Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4KD-Y1754-00-00 | Middle Gear Comp | ||
| 1 | 93306-30439-00 | Bearing (93306-30421-00 ) | 1 |
| 1 | 24W-17537-20-00 | Shim, Thrust (0.15T) UR | 1 |
| 1 | 24W-17537-10-00 | Shim, Thrust (0.13T) UR | 1 |
| 1 | 24W-17537-30-00 | Shim, Thrust (0.2T) UR | 1 |
| 1 | 24W-17537-50-00 | Shim, Thrust (0.4T) UR | 1 |
| 1 | 24W-17537-40-00 | Shim, Thrust (0.3T) UR | 1 |
| 1 | 24W-17537-60-00 | Shim, Thrust (0.5T) UR | 1 |
| 90179-16651-00 | Nut | ||
| 1 | 93306-00612-00 | Bearing | 1 |
| 1 | 52G-17531-01-00 | Shim, Pinion (0.1T) UR | 1 |
| 1 | 52G-17531-11-00 | Shim, Pinion (0.15T) UR | 1 |
| 1 | 52G-17531-21-00 | Shim, Pinion (0.2T) UR | 1 |
| 1 | 52G-17531-31-00 | Shim, Pinion (0.3T) UR | 1 |
| 1 | 52G-17531-41-00 | Shim, Pinion (0.4T) UR | 1 |
| 1 | 52G-17531-51-00 | Shim, Pinion (0.5T) UR | 1 |
| 1 | 52G-17285-00-00 | Clutch, Dog | 1 |
| 1 | 52G-17967-00-20 | Shim, (0.2T) UR | 1 |
| 1 | 52G-17967-00-30 | Shim, (0.3T) UR | 1 |
| 52G-17967-00-40 | Shim, (0.4T) UR | ||
| 1 | 93306-07801-00 | Bearing | 1 |
| 1 | 90179-55464-00 | Nut | 1 |
| 1 | 90179-28465-00 | Nut | 1 |
| 4KD-17553-00-00 | Shaft, Middle Driven | ||
| 52G-17968-00-14 | Shim, (1.4T) UR | ||
| 52G-17968-00-12 | Shim, (1.2T) UR | ||
| 52G-17968-00-10 | Shim, (1.0T) UR | ||
| 52G-17968-00-16 | Shim, (1.6T) UR | ||
| 1 | 52G-17968-00-18 | Shim, (1.8T) UR | 1 |
| 1 | 93306-30302-00 | Bearing | 1 |
| 90179-50467-00 | Nut | ||
| 4BD-17556-00-00 | Yoke, Joint | ||
| 1 | 90201-125F7-00 | Washer, Plate | 1 |
| 1 | 90179-12657-00 | Nut | 1 |
| 4KD-17551-01-00 | Housing, Bearing | ||
| 1 | 93210-56589-00 | O-Ring | 1 |
| 1 | 93210-65721-00 | O-Ring | 1 |
| 4 | 97027-08055-00 | Bolt | 4 |
| 4 | 92907-08600-00 | Washer, Plate | 4 |
| 52G-18514-02-00 | Fork, Shift 4 | ||
| 1 | 90501-101A5-00 | Spring, Compression | 1 |
| 1 | 93501-04011-00 | Ball | 1 |
| 52G-18534-00-00 | Bar, Shift Fork Guide | ||
| 3GC-1812A-00-00 | Stopper Shaft Assy | ||
| 3GC-18197-00-00 | Shaft | ||
| 1 | 99009-14400-00 | Circlip | 1 |
| 3GC-18451-00-00 | Lever, Shift | ||
| 52G-18198-00-00 | Lever | ||
| 1 | 90105-06680-00 | Bolt, Washer Based | 1 |
| 1 | 93102-14209-00 | Oil Seal | 1 |
| 1 | 93210-09350-00 | O-Ring | 1 |
| 4KD-17541-01-00 | Case, Transfer 1 | ||
| 1 | 93316-00403-00 | Bearing | 1 |
| 1 | 93306-30551-00 | Bearing | 1 |
| 1 | 93105-35027-00 | Oil Seal | 1 |
| 4KD-17542-01-00 | Case, Transfer 2 | ||
| 93316-00604-00 | Bearing | ||
| 1 | 93306-00435-00 | Bearing | 1 |
| 1 | 93101-30084-00 | .Oil Seal | 1 |
| 2 | 99510-08016-00 | Pin, Dowel | 2 |
| 4KD-17586-00-00 | Gear, Transfer Drive (23T) | ||
| 4KD-17587-00-00 | Gear, Idler (32T) | ||
| 22U-17553-01-00 | Shaft, Middle Driven | ||
| 4KD-17588-00-00 | Gear, Transfer Driden (26T) | ||
| 1 | 95027-06035-00 | Bolt, Flange | 1 |
| 5 | 95027-06030-00 | Bolt, Flange | 5 |
| 1 | 2HR-17576-00-00 | Yoke, Joint 2 | 1 |
| 1 | 90201-14633-00 | Washer, Plate | 1 |
| 1 | 90185-14070-00 | Nut, Self-Locking | 1 |
| 1 | 90340-14029-00 | Plug, Straight Screw | 1 |
| 1 | 214-11198-01-00 | Gasket | 1 |
| 1 | 95027-08012-00 | Bolt, Flange | 1 |
| 1 | 90201-08087-00 | .Washer, Plate | 1 |
| 1 | 22U-17527-01-00 | Cam, Driven | 1 |
| 1 | 90501-605E1-00 | Spring, Compression | 1 |
| 1 | 22U-17524-00-00 | Holder | 1 |
| 2 | 3H5-17529-00-00 | Washer, Thrust | 2 |
