Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 24121-48E51 | SHAFT, CNTR (NT:13) | ||
| 24221-44B20 | GEAR, 2ND DRIVE (NT:19) | ||
| 24231-44B01 | GEAR, 3RD DRIVE (NT:20) MODEL V | ||
| 24231-44B02 | GEAR, 3RD DRIVE (NT:20) MODEL W/X/Y/K1/K2/K3 | ||
| 24241-44B01 | GEAR, 4TH DRIVE (NT:23) | ||
| 24251-44B10 | GEAR, 5TH DRIVE (NT:25) | ||
| 24252-38A00 | BUSH, 5TH DRIVE MODEL V/W/X/Y/K1 | ||
| 24252-38A10 | BUSH,6TH DRIVE GEAR MODEL K2/K3 | ||
| 1 | 09167-25021 | WASHER,LOCK (25.1X33X1.0) | 1 |
| 1 | 09262-25080 | BEARING, CNTR RH 25X62X17 | 1 |
| 09263-20084 | BEARING, CNTR LH 20X33X16 | ||
| 1 | 09300-25023 | BUSH, 4TH DRIVE MODEL V/W/X/Y/K1 | 1 |
| 1 | 24252-19F00 | BUSH, SUB T/M DRIVEN GR MODEL K2/K3 | 1 |
| 1 | 09380-25003 | RING,SNAP | 1 |
| 1 | 09380-25013 | CIRCLIP, 2ND | 1 |
| 1 | 08211-25351 | WASHER | 1 |
| 24130-48E01 | SHAFT, DRIVE MODEL V/W/X/Y/K1 | ||
| 24130-48E02 | SHAFT, DRIVE MODEL K3 | ||
| 24311-44B10 | GEAR, 1ST DRIVEN (NT:32) | ||
| 24321-44B20 | GEAR, 2ND DRIVEN (NT:30) | ||
| 24331-44B00 | GEAR, 3RD DRIVEN (NT:24) MODEL V | ||
| 24331-44B01 | GEAR, 3RD DRIVEN (NT:24) MODEL W/X/Y/K1/K2/K3 | ||
| 24332-27A00 | BUSH, 3RD DRIVEN | ||
| 24341-44B01 | GEAR, 4TH DRIVEN (NT:22) MODEL V | ||
| 24341-44B02 | GEAR, 4TH DRIVEN (NT:22) MODEL W/X/Y/K1/K2/K3 | ||
| 24351-44B01 | GEAR, 5TH DRIVEN (NT:20) MODEL V | ||
| 24351-44B10 | GEAR, 5TH DRIVEN (NT:20) MODEL W/X/Y/K1/K2/K3 | ||
| 1 | 09167-28001 | WASHER, 3RD DRIVEN RH 28.1X38X1 | 1 |
| 1 | 09167-28002 | WASHER, 3RD DRIVEN LH 28.1X43X1.5 | 1 |
| 1 | 09169-28001 | WASHER, 3RD DRIVEN LH 28.1X40X1 | 1 |
| 1 | 09181-20223 | WASHER, 1ST DRIVEN RH 20X32X1 | 1 |
| 1 | 09181-22223 | WASHER, 1ST DRIVEN LH 22X34X1 | 1 |
| 09181-28167 | WASHER, 2ND DRIVEN 28X36X1 | ||
| 1 | 09262-20059 | BEARING, RH (20X42X12) | 1 |
| 1 | 09262-25083 | BEARING, LH (25X62X17) | 1 |
| 1 | 09283-36003 | SEAL, DRIVE SHAFT OIL 36X50X6 | 1 |
| 1 | 09300-22005 | BUSH, 1ST DRIVEN MODEL V/W/X/Y/K1/K2 | 1 |
| 1 | 24312-02F00 | BUSH, 1ST DRIVEN MODEL K2/K3 | 1 |
| 1 | 09300-28002 | BUSH, 2ND DRIVEN | 1 |
| 1 | 08331-31286 | CIRCLIP, 2ND DRIVEN | 1 |
| 1 | 08331-31286 | CIRCLIP, 3RD DRIVEN | 1 |
| 24741-38A00 | RETAINER, CNTR SHAFT | ||
| 1 | 24742-44B00 | RETAINER, CNTR LH | 1 |
| 24751-48E00 | RETAINER, DRIVE SHAFT | ||
| 2 | 01500-06103 | BOLT, DRIVE | 2 |
| 2 | 02112-06123 | SCREW | 2 |
| 1 | 02122-06123 | SCREW | 1 |
| 1 | 27510-17C10 | SPROCKET, ENGINE (NT:15) | 1 |
| 1 | 27521-48E00 | NUT | 1 |
| 1 | 27531-24B00 | SPACER | 1 |
| 27600-19C00-116 | CHAIN ASSY (DID50VM,116LE) | ||
| 1 | 09167-25019 | WASHER (25.3X41.6X1) | 1 |
| 1 | 09160-25070 | WASHER (25.2X42X3.2) | 1 |
| 1 | 09280-24010 | O RING (D:2.4,ID:23.7) | 1 |
