Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11012 | 11012-1648 | CAP | 2 |
| 11012A | 11012-1649 | CAP,GEAR CASE | 1 |
| 13088 | 13088-1075 | PLATE-FRICTION,T=2.8 | 2 |
| 13088A | 13088-1078 | PLATE-FRICTION,T=2.4 | 2 |
| 13089 | 13089-1083 | PLATE-CLUTCH | 2 |
| 13101 | 13101-1190 | GEAR-ASSY | 1 |
| 13101B | 13101-5083 | GEAR-ASSY | 1 |
| 14055 | 14055-1114 | CASE-GEAR,FR | 1 |
| 41046 | 41046-1089 | HOUSING-BEARING | 1 |
| 49035 | 49035-1056 | PIN-SPRING | 2 |
| 92005 | 92005-1127 | FITTING,BREATHER | 1 |
| 92015 | 92015-1402 | NUT,8MM | 4 |
| 92015A | 92015-1768 | NUT,25MM | 1 |
| 92022 | 92022-1941 | WASHER | 2 |
| 92022A | 92022-1990 | WASHER,TOOTHED | 1 |
| 92022B | 92022-225 | WASHER,25.3X32X0.5 | 1 |
| 92025 | 92025-1072 | SHIM,25.2X29.8X1.70 | 1 |
| 92025A | 92025-1073 | SHIM,25.2X29.8X1.72 | 1 |
| 92025B | 92025-1074 | SHIM,25.2X29.8X1.74 | 1 |
| 92025C | 92025-1075 | SHIM,25.2X29.8X1.76 | 1 |
| 92025D | 92025-1076 | SHIM,25.2X29.8X1.78 | 1 |
| 92025E | 92025-1077 | SHIM,25.2X29.8X1.80 | 1 |
| 92025F | 92025-1849 | SHIM,35.3X46X1.00 | 1 |
| 92025G | 92025-1850 | SHIM,35.3X46X0.10 | 1 |
| 92025H | 92025-1851 | SHIM,35.3X46X0.15 | 1 |
| 92025I | 92025-1856 | SHIM,35.3X46X0.50 | 1 |
| 92025J | 92025-1857 | SHIM,35.3X46X0.80 | 1 |
| 92025K | 92025-1919 | SHIM,T=0.10 | 1 |
| 92025L | 92025-1920 | SHIM,T=0.15 | 1 |
| 92025M | 92025-1921 | SHIM,T=0.50 | 1 |
| 92025N | 92025-1922 | SHIM,T=0.80 | 1 |
| 92025O | 92025-1923 | SHIM,T=1.00 | 1 |
| 92025P | 92025-1924 | SHIM,T=1.20 | 1 |
| 92026 | 92026-1337 | SPACER | 1 |
| 92026A | 92026-1338 | SPACER,29X40X1.0 | 2 |
| 92027 | 92027-1401 | COLLAR,25.2X29.8X10.2 | 1 |
| 92027A | 92027-1402 | COLLAR,25.2X29.8X10.3 | 1 |
| 92027B | 92027-1403 | COLLAR,25.2X29.8X10.4 | 1 |
| 92027C | 92027-1404 | COLLAR,25.2X29.8X10.5 | 1 |
| 92027D | 92027-1405 | COLLAR,25.2X29.8X10.6 | 1 |
| 92027E | 92027-1406 | COLLAR,25.2X29.8X10.7 | 1 |
| 92027F | 92027-1407 | COLLAR,25.2X29.8X10.8 | 1 |
| 92027G | 92027-1408 | COLLAR,25.2X29.8X10.9 | 1 |
| 92027H | 92027-1409 | COLLAR,25.2X29.8X11.0 | 1 |
| 92027I | 92027-1410 | COLLAR,25.2X29.8X11.1 | 1 |
| 92027J | 92027-1411 | COLLAR,25.2X29.8X11.2 | 1 |
| 92028 | 92028-1699 | BUSHING | 1 |
| 92033 | 92033-1249 | RING-SNAP,T=1.5 | 2 |
| 92037 | 92037-147 | CLAMP,TUBE | 1 |
| 92043 | 92043-1400 | PIN,8X18 | 2 |
| 92049 | 92049-1298 | SEAL-OIL,TC35X55X8 | 1 |
| 92049A | 92049-1309 | SEAL-OIL,TC30487 | 2 |
| 92055 | 92055-055 | RING-O,19.5X1.5 | 1 |
| 92055A | 92055-1136 | RING-O,25.7X2.4 | 1 |
| 92055B | 92055-1160 | RING-O,24.7MM | 1 |
| 92055C | 92055-1408 | RING-O,65.2X2.4 | 1 |
| 92055D | 92055-1409 | RING-O,46X2.5 | 2 |
| 92055E | 92055-1410 | RING-O,154.1X2.5 | 1 |
| 92059 | 92059-1929 | TUBE,4.7X8.5X900 | 1 |
| 92065 | 92065-058 | GASKET,10.5X16X1 | 1 |
| 92066 | 92066-1303 | PLUG | 1 |
| 92067 | 92067-001 | PLUG,DRAIN,10X12 | 1 |
| 92072 | 92072-031 | BAND,L=149 | 1 |
| 92116 | 92116-1003 | BEARING-ROLLER,4T30205 | 2 |
| 92143 | 92143-1703 | COLLAR | 2 |
| 92144 | 92144-1671 | SPRING | 2 |
| 92150 | 92150-1109 | BOLT,8X20 | 12 |
| 92180 | 92180-1121 | SHIM,32X48X0.8 | 1 |
| 92180A | 92180-1122 | SHIM,32X48X1.0 | 1 |
| 92180B | 92180-1123 | SHIM,32X48X1.2 | 1 |
| 92180C | 92180-1124 | SHIM,32X48X1.4 | 1 |
| 92180D | 92180-1125 | SHIM,32X48X1.6 | 1 |
| 115 | 115P0830 | BOLT-SMALL-UPSET | 2 |
| 120 | 120P0616 | BOLT,SOCKET,6X16 | 6 |
| 130 | 130P0830 | BOLT-FLANGED,8X30 | 4 |
| 130A | 130P1035 | BOLT-FLANGED | 8 |
| 172 | 172G0822 | STUD 8X22 | 4 |
| 601 | 601B6007 | BEARING-BALL,#6007C3 | 2 |
