Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 709401750 | Black, Upper Main Tube | 1 |
| 1 | 709401240 | Black, Handlebar Package DPS, XT, Hunting | 1 |
| 1 | 709402292 | Anodized Handlebar Package XTP, XXC | 1 |
| 1 | 709402063 | Sunburst Yellow, Handle Bar Package XMR Sunburst Yellow | 1 |
| 1 | 709401643 | Red, Handle Bar Package XMR Liquid Golg | 1 |
| 1 | 709401748 | Pitman Arm Except Package XMR | 1 |
| 1 | 709401756 | Pitman Arm Package XMR | 1 |
| 2 | 709400443 | Grey, Handle Grip Except Package Hunting Edition | 2 |
| 2 | 710005038 | Heated Hand Grip With Connector Package Hunting Edition | 2 |
| 1 | 414115200 | Tie-Rap 180 mm Package Hunting Edition | 1 |
| 2 | 709400449 | End Piece Except Packages XXC, XMR&XTP | 2 |
| 2 | 709400497 | Steering Support Packages XXC, XMR&XTP | 2 |
| 4 | 709401799 | Steering Support Except Packages XXC, XMR&XTP | 4 |
| 2 | 709400509 | Stiffner Except Packages XXC, XMR&XTP | 2 |
| 2 | 709400496 | Support Packages XXC, XMR&XTP | 2 |
| 2 | 205086060 | Socket Head Screw M8 X 60 Packages XXC, XMR&XTP | 2 |
| 4 | 207086046 | Hex. Screw M8 X 60 Except Packages XXC, XMR&XTP | 4 |
| 2 | 205083060 | Socket Screw M8 X 30 Packages XXC, XMR&XTP | 2 |
| 4 | 233281416 | Hex. Elastic Flange Nut M8 | 4 |
| 2 | 207183060 | Hex. Screw M8 X 30 Packages XXC, XMR&XTP | 2 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 4 | 709400783 | Spherical Half Bushing | 4 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 1 | 709400827 | Upper Column Attachment | 1 |
| 1 | 709401428 | Column Attachment | 1 |
| 2 | 703501039 | Tie-Rod Ass`y Includes 180 to 180b | 2 |
| 1 | 709402303 | LH Ball Joint | 1 |
| 1 | 709402302 | RH Ball Joint | 1 |
| 4 | 293300068 | O-Ring | 4 |
| 8 | 250200086 | Flat Washer | 8 |
| 4 | 250100099 | Nut M12 | 4 |
| 4 | 211400013 | Cotter Pin | 4 |
| 1 | 709400939 | Cover Package DPS | 1 |
| 1 | 709402112 | Cover Package XMR Liquid Gold | 1 |
| 1 | 709402113 | Cover Package XMR Sunburst Yellow | 1 |
| 1 | 709402113 | Cover Package XTP | 1 |
| 1 | 709400422 | Foam Packages XXC, XMR&XTP | 1 |
| 1 | 709402230 | Power Steering | 1 |
| 1 | 709402184 | LH Power Steering Bracket | 1 |
| 1 | 709402185 | RH Bracket | 1 |
| 1 | 709401743 | Power Steering Support | 1 |
| 11 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 11 |
| 2 | 250000986 | Hex. Flange Screw M8 X 35 | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 4 | 233081416 | Hex. Flange Nut M8 | 4 |
| 1 | 703100813 | Handle Guard Ass'y Package Hunting Edition | 1 |
| 1 | 703100352 | Handle Guard Ass'y, XT Package XT | 1 |
| 1 | 703100357 | Handle Guard Ass'y, LTD Package LTD | 1 |
| 1 | 715003811 | Deflector Kit Package XMR Liquid Gold | 1 |
| 1 | 709400822 | Handle Bar Protector Package XT | 1 |
| 1 | 709400822 | Handle Bar Protector Package LTD | 1 |
| 1 | 704902966 | DPS Decal Packages Hunting Edition, XT, LTD | 1 |
| 4 | 241142560 | Hex. Flange Screw K40 X 25 Packages Hunting Edition, XT, LTD | 4 |
| 4 | 211200035 | Flat Washer Packages Hunting Edition, XT, LTD | 4 |
| 2 | 517303264 | U-Clamp Packages Hunting Edition, XT, LTD | 2 |
| 1 | 709401303 | Deep Black RH Air Deflector Package XTP | 1 |
| 1 | 709401667 | Red, RH Deflector Package XMR Liquid Gold | 1 |
| 1 | 709402053 | Sunburst Yellow RH Air Deflector Package XMR Sunburst Yellow | 1 |
| 1 | 709402053 | Sunburst Yellow RH Air Deflector Package XXC | 1 |
| 1 | 709401304 | Deep Black LH Air Deflector Package XTP | 1 |
| 1 | 709401668 | Red, LH Deflector Package XMR Liquid Gold | 1 |
| 1 | 709402054 | Sunburst Yellow LH Air Deflector Package XMR Sunburst Yellow | 1 |
| 1 | 709402054 | Sunburst Yellow LH Air Deflector Package XXC | 1 |
| 2 | 205444056 | Socket Head Screw M4 X 40 Packages XXC, XMR&XTP | 2 |
| 2 | 232541414 | Elastic Stop Nut M4 Packages XXC, XMR&XTP | 2 |
| 2 | 715001378 | Air Deflector Support Kit Packages XXC, XMR&XTP | 2 |
| 1 | 715001378 | Air Deflector Support Kit Packages XXC, XMR&XTP | 1 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 Packages XXC, XMR&XTP | 2 |
| 4 | 232561600 | Hex. Elastic Stop Nut M6 Packages XTP & XMR | 4 |
| 2 | 250000717 | Torx Head Screw M6 X 16 Packages XTP & XMR | 2 |
| 2 | 709400161 | Small Bracket Packages XXC, XMR&XTP | 2 |
| 2 | 709400162 | Large Bracket Packages XXC, XMR&XTP | 2 |
| 2 | 205384034 | Socket Head Screw Packages XXC, XMR&XTP | 2 |
| 2 | 250000145 | Torx Screw M5 X 14 Package XTP | 2 |
| 2 | 250000742 | Torx Screw M5 X 14 Packages XXC & XMR | 2 |
| 2 | 232551600 | Hex. Elastic Nut M5 Packages XXC, XMR&XTP | 2 |
| 2 | 709400781 | Rubber Bumper Package LTD | 2 |
| 4 | 250000783 | Torx-Truss M/S M4 X 20 Package LTD | 4 |
| 4 | 234042600 | Flat Washer 4 mm, Stainless Package LTD | 4 |
| 4 | 232541414 | Elastic Stop Nut M4 Package LTD | 4 |
| 1 | 710003210 | GPS Support Package LTD | 1 |
| 1 | 293750058 | 2-Pieces Fixing Tie Rap for Edges Package LTD | 1 |
| 1 | 293750008 | Tie Wrap 368 mm Package LTD | 1 |
| 1 | 414115200 | Tie-Rap 180 mm Package LTD | 1 |
| 1 | 293750009 | Tie-Rap 173 mm Package LTD | 1 |
