Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 715009104 | Macchiato Satin, Frame Kit Includes 10 to 10a1fw | 1 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 1 | 705207424 | Front Plate | 1 |
| 2 | 207562034 | Hex. Flange Screw M6 X 20, Scotch Grip | 2 |
| 15 | 250100199 | Insert Half Hex Body M6 x 1.0 | 15 |
| 1 | 705206992 | Bumper Link | 1 |
| 1 | 250000857 | Flange Screw M12 X 60 | 1 |
| 1 | 250000060 | Flange Screw M10 X 16, Scotch Grip | 1 |
| 1 | 715009091 | Macchiato Satin, Front Bumper Kit Includes 40 to 40a1r | 1 |
| 4 | 390402200 | Pop Rivet 3/16" | 4 |
| 1 | 715006996 | Front Master Plate | 1 |
| 6 | 250100198 | Panel Nut M6 X 1.0 | 6 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 2 | 705202455 | Cap | 2 |
| 1 | 705206983 | U-Clamp | 1 |
| 2 | 233201436 | Hex. Flange Elastic Nut M10 | 2 |
| 1 | 705210064 | Deep Black, Reinforcement Cage Model Width 64 in. | 1 |
| 1 | 705210769 | Macchiato Satin, Reinforcement Cage Model Width 72 in. | 1 |
| 8 | 390402200 | Pop Rivet 3/16" | 8 |
| 1 | 705206924 | DPS Support | 1 |
| 2 | 207581244 | Hex. Flange Screw M8 X 12, Scotch Grip | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 1 | 705210278 | Rear Upper Plate | 1 |
| 1 | 705210281 | Rear Central Plate | 1 |
| 1 | 705210275 | Rear Lower Plate | 1 |
| 1 | 708201040 | Bag Kit Model Width 64 in. | 1 |
| 708201183 | Assembly Kit Model Width 72 in. | ||
| 2 | 705205926 | Black, LH Link Plate Model Width 64 in. | 2 |
| 705210773 | Macchiato Satin, Connecting Plate Model Width 72 in. | ||
| 1 | 715008492 | Junction Plate Kit | 1 |
| 4 | 250001195 | Elastic Flange Nut M12 | 4 |
| 2 | 705210066 | Deep Black, Rear Pillar Model Width 64 in. | 2 |
| 2 | 705210770 | Macchiato Satin, Rear Pillar Model Width 72 in. | 2 |
| 4 | 705210648 | Sleeve | 4 |
| 1 | 705210001 | Safety Belt Anchorage | 1 |
| 4 | 232521416 | Elastic Stop Nut M12 | 4 |
| 1 | 705207425 | Upper Arm Link | 1 |
| 1 | 705210249 | Retaining Plate | 1 |
| 1 | 706203122 | Support | 1 |
| 2 | 390402200 | Pop Rivet 3/16" | 2 |
| 1 | 715002889 | Black, Front Intrusion Bar Model Width 72 in. | 1 |
| 1 | 715003531 | Common Parts Kit Model Width 72 in. | 1 |
| 1 | 704904566 | Decal "Can-Am" Model Width 72 in. | 1 |
| 2 | 705205709 | Black, Clamp Model Width 72 in. | 2 |
| 1 | 705210068 | Deep Black, Front Cross Member Model Width 64 in. | 1 |
| 1 | 705210763 | Macchiato Satin, Front Cross Member Model Width 72 in. | 1 |
| 16 | 390402200 | Pop Rivet 3/16" | 16 |
| 1 | 705210070 | Deep Black, Rear Cross Member Model Width 64 in. | 1 |
| 1 | 705210764 | Macchiato Satin, Rear Cross Member Model Width 72 in. | 1 |
| 14 | 390402200 | Pop Rivet 3/16" | 14 |
| 1 | 715008442 | Black, LH Cage Kit Model Width 64 in. | 1 |
| 1 | 715009087 | Macchiato Satin, LH Cage Kit Model Width 72 in. | 1 |
| 6 | 390402200 | Pop Rivet 3/16" | 6 |
| 1 | 715008456 | Black, RH Cage Kit Model Width 64 in. | 1 |
| 1 | 715009089 | Macchiato Satin, RH Cage Kit Model Width 72 in. | 1 |
| 8 | 250001195 | Elastic Flange Nut M12 | 8 |
| 14 | 207523056 | Hex. Flange Screw M12 X 30, Scotch Grip | 14 |
| 6 | 250001195 | Elastic Flange Nut M12 | 6 |
| 4 | 250000857 | Flange Screw M12 X 60 | 4 |
| 4 | 293150102 | Rivet 3/16" | 4 |
| 4 | 250000901 | Torx Truss M8 X 65 | 4 |
| 4 | 250100025 | Elastic Flange Nut M8 | 4 |
