M 8X16 WS=13 | 4 |
| 54310086000 | SELF LOCKING NUT | ||
| 2 | 10003021000 | STAND SPRING SHORT | 2 |
| 57503022000 | CENTER STAND 93 | ||
| 58303022000 | CENTER STAND LONG 408MM '93 93 | ||
| 58303027000 | SPRINGBOW '93 LC4 '93 | ||
| 0931100603 | H H SCREW | ||
| 2 | 0985100003 | SELF LOCKING NUT DIN0985-M10 | 2 |
| 1 | 0912101603 | AH SCREW DIN0912-M10X160 | 1 |
| 0934100003 | HEXAGON NUT DIN0934-M10 | ||
| 1 | 54630044000 | COLLAR NUT M10 WS=13 SW=13 | 1 |
| 2 | 0127100003 | SPRING RING DIN0127-B10 | 2 |
| 58303038000 | FOOTREST BRACKET L/S '93 LC4 '93 | ||
| 58303040000 | FOOTREST L/S ' LC4 '93 | ||
| 54603140000/19 | FOOT PED R/S 93 | ||
| 58303041000 | FOOTREST SPRING L/S '93 LC4 '93 | ||
| 1 | 54603041000 | FOOTREST SPRING L/S & R/S | 1 |
| 58303044000 | BOLT FOR FOOTREST | ||
| 1 | 54603044000 | BOLT FOR FOOTREST 9,8 X 50 | 1 |
| 2 | 0125100003 | washer DIN 125 A 10.5 | 2 |
| 2 | 0094032253 | PIN DIN0094-3,2X25 STEEL | 2 |
| 42007049000 | PLASTIC CAP | ||
| 49003250000 | FOOTREST REAR L/S CPL. | ||
| 49003350000 | REAR FOOT PED R/S | ||
| 58303045044 | FOOTREST RUBBER CPL. '94 94 | ||
| 2 | 50203053000 | CHAIN ROLL D=30MM | 2 |
| 4 | 74003021000 | BUSHING 8.2 X 12 X 6 | 4 |
| 4 | 0625006087 | GROOVED BALL BEAR. 608 2RS C3 | 4 |
| 2 | 0985060003 | SELF LOCK. NUT DIN0985-M 6 | 2 |
| 1 | 54403135000 | PLASTIC CAP SFL10 | 1 |
| 1 | 58303063000 | BRAKE LEVER STOP '93 93 | 1 |
| 1 | 0991060203 | FLAT H.SCREW DIN7991-M6X20 | 1 |
| 0 | 36003014000 | LOCK WASHER 8MM (As Required) | 0 |
| 1 | 0015080303 | HH COLLAR SCREW M 8X30 WS=10 SW=10 | 1 |
| 1 | 0015080403 | HH COLLAR SCREW M 8X40 WS=10 SW=10 | 1 |
| 58303070000 | STOP RUBBER M8 | ||
| 1 | 0934080003 | HEXAGON NUT DIN0934-M 8 | 1 |
| 2 | 0015080253 | HH COLLAR SCREW M 8X25 WS=10 SW=10 | 2 |
| 54510052000 | SPROCKET SCREW | ||
| 4 | 0107080203 | AH OVAL H.SCREW DIN0170-M 8X20 | 4 |
| 0 | 0797080003 | TOOTHLOCK WASHER DIN6797-J 8,4 (As Required) | 0 |
| 0 | 0125080003 | washer DIN 125 A -8.4 (As Required) | 0 |
| 58303010000 | COVER OIL FILTER '94 94 | ||
| 1 | 0014060103 | HH COLLAR SCREW M 6X10 WS=8 SW=8 | 1 |
| 2 | 0015060163 | HH COLLAR SCREW M 6X16 WS=8 SW=8 | 2 |
| 2 | 0021060003 | WASHER DIN9021-A 6,4 | 2 |
| 2 | 54603048100 | clip nut M6 | 2 |
| 2 | 0910100003 | PLUG DIN0910-M 10X1 | 2 |
| 2 | 58038022900 | CU-SEAL RING 10 X 14 X 1,5 | 2 |
