Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | F7G-U35A5-20-00 | Cushion, Fore 5 UR FOR VPCC1 | 1 |
| 1 | F7G-U35A5-30-00 | Cushion, Fore 5 UR FOR LNC3 | 1 |
| 1 | F7G-U35A6-20-00 | Cushion, Fore 6 UR FOR VPCC1 | 1 |
| 1 | F7G-U35A6-30-00 | Cushion, Fore 6 UR FOR LNC3 | 1 |
| 1 | F7G-U36A3-20-00 | Pad 3 UR FOR VPCC1 | 1 |
| 1 | F7G-U36A3-30-00 | Pad 3 UR FOR LNC3 | 1 |
| 3 | F1C-U5195-00-00 | Clip, 1 | 3 |
| 8 | 90167-08SA8-00 | Screw, Tapping | 8 |
| 1 | F7G-U36A4-20-00 | Pad 4 UR FOR VPCC1 | 1 |
| 1 | F7G-U36A4-30-00 | Pad 4 UR FOR LNC3 | 1 |
| 1 | F7G-U35A1-20-00 | Cushion, Fore 1 UR FOR VPCC1 | 1 |
| 1 | F7G-U35A1-30-00 | Cushion, Fore 1 UR FOR LNC3 | 1 |
| 1 | F7G-U35A2-20-00 | Cushion Seat, Front Right UR FOR VPCC1 | 1 |
| 1 | F7G-U35A2-30-00 | Cushion Seat, Front Right UR FOR LNC3 | 1 |
| 1 | F7G-U36B1-20-00 | Pad 10 UR FOR VPCC1 | 1 |
| 1 | F7G-U36B1-30-00 | Pad 10 UR FOR LNC3 | 1 |
| 2 | F1C-U5195-00-00 | Clip, 1 | 2 |
| 5 | 90167-08SA8-00 | Screw, Tapping | 5 |
| 1 | F7G-U36B2-20-00 | Pad 11 UR FOR VPCC1 | 1 |
| 1 | F7G-U36B2-30-00 | Pad 11 UR FOR LNC3 | 1 |
| 1 | F7G-U3796-20-00 | Back Rest 3 UR FOR VPCC1 | 1 |
| 1 | F7G-U3796-30-00 | Back Rest 3 UR FOR LNC3 | 1 |
| 4 | F1C-U5195-00-00 | Clip, 1 | 4 |
| 10 | 90167-08SA8-00 | Screw, Tapping | 10 |
| 1 | F7G-U3798-20-00 | Back Rest 4 UR FOR VPCC1 | 1 |
| 1 | F7G-U3798-30-00 | Back Rest 4 UR FOR LNC3 | 1 |
| 2 | F7G-U372F-00-00 | Cushion 5 UR FOR VPCC1 | 2 |
| 2 | F7G-U372F-30-00 | Cushion 5 UR FOR LNC3 | 2 |
| 1 | F7G-U371D-20-00 | Cushion 1 UR FOR VPCC1 | 1 |
| 1 | F7G-U371D-30-00 | Cushion 1 UR FOR LNC3 | 1 |
| 1 | F1C-U5192-00-00 | .Snap | 1 |
| 1 | 90202-06SA3-00 | .Washer, Plate | 1 |
| 1 | F7G-U3713-20-00 | Cushion,Seat UR FOR VPCC1 | 1 |
| 1 | F7G-U3713-30-00 | Cushion,Seat UR FOR LNC3 | 1 |
| 1 | F3F-U3714-21-00 | Bracket,Seat | 1 |
| 1 | F3F-U3714-31-00 | Bracket,Seat | 1 |
| 16 | 90201-10S00-00 | Washer, Plate | 16 |
| 16 | 90204-10S00-00 | Washer, Spring | 16 |
| 16 | 90170-10S00-00 | .Nut | 16 |
| 16 | 90151-10S24-00 | Screw, Countersunk | 16 |
| 16 | 90202-06SA3-00 | .Washer, Plate | 16 |
| 4 | 90185-10S00-00 | Nut, Self-Locking | 4 |
| 1 | F7G-U35C5-20-00 | Cushion, Main 5 UR FOR VPCC1 | 1 |
| 1 | F7G-U35C5-30-00 | Cushion, Main 5 UR FOR LNC3 | 1 |
| 1 | F7G-U35C6-20-00 | Cushion, Main 6 UR FOR VPCC1 | 1 |
| 1 | F7G-U35C6-30-00 | Cushion, Main 6 UR FOR LNC3 | 1 |
| 1 | F7G-U3791-20-00 | Back Rest 1 UR FOR VPCC1 | 1 |
| 1 | F7G-U3791-30-00 | Back Rest 1 UR FOR LNC3 | 1 |
| 7 | F1C-U5195-00-00 | Clip, 1 | 7 |
| 16 | 90167-08SA8-00 | Screw, Tapping | 16 |
| 1 | 90169-08SA9-00 | Screw, Truss Head Tapping | 1 |
| 1 | F7G-U35E2-20-00 | Backrest, Main 2 UR FOR VPCC1 | 1 |
| 1 | F7G-U35E2-30-00 | Backrest, Main 2 UR FOR LNC3 | 1 |
| 1 | F7G-U828B-20-00 | Cushion 1 UR FOR VPCC1 | 1 |
| 1 | F7G-U828B-30-00 | Cushion 1 UR FOR LNC3 | 1 |
| 2 | F1C-U5192-00-00 | .Snap | 2 |
| 2 | 90202-06SA3-00 | .Washer, Plate | 2 |
| 1 | F4Y-U724H-00-00 | Holder | 1 |
| 1 | F7G-U828C-20-00 | Cushion 2 UR FOR VPCC1 | 1 |
| 1 | F7G-U828C-30-00 | Cushion 2 UR FOR LNC3 | 1 |
| 1 | F7G-U379A-20-00 | Back Rest 6 UR FOR VPCC1 | 1 |
| 1 | F7G-U379A-30-00 | Back Rest 6 UR FOR LNC3 | 1 |
| 1 | F7G-U35E5-20-00 | . .Backrest, Main 5 UR FOR VPCC1 | 1 |
| 1 | F7G-U35E5-30-00 | . .Backrest, Main 5 UR FOR LNC3 | 1 |
| 1 | F7G-U36B4-20-00 | . .Pad 13 UR FOR VPCC1 | 1 |
| 1 | F7G-U36B4-30-00 | . .Pad 13 UR FOR LNC3 | 1 |
| 1 | F7G-U36B8-20-00 | . .Back Rest 6 UR FOR VPCC1 | 1 |
| 1 | F7G-U36B8-30-00 | . .Back Rest 6 UR FOR LNC3 | 1 |
| 1 | F7G-U36B6-20-00 | . .Pad 15 UR FOR VPCC1 | 1 |
| 1 | F7G-U36B6-30-00 | . .Pad 15 UR FOR LNC3 | 1 |
| 1 | F7G-U35L1-20-00 | . .Backrest, Aft 1 UR FOR VPCC1 | 1 |
| 1 | F7G-U35L1-30-00 | . .Backrest, Aft 1 UR FOR LNC3 | 1 |
| 1 | F7G-U379B-20-00 | Back Rest 7 UR FOR VPCC1 | 1 |
| 1 | F7G-U379B-30-00 | Back Rest 7 UR FOR LNC3 | 1 |
| 1 | F7G-U35E6-20-00 | . .Backrest, Main 6 UR FOR VPCC1 | 1 |
| 1 | F7G-U35E6-30-00 | . .Backrest, Main 6 UR FOR LNC3 | 1 |
| 1 | F7G-U36B7-20-00 | . .Back Rest 7 UR FOR VPCC1 | 1 |
| 1 | F7G-U36B7-30-00 | . .Back Rest 7 UR FOR LNC3 | 1 |
| 1 | F7G-U35L2-20-00 | . .Backrest, Aft 2 UR FOR VPCC1 | 1 |
| 1 | F7G-U35L2-30-00 | . .Backrest, Aft 2 UR FOR LNC3 | 1 |
