Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13210-48E70 | CARBURETOR ASSY, FR MODEL V/W | ||
| 13210-48EB0 | CARBURETOR ASSY, FR MODEL V/W E33 | ||
| 13210-48EF0 | CARBURETOR ASSY, FR MODEL X/Y/K1/K2/K3 | ||
| 13210-48EG0 | CARBURETOR ASSY, FR MODEL X/Y/K1/K2/K3 E33; Includes Item(s) 1 - 53A | ||
| 2 | 02112-33073 | SCREW | 2 |
| 1 | 13387-47010 | RING | 1 |
| 1 | 13394-10010 | CLIP | 1 |
| 1 | 13382-44030 | WASHER MODEL V | 1 |
| 1 | 13382-03110 | WASHER MODEL W/X/Y/K1/K2/K3 | 1 |
| 1 | 13388-44030 | SPRING | 1 |
| 1 | 13383-48E80 | NEEDLE, JET (5C43-1) | 1 |
| 09494-00901 | JET, NEEDLE (P-4M) | ||
| 1 | 13605-38B00 | SCREW | 1 |
| 2 | 02112-04107 | SCREW | 2 |
| 1 | 13281-05A00 | PLUG | 1 |
| 1 | 13684-48E00 | HOSE (5X8X160) MODEL V/W/X E3,E28 | 1 |
| 1 | 13683-19B80 | HOSE (5X8X650) MODEL Y/K1/K2/K3 E3,E28 L:650!160 | 1 |
| 13684-48EA0 | HOSE (5X8X675) MODEL V/W E33 | ||
| 13683-33C20 | HOSE (5X8X80) MODEL X E33 | ||
| 1 | 13683-19B80 | HOSE (5X8X650) MODEL Y/K1/K2/K3 E33,L:650!80 | 1 |
| 1 | 13689-38A00 | SPRING MODEL X/Y/K1/K2/K3 E33 | 1 |
| 1 | 13681-04010 | CAP | 1 |
| 1 | 13278-47090 | O RING | 1 |
| 1 | 13418-38A00 | HOLDER | 1 |
| 1 | 13411-01400 | PLUNGER | 1 |
| 1 | 13417-08210 | SPRING | 1 |
| 1 | 09492-65005 | JET, AIR (65) | 1 |
| 1 | 09492-40021 | JET, PILOT (40) | 1 |
| 1 | 13502-45C10 | COVER MODEL V/W/X | 1 |
| 1 | 13502-38A00 | COVER MODEL Y/K1/K2/K3 | 1 |
| 1 | 13500-05A10 | DIAPHRAGM ASSY | 1 |
| 1 | 13503-38B00 | SPRING | 1 |
| 1 | 13389-37400 | PLATE | 1 |
| 1 | 02122-04103 | SCREW | 1 |
| 1 | 13251-38A00 | O RING | 1 |
| 1 | 13385-05A11 | HOLDER | 1 |
| 1 | 09491-90008 | JET, MAIN (90) MODEL V/W | 1 |
| 1 | 09491-90011 | JET, MAIN (90) MODEL X/Y/K1/K2/K3 | 1 |
| 1 | 13247-13A00 | .SCREW MODEL V/W/X | 1 |
| 1 | 13247-02340 | SCREW, DRAIN MODEL Y/K1/K2/K3 | 1 |
| 1 | 09404-06431 | CLAMP (L:65) MODEL V | 1 |
| 1 | 09404-06432 | CLAMP (L:65) MODEL W/X/Y/K1/K2/K3 | 1 |
| 1 | 13480-05A10 | DIAPHRAGM ASSY | 1 |
| 1 | 13481-45C10 | SPRING | 1 |
| 1 | 13484-38A00 | COVER | 1 |
| 4 | 13602-48B10 | SCREW | 4 |
| 1 | 08310-00047 | NUT | 1 |
| 02112-04307 | SCREW | ||
| 1 | 13554-45C00 | LEVER ASSY MODEL V | 1 |
| 1 | 13554-45C20 | LEVER ASSY MODEL W/X/Y/K1/K2/K3 | 1 |
| 1 | 13376-84110 | FILTER MODEL V/W/X | 1 |
| 1 | 13376-19F00 | FILTER MODEL Y/K1/K2/K3 | 1 |
| 1 | 13374-44080 | O RING MODEL V/W/X | 1 |
| 1 | 13374-35C00 | .O RING,NEEDLE VALVE SEAT MODEL Y/K1/K2/K3 | 1 |
| 1 | 13370-39A00 | VALVE ASSY, NEEDLE | 1 |
| 1 | 13602-05A10 | SCREW | 1 |
| 1 | 13250-38B00 | FLOAT | 1 |
| 1 | 13254-20010 | .PIN,FLOAT | 1 |
| 4 | 02112-05127 | SCREW | 4 |
| 1 | 13523-46110 | GASKET EXCEPT MODEL X/Y/K1/K2/K3 E33 | 1 |
| 1 | 09125-05122 | SCREW EXCEPT MODEL X/Y/K1/K2/K3 E33 | 1 |
| 1 | 13683-48EG0 | HOSE (5X8X450) MODEL X/Y E33 | 1 |
| 1 | 13683-19B80 | HOSE (5X8X650) MODEL K1/K2/K3 E33,L:650!450 | 1 |
| 1 | 13415-38300 | .E RING | 1 |
| 1 | 13279-47070 | SCREW, PILOT (1 3/4) | 1 |
| 1 | 13268-47070 | .SPRING | 1 |
| 1 | 13295-29900 | O RING | 1 |
| 1 | 13291-29900 | .WASHER (14X17) | 1 |
| 13331-33E00 | RING | ||
| 13602-48E00 | SCREW | ||
| 13627-48E00 | BRACKET, NO.1 | ||
| 13627-48E10 | BRACKET, NO.2 | ||
| 13683-48E10 | HOSE ASSY (5X8X125) MODEL X/Y/K1/K2/K3 E33 | ||
| 1 | 13683-48E00 | HOSE ASSY | 1 |
| 13683-48E10 | HOSE ASSY (5X8X125) E33 | ||
| 1 | 13641-48E00 | CABLE, ID SYNCHRO | 1 |
| 1 | 13642-48E00 | CABLE, THROTTLE RETURN,F-R | 1 |
| 1 | 09407-18403 | CLAMP MODEL V/W E33 | 1 |
| 13840-48E00 | SHEET, HEAT SHIELD MODEL V/W E33 %F.NO.V2102739 | ||
| 13840-48E01 | SHEET, HEAT SHIELD MODEL V/W E33 F.NO.V2102740% | ||
| 13840-48E01 | SHEET, HEAT SHIELD MODEL X E33 | ||
| 13684-48EG0 | HOSE (5.3X10.5X450) MODEL X/Y E33 | ||
| 13684-02F10 | HOSE (5.3X10.5X450) MODEL K1/K2/K3 E33 | ||
| 1 | 13685-48B00 | NIPPLE MODEL X/Y/K1/K2/K3 E33 | 1 |
| 1 | 09355-50105-600 | HOSE, AIR VENT (5X10X600) MODEL X/Y/K1/K2/K3 E33 L:600!500 | 1 |
| 13590-48E00 | VALVE, AIR VENT MODEL X/Y/K1/K2/K3 E33 | ||
| 2 | 01550-06123 | BOLT MODEL X/Y/K1/K2/K3 E33 | 2 |
