Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 16100-MEN-A12 | CARBURETOR ASSY. (FCR00G A) | ||
| 1 | 16010-MEN-851 | GASKET SET | 1 |
| 1 | 16011-MEN-851 | VALVE SET, FLOAT | 1 |
| 16013-KRN-851 | FLOAT SET | ||
| 1 | 16014-MEY-A11 | TOP SET | 1 |
| 16015-MEN-A01 | CHAMBER SET, FLOAT | ||
| 1 | 16016-KRN-A01 | SCREW SET A | 1 |
| 1 | 16018-MEY-A11 | ARM SET, LINK | 1 |
| 1 | 16019-MEB-671 | START SET, HOT | 1 |
| 1 | 16021-MEN-A01 | DIAPHRAGM SET, PUMP | 1 |
| 1 | 16028-MEN-A01 | SCREW SET B | 1 |
| 1 | 16029-MEY-A11 | SCREW SET, JET NEEDLE | 1 |
| 16032-MEN-A11 | SHAFT SET, THROTTLE | ||
| 1 | 16037-MEB-671 | VALVE SET, FLOATING | 1 |
| 1 | 16038-KRN-671 | JOINT SET, FUEL | 1 |
| 1 | 16046-MEB-671 | VALVE SET, STARTER | 1 |
| 16060-MEN-A11 | SENSOR ASSY., THROTTLE | ||
| 1 | 16080-HP1-601 | BOLT, COVER | 1 |
| 1 | 16083-MEB-671 | SCREW, PAN | 1 |
| 1 | 16112-HP1-A01 | VALVE, THROTTLE | 1 |
| 1 | 16157-MEN-A01 | COVER, THROTTLE | 1 |
| 1 | 16163-MEB-671 | GASKET, FLOAT CHAMBER | 1 |
| 16165-MEN-A01 | HOLDER, NEEDLE JET | ||
| 1 | 16172-MEB-671 | ROLLER | 1 |
| 1 | 16177-MEB-671 | WASHER, PLAIN (PO) | 1 |
| 1 | 16178-MEB-671 | WASHER, PLAIN (SUS) | 1 |
| 1 | 16185-MEN-671 | PLATE, BUFFER | 1 |
| 1 | 16196-MEN-851 | TUBE, OVERFLOW | 1 |
| 1 | 16197-MEB-671 | TUBE, AIR VENT | 1 |
| 1 | 16198-MEB-671 | TUBE, AIR VENT | 1 |
| 1 | 16199-MEB-671 | TUBE, AIR VENT | 1 |
| 4 | 93892-04008-08 | SCREW-WASHER (4X8) | 4 |
| 4 | 93892-04008-18 | SCREW-WASHER (4X8) | 4 |
| 4 | 93892-04014-08 | SCREW-WASHER (4X14) | 4 |
| 4 | 93892-04014-18 | SCREW-WASHER (4X14) | 4 |
| 5 | 95002-02079 | CLIP, TUBE (B7) | 5 |
| 99101-357-1820 | JET, MAIN (#182) (Optional). | ||
| 99101-357-1850 | JET, MAIN (#185) (Optional). | ||
| 99113-GHB-1820 | JET, MAIN (#182) (Optional). | ||
| 99113-GHB-1850 | JET, MAIN (#185) (Optional). | ||
| 1 | 99101-357-1680 | JET, MAIN (#168) (Optional). | 1 |
| 1 | 99101-357-1700 | JET, MAIN (#170) (Optional). | 1 |
| 1 | 99101-357-1720 | JET, MAIN (#172) (Optional). | 1 |
| 1 | 99101-357-1750 | JET, MAIN (#175) (Optional). | 1 |
| 1 | 99101-357-1780 | JET, MAIN (#178) (Optional). | 1 |
| 99101-357-1800 | JET, MAIN (#180) (Optional). | ||
| 1 | 99113-GHB-1680 | JET, MAIN (#168) (Optional). | 1 |
| 1 | 99113-GHB-1700 | JET, MAIN (#170) (Optional). | 1 |
| 1 | 99113-GHB-1720 | JET, MAIN (#172) (Optional). | 1 |
| 1 | 99113-GHB-1780 | JET, MAIN (#178) (Optional). | 1 |
| 99113-GHB-1800 | JET, MAIN (#180) (Optional). | ||
| 1 | 99101-357-1880 | JET, MAIN (#188) (Optional). | 1 |
| 1 | 99113-GHB-1880 | JET, MAIN (#188) (Optional). | 1 |
| 1 | 99103-GBF-0400 | JET, SLOW (#40) (Optional). | 1 |
| 1 | 99103-GBF-0450 | JET, SLOW (#45) (Optional). | 1 |
| 1 | 99103-GBF-0480 | JET, SLOW (#48) (Optional). | 1 |
| 1 | 99103-KA3-0400 | JET, SLOW (#40) (Optional). | 1 |
| 1 | 99103-KA3-0450 | JET, SLOW (#45) (Optional). | 1 |
| 1 | 99103-440-0400 | JET, SLOW (#40) (Optional). | 1 |
| 1 | 99103-440-0420 | JET, SLOW (#42) | 1 |
| 1 | 99103-440-0450 | JET, SLOW (#45) (Optional). | 1 |
| 1 | 99103-440-0480 | JET, SLOW (#48) (Optional). | 1 |
| 1 | 99103-KA3-0380 | JET, SLOW (#38) (Optional). | 1 |
| 1 | 99103-KBA-0380 | JET, SLOW (#38) (Optional). | 1 |
| 1 | 99103-440-0380 | JET, SLOW (#38) (Optional). | 1 |
| 1 | 99108-MEB-0550 | JET, LEAK (#55) | 1 |
| 1 | 99108-KRN-0450 | JET, LEAK (#45) (Optional). | 1 |
| 1 | 99108-KRN-0500 | JET, LEAK (#50) (Optional). | 1 |
| 1 | 99108-KSE-0600 | JET, LEAK (#60) (Optional). | 1 |
| 1 | 99108-KSC-0650 | JET, LEAK (#65) (Optional). | 1 |
| 1 | 99112-MEB-0720 | JET, BY-STARTER (#72) | 1 |
| 1 | 16088-HP1-901 | CLIP | 1 |
| 1 | 16076-ND5-004 | O-RING (1.3X4.3) | 1 |
| 1 | 16033-MEN-A01 | LEVER SET, PUMP | 1 |
| 2 | 16178-MEN-851 | BINDER | 2 |
| 16201-MEN-A01 | NEEDLE SET, JET (NJYP) (Optional). | ||
| 1 | 16202-MEN-A01 | NEEDLE SET, JET (NJYQ) (Optional). | 1 |
| 1 | 16203-MEN-A01 | NEEDLE SET, JET (NJYR) (Optional). | 1 |
| 16204-MEN-A01 | NEEDLE SET, JET (NJYS) (Optional). | ||
| 1 | 16205-MEN-A01 | NEEDLE SET, JET (NJYT) (Optional). | 1 |
| 16229-MEN-E01 | NEEDLE SET, JET (NJGP) (Optional). | ||
| 16230-MEN-E01 | NEEDLE SET, JET (NJGQ) (Optional). | ||
| 16231-MEN-E01 | NEEDLE SET, JET (NJGR) | ||
| 1 | 16232-MEN-E01 | NEEDLE SET, JET (NJGS) (Optional). | 1 |
| 16233-MEN-E01 | NEEDLE SET, JET (NJGT) (Optional). |
