Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 3280290 | 6 PULSE SPEEDOMETER, 3.38 IN | ||
| 3280312 | 6 PULSE SPEEDOMETER, 3.38 IN (EB) | ||
| 1 | 5430967 | PLUG,INDIC.HOLE | 1 |
| 1 | 4040053 | HOT TEMPERATURE INDICATOR | 1 |
| 1 | 4040054 | INDIC NEUT./REV. | 1 |
| 3 | 7511881 | SCREW | 3 |
| 3 | 7670086 | NUT (10) | 3 |
| 1 | 2460668 | HARNESS,CTR.PNL. | 1 |
| ------- | Asm., Throttle Control (See Controls - Throttle Asm./Cable Pg. B11, Ref. 5) | ||
| 1 | 5242987-067 | HANDLEBAR TUBE, MEDIUM GLOSS BL | 1 |
| 2200774 | Discontinued (Incl. Blocks and 8,12,30) | ||
| 5630616-067 | Discontinued | ||
| 7541933 | NUT | ||
| 7555868 | WASHER, LOCK,(S.S.) | ||
| 2 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 2 |
| 4 | 7515189 | SCREW | 4 |
| 3280291 | CLAMP,BACK,ELEC.SPEEDO,3.38" | ||
| 5433042-053 | POD,HDLIGHT,UPPER,MD.YLW (AE)(AK) | ||
| 5433042-191 | POD-HEADLIGHT,UPPER,OLIVE GR (AA)(AF) | ||
| 5433042-136 | Discontinued (AB)(AH)(EB) | ||
| 5433042-317 | POD-HEADLIGHT,UPPER,GUNMETAL (AL) | ||
| 5433289-283 | Discontinued (AC)(AJ) | ||
| ------- | Asm., Master Cylinder (See Controls - Master Cylinder/Brake Line Pg. B12 for details) | ||
| 1 | 5432926 | SPACER,SWITCH,LH | 1 |
| 1 | 4010262 | HI/LO/OFF (REV/OR) HANDLEBAR SW | 1 |
| 2 | 5431030 | HANDLEBAR GRIP, 7/8 ID, GLOSS B | 2 |
| 1 | 5432952 | PLUG, HOLE | 1 |
| 1 | 7517625 | SCREW, SET | 1 |
| 1 | 5240586-067 | POD MOUNTING BRACKET, BLACK | 1 |
| 2 | 7517317 | SCREW | 2 |
| 1 | 4032079 | ADJUSTING KNOB | 1 |
| 1 | 5411120 | HEADLIGHT BOOT | 1 |
| 1 | 4032077 | COLLAR LOCK | 1 |
| 4032075 | ASM,HEADLIGHT W/ADJUST ROD-KNOB | ||
| 1 | 2870448 | HEADLIGHT BULB | 1 |
| 4032078 | Discontinued | ||
| 2 | 5410163 | O-RING | 2 |
| 1 | 7080726 | CHOKE CABLE W/ ADJUSTER | 1 |
| 1 | 2200188 | CHOKE CONTROL KIT | 1 |
| 4 | 7542122 | NYLOK NUT | 4 |
| 2 | 7670089 | NUT,U-TYPE | 2 |
| 2410025 | POWERPLUG ASM,12V (If built before 9/27/99) | ||
| 2 | 7621334 | RIVET | 2 |
| 4010283 | RECEPTACLE-POD MNT,12 VOLT (If built after 9/27/99) | ||
| 7080631 | Discontinued | ||
| 7522021 | Discontinued | ||
| 1 | 5432314-070 | HEADLIGHT POD, LOWER, GLOSS BLA (If built before 9/27/99)(AA)(AB) | 1 |
| 1 | 5433366-070 | HEADLIGHT POD, LOWER, GLOSS BLA (If built between 9/27/99 and 4/24/00) (AA)(AB)(AE)(AF)(AH)(AK)(AL)(EB) | 1 |
| 1 | 5433706-283 | HEADLIGHT POD, LOWER, GLOSS BLA (If built between 9/27/99 and 4/24/00)(AC)(AJ) | 1 |
| 5431811-070 | Discontinued (If built after 4/24/00)(AC)(AJ)(AF)(AH) | ||
| 1 | 4110264 | IGNITION SWITCH (Incl. Key) | 1 |
| 1 | 4010278 | KEYBLANK-B,6700-6800,2000-2100 Your key can be duplicated only by obtaining a key blank from Polaris and having it cut by mating it with your existing key. | 1 |
| 1 | 4010321 | KEYBLANK-A,2700-2800,2200-2389 Your key can be duplicated only by obtaining a key blank from Polaris and having it cut by mating it with your existing key. | 1 |
| 1 | 5433534 | KEY COVER-KEYSWITCH | 1 |
| 1 | 5433733 | IGNITION SWITCH NUT | 1 |
| 1 | 7080229 | NUT-CHOKE SLIDE | 1 |
| 1 | 4040081 | SPEEDO SENSOR KIT, LARGE (If built before 8/09/99) | 1 |
| 1 | 4010298 | HALL EFFECT SENSOR (If built after 8/09/99)(Incl. 43) | 1 |
| 1 | 5132382 | HALL SENSOR CAP (If built after 8/09/99) | 1 |
| 1 | 7517658 | SCREW | 1 |
