Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 11340-24F00 | COVER, CLUTCH MODEL X | 1 |
| 1 | 11340-24F01 | COVER,CLUTCH MODEL Y/K1/K2/K3; Includes Item(s) 2 | 1 |
| 1 | 11971-33210 | .LENS, OIL LEVEL CHECK | 1 |
| 1 | 11482-24F00 | GASKET,CL COVER | 1 |
| 2 | 04211-09189 | PIN | 2 |
| 12 | 01547-06307 | BOLT MODEL X | 12 |
| 12 | 09103-06213 | BOLT (6X30) MODEL Y/K1/K2/K3 | 12 |
| 1 | 09259-20008 | PLUG, ENGINE OIL FILLER MODEL X/Y/K1/K2 | 1 |
| 1 | 11971-25D00 | PLUG,ENGINE OIL FILLER MODEL K3 | 1 |
| 1 | 09280-17003 | O RING (D:3.1,ID:16.8) | 1 |
| 1 | 11371-24F00 | COVER,CLUTCH OUTER | 1 |
| 1 | 11372-24F00 | CUSHION,CLUTCH OUTER COVER | 1 |
| 3 | 09139-06107 | SCREW (6X16) | 3 |
| 3 | 11373-24F00 | WASHER CLUTCH OUTER COV SCREW | 3 |
| 11380-24F01 | COVER, STARTER CLUTCH MODEL X/Y/K1/K2 | ||
| 1 | 11380-24F20 | COVER,STARTER CLUTCH MODEL K3 | 1 |
| 1 | 11491-24F00 | GASKET, STARTER CLUTCH COVER MODEL X | 1 |
| 1 | 11491-24F01 | GASKET,STARTER CLUTCH COVER MODEL Y/K1/K2/K3 | 1 |
| 2 | 04211-09149 | PIN | 2 |
| 6 | 01547-06257 | BOLT MODEL X | 6 |
| 6 | 09103-06212 | BOLT (6X25) MODEL Y/K1/K2/K3 | 6 |
| 1 | 01547-06357 | BOLT MODEL X | 1 |
| 1 | 09103-06214 | BOLT (6X35) MODEL Y/K1/K2/K3 | 1 |
| 1 | 09168-06023 | GASKET | 1 |
| 1 | 09259-36016-20H | PLUG, CRANKSHAFT HOLE MODEL X/Y/K1 | 1 |
| 1 | 09259-36021 | PLUG, SHAFT HOLE MODEL K2/K3 | 1 |
| 1 | 09280-33004 | O RING | 1 |
| 1 | 09248-16012 | PLUG, TDC (16X8) | 1 |
| 1 | 09168-16002 | GASKET | 1 |
| 11382-24F00 | CAP, STARTER IDLE GEAR MODEL X/Y/K1/K2 | ||
| 1 | 11382-24F20 | CAP,STARTER IDLE GEAR MODEL K3 | 1 |
| 1 | 11492-24F00 | GASKET,START IDLE GEAR CAP | 1 |
| 3 | 01547-06257 | BOLT MODEL X | 3 |
| 3 | 09103-06212 | BOLT (6X25) MODEL Y/K1/K2/K3 | 3 |
| 2 | 01547-06357 | BOLT MODEL X | 2 |
| 2 | 09103-06214 | BOLT (6X35) MODEL Y/K1/K2/K3 | 2 |
| 1 | 11351-24F00 | COVER,MAGNETO | 1 |
| 1 | 11483-24F00 | GASKET,MAGNETO COVER | 1 |
| 9 | 01547-06307 | BOLT MODEL X | 9 |
| 9 | 09103-06213 | BOLT (6X30) MODEL Y/K1/K2/K3 | 9 |
| 11361-24F00 | COVER, ENGINE SPROCKET MODEL X | ||
| 1 | 11361-24F10 | COVER, ENGINE SPROCKET MODEL Y/K1/K2/K3 | 1 |
| 1 | 11362-24F00 | PROTECTOR, ENGINE SPRKT COVER | 1 |
| 1 | 01547-06407 | BOLT MODEL X | 1 |
| 1 | 09103-06215 | BOLT (6X40) MODEL Y/K1/K2/K3 | 1 |
| 3 | 01547-06557 | BOLT MODEL X | 3 |
| 3 | 09103-06216 | BOLT (6X55) MODEL Y/K1/K2/K3 | 3 |
| 1 | 11383-24F00 | COVER, GEAR SHIFT | 1 |
| 1 | 11485-24F00 | GASKET,GEAR SHIFT COVER | 1 |
| 3 | 01547-06253 | BOLT | 3 |
| 2 | 01547-06353 | BOLT | 2 |
| 11330-24F01 | COVER, BREATHER | ||
| 09364-12002 | UNION, BREATHER | ||
| 1 | 11318-24F00 | GASKET, BREATHER COVER MODEL X | 1 |
| 1 | 11318-24F01 | GASKET, BREATHER COVER MODEL Y/K1/K2/K3 | 1 |
| 2 | 01547-06303 | BOLT MODEL X | 2 |
| 4 | 01547-06303 | BOLT MODEL Y/K1/K2/K3 | 4 |
| 2 | 01547-06503 | BOLT MODEL X | 2 |
| 11334-24F00 | BRACKET, OIL RETURN TANK MODEL X | ||
| 11330-02F01 | TANK, OIL RETURN MODEL X | ||
| 1 | 01550-06123 | BOLT MODEL X | 1 |
| 11332-24F00 | HOSE, BREATHER MODEL X | ||
| 2 | 09401-15101 | CLIP (ID:15.5) MODEL X | 2 |
| 11390-24F00 | HOSE, OIL DRAIN MODEL X | ||
| 1 | 09403-16307 | CLAMP, OIL DRAIN HOSE MODEL X | 1 |
