Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 94400-06B20-9HJ | BODY ASSY, COWLING | ||
| 94400-06B20-9HD | BODY ASSY, COWLING Includes Item(s) 2 - 4 | ||
| 68271-04A00-064 | EMBLEM FOR 9HJ | ||
| 68271-04A00-742 | EMBLEM FOR 9HD | ||
| 94435-27A00-34R | COVER, FRONT (BLUE) FOR 9HJ | ||
| 94435-27A00-13Z | COVER, FRONT (BLACK) FOR 9HD | ||
| 4 | 03541-04125 | SCREW | 4 |
| 94611-06B01 | SCREEN, WIND (CLEAR) | ||
| 1 | 94631-27A00 | MOLDING | 1 |
| 3 | 09139-05025 | SCREW (5X14) | 3 |
| 2 | 09139-05032 | SCREW (5X18) | 2 |
| 5 | 94619-27A00 | NUT | 5 |
| 94529-27A00 | PLATE, MIRROR RH | ||
| 94539-27A00 | PLATE, MIRROR LH | ||
| 94430-06B30-9HJ | COVER, SIDE RH (WHITE/BLUE) FOR 9HJ | ||
| 94430-06B30-9HD | COVER, SIDE RH (BLACK/RED) FOR 9HD; Includes Item(s) 13 - 14 | ||
| 68111-43400-064 | EMBLEM | ||
| 68680-27A50-9HT | TAPE SET, RH FOR 9HJ | ||
| 68680-27A50-9HU | TAPE SET, RH FOR 9HD | ||
| 94440-06B30-9HJ | COVER, SIDE LH (WHITE/BLUE) FOR 9HJ | ||
| 94440-06B30-9HD | COVER, SIDE LH (BLACK/RED) FOR 9HD; Includes Item(s) 16 - 17 | ||
| 68690-27A50-9HT | TAPE SET, LH FOR 9HJ | ||
| 68690-27A50-9HU | TAPE SET, LH FOR 9HD | ||
| 2 | 09139-06027 | SCREW, REAR (6X12) | 2 |
| 2 | 09169-06033 | WASHER | 2 |
| 6 | 09139-06030 | SCREW (6X16) | 6 |
| 2 | 94570-04A00 | CUSHION | 2 |
| 94510-06B00 | BRACE, FRONT | ||
| 1 | 07120-08205 | BOLT | 1 |
| 2 | 07120-08165 | BOLT, LOWER | 2 |
| 94530-06B00 | BRACE, REAR | ||
| 94470-06B10-9HJ | COVER, LOWER RH (WHITE/BLUE) FOR 9HJ | ||
| 94470-06B10-9HD | COVER, LOWER RH (BLACK/RED) FOR 9HD; Includes Item(s) 27 - 29 | ||
| 68261-27A00-8KE | EMBLEM FOR 9HJ | ||
| 68261-27A00-7JS | EMBLEM FOR 9HD | ||
| 68131-27A00-9HT | EMBLEM FOR 9HJ | ||
| 68131-27A00-9EW | EMBLEM FOR 9HD | ||
| 68680-27A60-9HT | TAPE SET, LOWER FOR 9HJ | ||
| 68680-27A60-9HU | TAPE SET, LOWER FOR 9HD | ||
| 94480-06B30-9HJ | COVER, LOWER LH (WHITE/BLUE) FOR 9HJ | ||
| 94480-06B30-9HD | COVER, LOWER LH (BLACK/RED) FOR 9HD; Includes Item(s) 31 - 33 | ||
| 68690-27A60-9HT | TAPE SET, LOWER FOR 9HJ | ||
| 68690-27A60-9HU | TAPE SET, LOWER FOR 9HD | ||
| 6 | 09139-06030 | SCREW, UPPER (6X16) | 6 |
| 6 | 09139-06039 | SCREW, RH & LH (6X16) | 6 |
| 94490-06B00 | BRACE, LOWER | ||
| 2 | 09139-06028 | SCREW (6X20) | 2 |
| 2 | 09320-09016 | CUSHION | 2 |
| 2 | 09180-06152 | SPACER | 2 |
| 2 | 09160-06056 | WASHER (6.5X18X1) | 2 |
| 10 | 09161-07005 | WASHER | 10 |
| 94475-06B01-22R | COVER, LOWER FRONT (WHITE) FOR 9HJ | ||
| 94475-06B01-22P | COVER, LOWER FRONT (RED) FOR 9HD | ||
| 2 | 09139-05025 | SCREW (5X14) | 2 |
| 2 | 08316-26055 | NUT | 2 |
| 94580-06B00 | BRACE, LOWER RH | ||
| 94590-06B00 | BRACE, LOWER LH | ||
| 94493-06B00 | BRACE, LOWER REAR | ||
| 2 | 01517-06128 | BOLT | 2 |
| 2 | 09139-06030 | SCREW (6X16) | 2 |
| 2 | 08321-21064 | LOCK WASHER | 2 |
| 2 | 08313-11065 | NUT | 2 |
| 94550-06B00 | BRACE, MIRROR RH | ||
| 94560-06B00 | BRACE, MIRROR LH | ||
| 2 | 09250-08008 | CUSHION | 2 |
| 4 | 01107-06165 | BOLT | 4 |
| 4 | 08321-21064 | LOCK WASHER | 4 |
| 2 | 08321-31064 | LOCK WASHER | 2 |
| 1 | 09139-06030 | SCREW (6X16) | 1 |
