Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 504153718 | Chaincase Ass'y | 1 |
| 1 | 861805514 | Kit Plate Ass'y | 1 |
| 5 | 233261434 | Flange Elastic Nut M6 | 5 |
| 3 | 293150148 | Rivet Magna-Grip 6,4 X 50,8 | 3 |
| 3 | 293150149 | Collar Huck Magna-Grip 6.4 | 3 |
| 1 | 504082900 | Washer | 1 |
| 1 | 250000740 | Torx Screw M8 X 20, Scotch Grip | 1 |
| 2 | 233261434 | Flange Elastic Nut M6 | 2 |
| 1 | 293200168 | Oil Seal | 1 |
| 1 | 293350115 | Ball Bearing | 1 |
| 1 | 504152576 | Circlip | 1 |
| 1 | 504152628 | Shim | 1 |
| 1 | 504153911 | Sprocket 23 Teeth Includes 140 to 140 | 1 |
| 1 | 504153912 | Sprocket 25 Teeth | 1 |
| 1 | 504152784 | Spring Washer M10 | 1 |
| 1 | 207503046 | Hex. Flange Screw M10 X 30, Scotch Grip | 1 |
| 1 | 293200159 | Oil Seal | 1 |
| 1 | 293350059 | Ball Bearing | 1 |
| 1 | 504152582 | Circlip | 1 |
| 1 | 504153995 | Sprocket 45 Teeth Includes 1130 to 1130 | 1 |
| 1 | 504153997 | Sprocket 51 Teeths | 1 |
| 1 | 504152572 | Circlip | 1 |
| 1 | 293300201 | O-Ring | 1 |
| 1 | 504154019 | Magnetic Cap Includes 1160 to 1160a | 1 |
| 1 | 504154043 | Cap | 1 |
| 1 | 504152631 | Drive Chain, 108 Links | 1 |
| 1 | 504153268 | Drive Chain, 112 Links | 1 |
| 1 | 414575600 | Hair Pin | 1 |
| 1 | 504153760 | Adjustment Screw | 1 |
| 1 | 250500013 | Hex. Countersunk Drain Plug | 1 |
| 1 | 293300202 | O-Ring | 1 |
| 1 | 504153559 | Tensioner | 1 |
| 1 | 504153312 | Slider Chain | 1 |
| 1 | 293370105 | Circlip | 1 |
| 1 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 | 1 |
| 1 | 504154066 | Deep Black, Chain Case Cover Ass'y Includes 1700 to 1700c | 1 |
| 1 | 515178223 | Clip Connector | 1 |
| 1 | 415130141 | Braided Sleeve | 1 |
| 1 | 293300214 | O Ring | 1 |
| 8 | 250001153 | Hex. Flange Screw M6X20 | 8 |
| 504153535 | Cap Ass'y Includes 1740 to 1740c | ||
| 1 | 504152860 | Cap | 1 |
| 1 | 414580700 | Male Connector | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 504153695 | Bearing Housing Ass'y Includes 2500 to 2500a | 1 |
| 1 | 250300028 | Clinch Stud, M8 X 25 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 504154021 | Drive Axle Ass'y Includes 3000 to 3000e | 1 |
| 504153880 | Sprocket, 8 Teeth | ||
| 504153881 | Sprocket, 8 Teeth | ||
| 1 | 504153886 | Retaining Ring | 1 |
| 1 | 504153344 | Track Ass'y 15"X128"X1.25", RIP SAW Includes 3200 to 3200b | 1 |
| 1 | 504153345 | Track Ass'y 15"X128"X1.25", ICE RIPPER Includes 3200 to 3200b | 1 |
| 1 | 504154056 | Track Ass'y 15'' X 129'' X 1.5'' Includes 3200 to 3200b | 1 |
| 1 | 415129528 | Track Guide | 1 |
| 1 | 504152651 | Cleat | 1 |
