Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 715009108 | Liquid Titan, Frame Kit Includes 10 to 10a1gv | ||
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 1 | 705207424 | Front Plate | 1 |
| 2 | 207562034 | Hex. Flange Screw M6 X 20, Scotch Grip | 2 |
| 17 | 250100199 | Insert Half Hex Body M6 x 1.0 | 17 |
| 2 | 250100199 | Insert Half Hex Body M6 x 1.0 | 2 |
| 1 | 705206992 | Bumper Link | 1 |
| 1 | 250000857 | Flange Screw M12 X 60 | 1 |
| 1 | 250000060 | Flange Screw M10 X 16, Scotch Grip | 1 |
| 1 | 705209140 | Magma Red, Front Bumper Includes 40 to 40a1r | 1 |
| 4 | 390402200 | Pop Rivet 3/16" | 4 |
| 1 | 715006996 | Front Master Plate | 1 |
| 6 | 250100198 | Panel Nut M6 X 1.0 | 6 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 2 | 705202455 | Cap | 2 |
| 1 | 705206983 | U-Clamp | 1 |
| 2 | 233201436 | Hex. Flange Elastic Nut M10 | 2 |
| 1 | 705209878 | Liquid Titan, LH Reinforcement Cage Includes 50 to 50a1j | 1 |
| 8 | 390402200 | Pop Rivet 3/16" | 8 |
| 1 | 705209880 | Liquid Titan, RH Reinforcement Cage Includes 60 to 60a1j | 1 |
| 1 | 705206924 | DPS Support | 1 |
| 2 | 207581244 | Hex. Flange Screw M8 X 12, Scotch Grip | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 1 | 705210278 | Rear Upper Plate | 1 |
| 1 | 705210281 | Rear Central Plate | 1 |
| 1 | 705210275 | Rear Lower Plate | 1 |
| 1 | 708201098 | Assembly Kit Includes 200 to 200a | 1 |
| 2 | 705209866 | Liquid Titan, Connecting Plate | 2 |
| 1 | 705210271 | Connecting Plate | 1 |
| 4 | 250001195 | Elastic Flange Nut M12 | 4 |
| 2 | 705209861 | Liquid Titan, Rear Pillar | 2 |
| 4 | 705210648 | Sleeve | 4 |
| 1 | 705210001 | Safety Belt Anchorage | 1 |
| 4 | 232521416 | Elastic Stop Nut M12 | 4 |
| 1 | 705207425 | Upper Arm Link | 1 |
| 1 | 705210249 | Retaining Plate | 1 |
| 1 | 706203122 | Support | 1 |
| 2 | 390402200 | Pop Rivet 3/16" | 2 |
| 1 | 705209868 | Liquid Titan, Front Cross Member Includes 420 to 420a1j | 1 |
| 16 | 390402200 | Pop Rivet 3/16" | 16 |
| 1 | 705209870 | Liquid Titan, Rear Cross Member Includes 430 to 430a1h | 1 |
| 14 | 390402200 | Pop Rivet 3/16" | 14 |
| 1 | 715008452 | Liquid Titan, LH Cage Kit Includes 440 to 440a1u | 1 |
| 9 | 390402200 | Pop Rivet 3/16" | 9 |
| 1 | 715008466 | Liquid Titan, RH Cage Kit Includes 450 to 450a1u | 1 |
| 20 | 207523056 | Hex. Flange Screw M12 X 30, Scotch Grip | 20 |
| 14 | 250001195 | Elastic Flange Nut M12 | 14 |
| 12 | 250001195 | Elastic Flange Nut M12 | 12 |
| 2 | 250000856 | Hex. Flange Screw DIN.6921 M12X25 | 2 |
| 4 | 250000857 | Flange Screw M12 X 60 | 4 |
| 2 | 705206806 | Stiffner | 2 |
| 4 | 293150102 | Rivet 3/16" | 4 |
| 2 | 705206807 | Stiffner | 2 |
| 4 | 250000901 | Torx Truss M8 X 65 | 4 |
| 4 | 250000717 | Torx Head Screw M6 X 16 | 4 |
| 4 | 250100025 | Elastic Flange Nut M8 | 4 |
| 4 | 233261466 | Hex. Flange Elastic Nut M6 | 4 |
