Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 64X-14711-00-9P | Muffler 1 | ||
| 1 | 6K8-51129-00-00 | . .Nipple | 1 |
| 1 | 62T-14613-00-00 | .Gasket, Exhaust Pipe | 1 |
| 6 | 90105-10M60-00 | Bolt, Flange | 6 |
| 90105-10M72-00 | Bolt, Washer Based | ||
| 64X-14712-00-9P | Ring, Joint | ||
| 64X-14749-00-00 | Gasket, Muffler Damper 2 | ||
| 2 | 93605-12M21-00 | Pin, Dowel | 2 |
| 90116-08M59-00 | Bolt, Stud | ||
| 2 | 92990-08100-00 | Washer, Spring | 2 |
| 2 | 95380-08600-00 | Nut | 2 |
| 2 | 90119-08M11-00 | Bolt, With Washer | 2 |
| 64X-14781-00-94 | Stay, Muffler 2 | ||
| 90105-10M73-00 | Bolt, Washer Based | ||
| 63M-12577-00-00 | Hose 2 | ||
| 2 | 90450-14M05-00 | Hose Clamp Assy | 2 |
| 1 | 90446-20M31-00 | Hose (L340) | 1 |
| 1 | 64X-14721-00-94 | Muffler 2 | 1 |
| 2 | 90105-10M60-00 | Bolt, Flange | 2 |
| 1 | 62T-41113-00-9M | Outer Cover, Exhaust | 1 |
| 1 | 62T-41114-01-00 | .Gasket, Exhaust Outer Cover | 1 |
| 6 | 97013-06025-00 | Bolt | 6 |
| 6 | 92903-06600-00 | Washer, Plate | 6 |
| 1 | 62T-14625-00-00 | Joint, Exhaust 2 | 1 |
| 2 | 90450-99M06-00 | Hose Clamp Assy | 2 |
| 64X-14615-00-00 | Joint, Exhaust 1 | ||
| 950-99M16-00 | Hose Clamp Assy | ||
| 64X-12582-00-00 | Joint, Hose 2 | ||
| 1 | 90450-22M14-00 | Hose Clamp Assy | 1 |
| 64X-41124-00-00 | Gasket, Exhaust Outer Cover | ||
| 64X-41123-00-9M | Outer Cover, Exhaust | ||
| 64X-14763-00-94 | Spacer | ||
| 1 | 64X-14623-00-00 | Gasket, Exhaust Pipe | 1 |
| 97085-06220-00 | Screw, With Washer | ||
| 90105-08M70-00 | Bolt, Washer Based | ||
| 90105-08M71-00 | Bolt, Washer Based | ||
| 64X-14717-01-00 | Plate, Stopper | ||
| 90119-08M37-00 | Bolt, With Washer | ||
| 1 | 90480-20M05-00 | Grommet | 1 |
| 1 | 62T-14771-00-94 | Stay, Muffler 1 | 1 |
| 4 | 90119-10M72-00 | Bolt, With Washer | 4 |
| 2 | 90105-10M45-00 | Bolt, Washer Based | 2 |
| 65V-14752-00-00 | Pipe, Outlet | ||
| 1 | 90450-88M15-00 | Hose Clamp Assy | 1 |
| 65V-12578-00-00 | Hose 3 | ||
| 1 | 90446-27M73-00 | Hose (L700) | 1 |
| 90445-14M06-00 | Hose (L630) | ||
| 1 | 64X-12581-00-00 | Joint, Hose 1 | 1 |
| 1 | 90450-18M09-00 | Hose Clamp Assy | 1 |
| 90445-14M10-00 | Hose (L500) | ||
| 1 | 63M-12580-00-00 | Joint Assy | 1 |
| 1 | 90446-24M89-00 | Hose (L420) | 1 |
| 1 | 682-84385-01-00 | Cap,1 | 1 |
| 1 | 63M-12590-00-00 | Conduction Assy | 1 |
| 1 | EU0-61652-00-00 | Nut | 1 |
| 1 | 90601-118UF-00 | Band, Hose 18 YMUS | 1 |
| GP7-672A4-00-00 | Nut, Thru-Hull | ||
| 90604-80797-00 | Through Hull Connection 3/8-12 | ||
| 1 | 90430-16910-00 | Gasket | 1 |
| 1 | 90450-14M05-00 | Hose Clamp Assy | 1 |
