Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1823801 | SPINDLE ASSEMBLY, LEFT [INCLUDES QTY 2 OF 2] | 1 |
| 1 | 1823802 | SPINDLE ASSEMBLY, RIGHT [INCLUDES QTY 2 OF 2] | 1 |
| 1 | 1823801-293 | SPINDLE ASSEMBLY, LEFT, INDY RE [INCLUDES QTY 2 OF 2] [RED] | 1 |
| 1 | 1823802-293 | SPINDLE ASSEMBLY, RIGHT, INDY R [INCLUDES QTY 2 OF 2] [RED] | 1 |
| 1 | 1823801-067 | SPINDLE ASSEMBLY, LEFT, GS BLK [INCLUDES QTY 2 OF 2] [BLACK] | 1 |
| 1 | 1823802-067 | SPINDLE ASSEMBLY, RIGHT, GS BLK [INCLUDES QTY 2 OF 2] [BLACK] | 1 |
| 1 | 1823801-630 | SPINDLE ASSEMBLY, LEFT, LIME SQ [INCLUDES QTY 2 OF 2] [LIME SQUEEZE] | 1 |
| 1 | 1823802-630 | SPINDLE ASSEMBLY, RIGHT, LIME S [INCLUDES QTY 2 OF 2] [LIME SQUEEZE] | 1 |
| 1 | 1823801-728 | SPINDLE ASSEMBLY, LEFT, GHOST G [INCLUDES QTY 2 OF 2] [GHOST GRAY] | 1 |
| 1 | 1823802-728 | SPINDLE ASSEMBLY, RIGHT, GHOST [INCLUDES QTY 2 OF 2] [GHOST GRAY] | 1 |
| 1 | 1823801-751 | ASM-SPINDLE LH POLARIS BLUE [INCLUDES QTY 2 OF 2] [POLARIS BLUE] | 1 |
| 1 | 1823802-751 | ASM-SPINDLE RH POLARIS BLUE [INCLUDES QTY 2 OF 2] [POLARIS BLUE] | 1 |
| 1 | 1823801-784 | ASM-SPINDLE LH PLUM CRAZY [INCLUDES QTY 2 OF 2] [PLUM CRAZY] | 1 |
| 1 | 1823802-784 | ASM-SPINDLE RH PLUM CRAZY [INCLUDES QTY 2 OF 2] [PLUM CRAZY] | 1 |
| 4 | 5438460 | SKI PIVOT BUSHING | 4 |
| 1 | 1824756-067 | ASM-UCA MOLY LH BLK [INCLUDES 5-9] | 1 |
| 1 | 1824757-067 | ASM-UCA MOLY RH BLK [INCLUDES 5-9] | 1 |
| 1 | 1824171-067 | CONTROL ARM, UPPER, LEFT HAND, [UCA ONLY] | 1 |
| 1824172-067 | Discontinued [UCA ONLY] | ||
| 1 | 1824758-067 | ASM-LCA LH BLK [INCLUDES 5-7 & 10-12] | 1 |
| 1 | 1824759-067 | ASM-LCA RH BLK [INCLUDES 5-7 & 10-12] | 1 |
| 1824169-067 | Discontinued [LCA ONLY] | ||
| 1824170-067 | RIGHT SIDE, LOWER CONTROL ARM, [LCA ONLY] | ||
| 6 | 5140556 | PIVOT SHAFT | 6 |
| 8 | 5450297 | PIVOT BUSHING | 8 |
| 8 | 7556758 | WASHER, 18.2 X 25 X 1.6 | 8 |
| 2 | 7061179 | SPHERICAL CONTROL ARM BEARING U | 2 |
| 2 | 7710642 | RING-RET INT 1.125 | 2 |
| 2 | 5140557 | CONTROL ARM PIVOT SHAFT, LOWER, | 2 |
| 2 | 2204229 | SPHERICAL BEARING KIT, 10 MM | 2 |
| 2 | 7710539 | RING-RETAINING,1.25 ID HSNG | 2 |
| 2 | 5136910 | BUSHING, 15.88 X 10.13 X 76.20 | 2 |
| 2 | 7519015 | SCR-M10X1.5X75 10.9 HCS ZOD | 2 |
| 4 | 7555806 | FLAT WASHER | 4 |
| 2 | 7547464 | NUT-HEX-M12X1.5 8 ZOD NYL | 2 |
| 4 | 7556994 | WSHR-M12X25X1.6 THRU HARD ZOD | 4 |
| 1 | 7518917 | HEX FLANGE SCREW, 10 MM X 1.5 M | 1 |
| 8 | 7547423 | NUT-M10X1.5 HFN NYLOC ZOD | 8 |
| 16 | 7547332 | NYLOC OLIVE NUT, 8 MM X 1.25 MM | 16 |
| 4 | 5137360 | BUSHING, 10 MM X 17.5 MM X 30 M | 4 |
| 2 | 7518941 | SCREW, 10 MMX 1.5 MM X 60 MM | 2 |
| 2 | 7518971 | SCR-M10X1.5X50 8.8 HX/FL ZOD | 2 |
