Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 709401545 | Black, Upper Main Tube Model STD | 1 |
| 1 | 703501108 | Main Tube Kit Model DPS | 1 |
| 1 | 709401542 | Pitman Arm Model STD | 1 |
| 1 | 709401240 | Black, Handlebar | 1 |
| 1 | 703501110 | Pitman Arm Kit Models DPS and Mossy Oak Edition | 1 |
| 2 | 710005038 | Heated Hand Grip With Connector Model Mossy Oak Edition | 2 |
| 2 | 709400493 | Handle Grip Models STD and DPS | 2 |
| 2 | 709400449 | End Piece Models STD and DPS | 2 |
| 4 | 709401799 | Steering Support Model Mossy Oak Edition | 4 |
| 2 | 709400509 | Stiffner Model Mossy Oak Edition | 2 |
| 4 | 207086046 | Hex. Screw M8 X 60 Model Mossy Oak Edition | 4 |
| 4 | 233281416 | Hex. Elastic Flange Nut M8 | 4 |
| 1 | 250200086 | Flat Washer Model STD | 1 |
| 1 | 250000047 | Hex. Flange Elastic Nut M12 Model STD | 1 |
| 2 | 207682044 | Hex. Flange Screw M8 X 20 | 2 |
| 2 | 207682534 | Hex. Flange Screw M8 X 25 | 2 |
| 1 | 503190396 | Ball Bearing Model STD | 1 |
| 2 | 709400783 | Spherical Half Bushing Model STD and DPS | 2 |
| 2 | 709401370 | Spherical Half Bushing Model STD | 2 |
| 1 | 293250177 | Seal Model STD | 1 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 1 | 709400827 | Upper Column Attachment | 1 |
| 1 | 709401428 | Column Attachment | 1 |
| 2 | 703501038 | Tie Rod Ass`y Included 180 to 180b | 2 |
| 1 | 709402303 | LH Ball Joint | 1 |
| 1 | 709402302 | RH Ball Joint | 1 |
| 2 | 293300068 | O-Ring Model STD and DPS | 2 |
| 8 | 250200086 | Flat Washer | 8 |
| 4 | 250100099 | Nut M12 | 4 |
| 4 | 211400013 | Cotter Pin | 4 |
| 1 | 250400034 | Cotter Pin Model STD | 1 |
| 1 | 709400939 | Cover Model STD and DPS | 1 |
| 1 | 709402388 | Power Steering Ass'y Model DPS | 1 |
| 1 | 709402184 | LH Power Steering Bracket Model DPS | 1 |
| 1 | 709402185 | RH Bracket Model DPS | 1 |
| 1 | 709401743 | Power Steering Support Model DPS | 1 |
| 11 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip Model DPS | 11 |
| 2 | 250001133 | Hex. Flange Screw M8 X 45 Scotch Grip Model DPS | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 Model DPS | 2 |
| 4 | 233081436 | Hex. Flange Nut Model DPS | 4 |
| 1 | 703100813 | Handle Guard Ass'y Model Mossy Oak Edition | 1 |
| 1 | 704902966 | DPS Decal Model Mossy Oak Edition | 1 |
| 4 | 241142560 | Hex. Flange Screw K40 X 25 Model Mossy Oak Edition | 4 |
| 4 | 211200035 | Flat Washer Model Mossy Oak Edition | 4 |
| 2 | 517303264 | U-Clamp Model Mossy Oak Edition | 2 |
