Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 58303001000 | FRAME 350-620 EXC,EGS,RXC (MIT LAGER FOR ANLENKUNG) LC4 '93 | ||
| 58303001100 | FRAME SX,EXC,SUPERCOMPETITION (MIT LAGER FOR ANLENKUNG) LC4 '93 | ||
| 58303002000 | SUB FRAME 93 | ||
| 58303102100 | SUB FRAME 350-620 SX,EXC, 400/620 EGS AUS 94 | ||
| 58303002090 | PLUG 12 X 17 MM | ||
| 58303003000 | FOOTREST BRACKET REAR L/S 93 | ||
| 58303103000 | FOOT PED BRACKET R 93 | ||
| 58303002145 | BRACKET | ||
| 58303002045 | BRACKET | ||
| 44003007000 | STEERING HEAD LOCK | ||
| 58038022800 | SEAL RING 22x27x2 (COPPER) | ||
| 0604220151 | MAGNETIC PLUG | ||
| 2 | 0014060133 | HH COLLAR SCREW M 6X13 WS=8 SW=8 | 2 |
| 58003012000 | SPACER ROLLER 10,3X20X22 | ||
| 2 | 71001012000 | PVC CAP D=22MM | 2 |
| 58307015000 | TANK SUPPORT '93 93 | ||
| 58003055500 | ENGINE SUPPORT L/S LC4 '90 | ||
| 58003155500 | ENGINE SUPPORT R/S LC4 '90 | ||
| 0931101103 | HH SCREW DIN0931-M10X110 | ||
| 1 | 49009082000 | flanged hex nut DIN 6927 M10 WS15 | 1 |
| 0931080753 | H H SCREW | ||
| 2 | 10003021000 | STAND SPRING SHORT | 2 |
| 57503022000 | CENTER STAND 350-600 EGS/RXC 93 | ||
| 58303022000 | CENTER STAND LONG 408MM '93 93 | ||
| 58303027000 | SPRINGBOW '93 LC4 '93 | ||
| 0931100603 | H H SCREW | ||
| 2 | 0985100003 | SELF LOCKING NUT DIN0985-M10 | 2 |
| 1 | 0912101603 | AH SCREW DIN0912-M10X160 | 1 |
| 0934100003 | HEXAGON NUT DIN0934-M10 | ||
| 1 | 54630044000 | COLLAR NUT M10 WS=13 | 1 |
| 58303038000 | FOOTREST BRACKET L/S '93 LC4 '93 | ||
| 58303040000 | FOOTREST L/S ' LC4 '93 | ||
| 54603140000/19 | FOOT PED R/S | ||
| 58303041000 | FOOTREST SPRING L/S '93 LC4 '93 | ||
| 1 | 54603041000 | FOOTREST SPRING L/S & R/S | 1 |
| 58303044000 | BOLT FOR FOOTREST | ||
| 1 | 54603044000 | BOLT FOR FOOTREST 9,8 X 50 | 1 |
| 1 | 0125100003 | washer DIN 125 A 10.5 (As Required) | 1 |
| 2 | 0094032253 | PIN DIN0094-3,2X25 STEEL | 2 |
| 42007049000 | PLASTIC CAP | ||
| 49003250000 | FOOTREST REAR L/S CPL. | ||
| 49003350000 | REAR FOOT PED R/S | ||
| 58303045000 | FOOT PED PLASTIC LC4 '94 | ||
| 58303045050 | CARRIER | ||
| 1 | 50203053000 | CHAIN ROLL D=30MM | 1 |
| 50203053100 | CHAIN ROLL | ||
| 2 | 74003021000 | BUSHING 8.2 X 12 X 6 | 2 |
| 4 | 0625006087 | GROOVED BALL BEAR. 608 2RS C3 | 4 |
| 71004038000 | WASHER | ||
| 2 | 0985060003 | SELF LOCK. NUT DIN0985-M 6 | 2 |
| 1 | 58303063000 | BRAKE LEVER STOP '93 LC4 '93 | 1 |
| 1 | 0991060203 | FLAT H.SCREW DIN7991-M6X20 | 1 |
| 0931080403 | HH SCREW DIN931 M8x40 | ||
| 58303070000 | STOP RUBBER M8 | ||
| 1 | 0934080003 | HEXAGON NUT DIN0934-M 8 | 1 |
| 54310086000 | SELF LOCKING NUT | ||
| 2 | 0912080253 | AH SCREW DIN0912-M 8X25 | 2 |
| 54510052000 | SPROCKET SCREW | ||
| 4 | 0107080203 | AH OVAL H.SCREW DIN0170-M 8X20 | 4 |
| 1 | 0797080003 | TOOTHLOCK WASHER DIN6797-J 8,4 (As Required) | 1 |
| 1 | 0125080003 | washer DIN 125 A -8.4 (As Required) | 1 |
